Coleman VANQUISH 3AAA Manual

VANQUISH 3AAA
HEADLAMP 200LM
Fig. 1
Fig. 3
Fig. 5
Coleman Brands Pty. Ltd.
ABN 74 091 681 195
Suite W2C1, 75-85 O'Riordan Street,
Sydney Corporate Park, Alexandria, NSW 2015
Australia
Telephone: 1800 224 350
Email: customerservice@colemanaust.com.au
www.colemanaustralia.com.au
© 2016 The Coleman Company, Inc. All rights reserved.
Coleman®,
trademarks of The Coleman Company, Inc.
Fig. 2
Fig. 4
Fig. 6
and are registered
4010051667 (ECN20055562-01)
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using electric appliances, basic
precautions should always be followed, including
the following:
1. Keep AAA batteries away from small children. If
swallowed promptly see a doctor.
2. Do not install the batteries backwards, follow
the + and - symbols as shown in the instructions.
Do not charge or put in a re. Do not mix
alkaline, standard, or rechargeable batteries. Do
not mix old and new batteries. The batteries may
explode or leak causing injury.
3. Do not leave discharged batteries in the
product for an extended period of time as this
could permanently damage the product.
4. Replace all batteries at the same time.
5. Alkaline batteries can be safely disposed of
with normal household waste, but should be
recycled wherever possible.
SAVE THESE INSTRUCTIONS
TO INSTALL OR REPLACE BATTERIES IN
HEADLAMP
Your new headlamp operates on 3 "AAA" cell
batteries. For longest life, use alkaline batteries.
1. Gently pry to open the battery door by hands (Fig. 1).
2. Install the batteries with the correct polarity as
marked on the headlamp (Fig. 2).
3. Close the door by pressing rmly on the door
until it snaps to the closed position (Fig. 3).
TO OPERATE HEADLAMP
1. To cycle between modes or to turn the
headlamp o , press switch on the top until
desired mode is reached (Fig. 4).
2. If the light has been on in any mode for more than
5 seconds, the next press will turn the light o .
3. In any mode, hold down the switch for 3
seconds to change to distance detection mode.
• Distance detection mode will automatically
go to using both spot and area LEDs. It will
then adjust based on the distance control.
• To get out of the distance detection mode, hold
down the switch for 3 seconds again. This will
return to red ( rst normal mode setting).
TO OPERATE BATTERY LOCK
This light has the battery lock structure, which stops
the battery drain from device when locked. Turn the
headlamp to locked position when not in use.
1. To engage battery lock, pull the front and rear
body until the red area is fully shown. The
headlamp will not operate when in the locked
position (Fig. 5).
2. To operate headlamp, push the front and rear
body until the red area is fully hidden. The
headlamp will be unlocked and able to operate
as normal (Fig. 6).
THINGS YOU SHOULD KNOW
1. Operating time for this light depends on
whether it is run continuously or intermittently.
Intermittent operation extends the run time of
the batteries.
2. LEDs are lifetime light sources and do not need
to be replaced.
