Heavy-Duty Rolling
TV/Monitor Cart with
Crank Handle
Model: DMCS60100XXCK
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY
OR PROPERTY DAMAGE MAY OCCUR!
100"
MAX
220 lb./100 kg
220 lb./100 kg
Tripp Lite по адресу: tripplite.com
®
Copyright © 2021 Tripp Lite. All rights reserved.
1
TV
TV
DVD
DVD
11 lb./5 kg (x2)
11 lb./5 kg (x2)
MAX
MAX
MAX
MAX
CAMERA
CAMERA
11 lb./5 kg
11 lb./5 kg
MAX
MAX
Advertisement
Related Manuals for Tripp Lite DMCS60100XXCK
Summary of Contents for Tripp Lite DMCS60100XXCK
- Page 1 800 x 600 / 1000 x 600 Este manual esta disponible en español en la página de Tripp Lite: tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании...
-
Page 2: Safety Instructions
PRODUCT REGISTRATION Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. -
Page 3: Component Checklist
Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit tripplite.com/support for service. Left Leg (x1) Right Leg (x1) Middle Base (x1) Left Cover (x1) Plastic Cover (x2) Universal Plate (x1) Plastic Handle (x2) - Page 4 Assembly CAUTION: Hold the inner column when loosening screws to adjust height. Adjust to the desired height, then tighten the screws, leaving Install the heavy-duty locking a small gap between casters into the threaded caster slots. Use the wrench screws (Z) and the (C1) to tighten the casters .
- Page 5 Assembly CAUTION: After assembling the universal plate (F) to the columns as shown, tighten the screws (Z). Note: Adjust the height with the crank handle (L), then tighten the screw (U).
- Page 6 Assembly...
- Page 7 Assembly Note: Choose the appropriate screws, washers and spacers (if needed) according to the type of screen. Screw the adapter brackets onto the display. CAUTION: Tighten all screws but do not over tighten.
- Page 8 Assembly Notes: • To lock, rotate the bottom screws counterclockwise. • To unlock, rotate the bottom screws clockwise. Note: Use a padlock (not included) to protect the display from tampering or theft. CAUTION: Be sure the display is correctly mounted and the screws are securely tightened before releasing the display.
- Page 9 Assembly...
- Page 10 Adjustment Keep the monitor arm horizontal while making spring tension adjustments. Prior to any arm movement, fully remove the Allen key. (Note: DO NOT over-tighten screw.) Note: Loosen the screw, as shown. Use the handle to adjust the column to the desired height, then tighten the screw to secure.
-
Page 11: Maintenance
Adjustment Note: To adjust the DVD shelf to the desired height, loosen the screws on both support blocks, then tighten all screws to secure. Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). •... - Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 21-08-119 933F2E_RevB...
