Owner's Manual
Dual Flat-Panel
200x200 / 300x200
300x300 / 400x200
400x300 / 400x400
Este manual esta disponible en español en la página de Tripp Lite:
Ce manuel est disponible en français sur le site Web de Tripp Lite :
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: www.tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
19-04-452-933908-EN.indd 1
Mobile Cart
Model: DMCSD3545M
45"
MAX
www.tripplite.com
www.tripplite.com
verfügbar: www.tripplite.com
PROTECT YOUR INVESTMENT!
www.tripplite.com/warranty
Copyright © 2019 Tripp Lite. All rights reserved.
88 lb. x 2
(40 kg x 2)
TV
1
11 lb.
11 lb.
(5 kg)
(5 kg)
DVD
WEBCAM
5/6/2019 9:43:43 AM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tripp Lite DMCSD3545M
Summary of Contents for Tripp Lite DMCSD3545M
- Page 1 WEBCAM Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com...
-
Page 2: Warranty And Product Registration
FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products. -
Page 3: Component Checklist
Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit www.tripplite.com/support for service. Left Plastic Cover Right Plastic Cover Middle Base DVD Shelf Universal Plate Top Covers Cable Covers Left Column... - Page 4 Component Checklist Package P Butterfly Nuts Butterfly Nuts M8x30 M8x40 M6x14 M6x25 M6x8 M6x14 M8x65 M4x6 M4x6 D8 Washers D6 Washers 5 mm Hex Key Wrench Package M M5x14 M6x14 M8x20 M6x30 M8x30 Washer Small Spacer Big Spacer 19-04-452-933908-EN.indd 4 5/6/2019 9:43:43 AM...
-
Page 5: Assemble The Base
Assembly Assemble the Base Using M8x40 screws (P-D) and the 5 mm hex key (P-N), attach the right base to the middle base. Repeat this step for the left base. Note: Lock the brakes on the casters to avoid any sudden movements during installation. Each caster can be adjusted independently for fine adjustments. - Page 6 Assembly Attach the Columns to the Base Inner Column Tighten the Safety Screw. Pull the pin outward and lift the inner column upward at the same time until the inner column is at the desired height. Release the pin to secure. Using M8x30 screws (P-C), attach the columns to the base.
- Page 7 Assembly Install the Crossbar Using M6x14 screws (P-H), attach the crossbar to the columns. Once the crossbar installation is completed, use the 5 mm hex key (P-N) to tighten the bottom screws on the base. Install the Cable Covers 19-04-452-933908-EN.indd 7 5/6/2019 9:43:45 AM...
- Page 8 Assembly Install the Universal Plate P-B P-L Using M8x65 screws (P-I), D8 washers (P-L) and butterfly nuts (P-B), attach the universal plate to the columns. 19-04-452-933908-EN.indd 8 5/6/2019 9:43:46 AM...
- Page 9 Assembly Install the Adapter Brackets Top of the display. Install the Adapter Brackets For Flat-Back Screen Note: Choose appropriate screws and washers according to the type of screen. • Screw the adapter brackets onto the display. Tighten all screws, but do not over-tighten. 19-04-452-933908-EN.indd 9 5/6/2019 9:43:46 AM...
- Page 10 Assembly Install the Adapter Brackets For Recessed-Back Screen or to Access A/V Inputs Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Screw the adapter brackets onto the display. Tighten all screws, but do not over-tighten. 19-04-452-933908-EN.indd 10 5/6/2019 9:43:47 AM...
- Page 11 Assembly Attach the Displays onto the Universal Plate • Hang the displays onto the universal plate. • Tighten the bottom screws to secure. Make sure the displays are mounted correctly and the screws are tightened safely before releasing the displays. 19-04-452-933908-EN.indd 11 5/6/2019 9:43:47 AM...
- Page 12 Assembly Install the Camera Shelf Using M4x6 screws (P-J) and (P-K), attach the camera shelf to the connecting plate. P-M P-F Using M6x25 screws (P-F) and D6 washers (P-M), attach the connecting plate to the universal plate. 19-04-452-933908-EN.indd 12 5/6/2019 9:43:48 AM...
- Page 13 Assembly Install the DVD Shelf Using M6x8 screws (P-G), attach the support bar to the columns at the desired position. Using M6x25 screws (P-F), M6x8 screws (P-H) and butterfly nuts (P-A), attach the DVD shelf to the support bar. 19-04-452-933908-EN.indd 13 5/6/2019 9:43:49 AM...
-
Page 14: Cable Management
Assembly Cable Management Route the cables through the cable covers. 19-04-452-933908-EN.indd 14 5/6/2019 9:43:50 AM... - Page 15 Assembly Adjustment +10° –10° TV height is measured from the floor to the TV center. • Adjust the columns to the desired height before installing the display. • If adjusting the column height after completing the display installation, first remove the DVD shelf, then adjust the columns to the desired height.
-
Page 16: Maintenance
Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit www.tripplite.com/support if you have any questions. 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 19-04-452 93-3908_RevB 19-04-452-933908-EN.indd 16 5/6/2019 9:43:51 AM...
