Technical Data
(Scan engine)
Dimensions
Ambient temperature
Storage temperature
Weight
Interface options
Terminal assignment
(Handheld scanner)
Use the device only with iSCAN1XXCABX connection cable. The iSCAN102, PDF and 2D
may only be used in the hazardous area with iSCANPSCABR and iCSCANPSCABU
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E-mail: info@extronics.com Web:

iSCAN102 and iSCAN102PDF:

•
Light source
•
LED safety
•
Scan rate
•
Reader distance

iSCAN1022D:

•
LED lighting
•
Laser
•
LED safety
•
Laser safety
•
Scan rate
•
Reader distance
104 x 76 x 185 mm (length x width x height)
-20°C to +50°C
iSCAN102 and iSCAN102PDF:
-30°C to +70°C
iSCAN1022D:
-40°C to +70°C
ca. 200g (without connection cable)
RS232 TTL / USB
USB cable
USB/D+ green
USB/D- white
GND black
+UB brown
Visible red light 630nm
LED classification acc. to DIN EN 60825-1
500 scans per second
50mm to 800mm (0.5mm)
Visible red light 630nm
Visible red light 630nm
LED classification acc. to IEC62471
Laser classification acc. to IEC60825-1 Class 1
60 scans per second
30mm to 400mm (0.13mm)
RS232 cable
RS232-TXD white
GND brown
+UB yellow
