Before using your washing machine,please read this
manual carefully and keep it for future reference.
Front Loading Combo
OWNER'S MANUAL
COMBI-110
Read This Manual
Inside you will find many helpful hints on how to use
and maintain your washing machine properly. Just
a little preventative care on your part can save you
a great deal of time and money over the life of your
washing machine. You'll find many answers to
common problems in the chart of troubleshooting
tips. If you review the chart of Troubleshooting Tips
first, you may not need to call for service.
Advertisement
Table of Contents
Related Manuals for P&C COMBI-110
Summary of Contents for P&C COMBI-110
- Page 1 Before using your washing machine,please read this manual carefully and keep it for future reference. Front Loading Combo OWNER’S MANUAL COMBI-110 Read This Manual Inside you will find many helpful hints on how to use and maintain your washing machine properly. Just...
-
Page 2: Table Of Contents
Contents Safety And Precautions Contents Safety and precautions Safety And Precautions..................2 This manual contains important information on the installation, use, and care of your appliance. Please read this manual carefully before installation and operation of this Safety and precautions................machine to prevent injury and property damage. Important safety instructions................ -
Page 3: Safety And Precautions
Safety And Precautions Safety And Precautions Important safety instructions Important safety instructions SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons - Do not machine wash fiberglass materials (such as curtains and window coverings that use fiberglass materials.)Small particles may remain in the when using your appliance, follow basic precautions, including the following: washing machine and stick to fabrics in subsequent wash loads causing skin... -
Page 4: Grounding Instructions
Safety And Precautions Safety And Precautions Important safety instructions Grounding instructions SAVE THESE INSTRUCTIONS - If connected to a circuit protected by fuses, use time-delay fuses with this - This appliance must be grounded . In the event of a malfunction or breakdown, appliance. -
Page 5: Cautions When Washing Clothes
Safety And Precautions Installation Requirements Installation requirements Cautions when washing clothes - Cold water shall be used and hot water may be also connected according to 1.This machine must be earthed properly. If there is any short circuit, earthing can the local situations. -
Page 6: Location Requirements
Installation Requirements Installation Requirements Location requirements Electrical requirements Selecting the proper location for your washer improves performance and minimizes noise 1.A120v.60Hz,AConly,15-or 20amp,fused electrical supply is required. A time-delay fuse or and possible washer “walk.”Your washer can be installed under a custom counter,or in a circuit serving only this appliance be provided . -
Page 7: Installation Instructions
Installation Instructions Installation Instructions Install inlet pipe Dispose the packing materials The packing materials of this machine may be dangerous to children. Please dispose of them 1.Connect the elbow to tap and fasten it properly and immediatelly. Please dispose of the related packing materials clockwise. -
Page 8: Level The Washer
Installation Instructions Operating Instructions Level the washer Operating instructions 1.When positioning the washing machine, please WARNING – To reduce the risk of fire, electric shock, or injury to first check if the legs are closely attached to the persons, read the IMPORTANT SAFETY INSTRUCTIONS before cabinet. -
Page 9: Operating Instructions
Operating Instructions Operating Instructions Checklist and preparation before washing clothes Checklist and preparation before washing clothes Wrinkle-style clothes, embossed clothes, resin clothes etc. may get distorted when being Size: articles of different sizes are washed together to increase the washing effects. immersed in water. -
Page 10: View Of Control Panel
Operating Instructions Operating Instructions Checklist and preparation before washing clothes View of control panel The clothes which easily get fuzzed shall be turned over for washing The clothes which easily get fuzzed shall be washed separately; otherwise the other articles can be stained with dust and thrum etc. Preferably, black clothes and cotton clothes shall be washed separately because they can easily get stained with the thrums of other colors when being washed together. - Page 11 Operating Instructions Operating Instructions View of control panel View of control panel View of the programme Normal/Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen. - Heavy Duty Intended for washing heavy clothing like towels. - Bulky/Large This program is intended for washing large clothing . - Sports Wear Activewear.
-
Page 12: Select The Procedure
Operating Instructions Operating Instructions View of control panel -Timed Dry Extra Rinse The laundry will undergo extra rinse once after you select it. -Dry Press the Dry button continuously to choose the dry level: Extra Dry /Normal Dry/Gentle Dry. Load(kg) Dry programme Dry Capacity The reference weight of dry clothes... - Page 13 Operating Instructions Operating Instructions Table of washing procedures Heavily soiled, pure white cotton or flax (for example: coffee Extra Hot table cloths, canteen table cloths, towels, bed sheets) Washing/ Default Delay Soil Time Extra Programme Temp. °C Spin Moderately solided, colorful flax, cotton and synthetic articles Drying Load (kg)
-
Page 14: Care And Cleaning
Care And Cleaning Care And Cleaning Care and cleaning Care and cleaning Before your maintenance starts, please remove the power plug or disconnect power Remove the remaining water in drain pump and close the tap. - Solvents are forbidden as to avoid the being washing machine damaged, and o avoid burning, to be done after the hot water inside the machine has cooled down. - Page 15 Care And Cleaning Care And Cleaning Care and cleaning Care and cleaning Pull out the power plug to avoid electrical shock before washing. Emergency Door Release After using the washing machine, pull out the power cord and close the door tightly to avoid pinching the children.
-
Page 16: Troubleshooting Tips
Troubleshooting Tips Remove The Problems Troubleshooting tips Remove the problems The start of the appliance does not work or it stops during operation. Troubles Reason Solution First try to find a solution to the problem, If not, contact the service centre. Check if the door is closed tightly. -
Page 17: Appendix
Appendix Technical Specifications Appendix Technical specifications Care Lable Illustration Illustration Graphic Symbol Graphic Symbol Power Supply 120V , 60Hz Dimension(W*D*H) 595*595*850 Hand Wash No Machine Wash Net Weight 73kg (161Ib) Washing (including Machine Do not Wash Wash and Hand Wash) Washing Capacity 12.0kg (26Ib) No Dry Clean...
