- Page 1 25 Litre Electronic Microwave Owner s Instruction Manual UBCOMBI25SS UBCOMBI25BK Read the Instructions carefully and Keep for Future Reference...
- Page 2 Important safety instructions When using electrical appliance basic safety precautions should be followed, including the following: warning: to reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1.Read all instructions before using the appliance. 2.Use this appliance only for its intended use as described in this manual.
- Page 3 7.To reduce the risk of fire in the oven cavity: a.When heating food in plastic or paper container, keep an eye on the oven due to the possibility of ignition. b.Remove wire twist-ties from paper or plastic bags before placing bag in oven. c.If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
- Page 4 needed to handle the utensil. 15.Utensils should be checked to ensure that they are suitable for use in microwave oven. 16.Warning: it is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.
- Page 5 damaged and the warranty would be avoid . 21.The accessible surface may be hot during operation. 22.The door or the outer surface may get hot when the appliance is operating. 23.The temperature of accessible surfaces may be high when the appliance is operating. 24.The appliance shall be placed against a wall.
- Page 6 31.The microwave oven is intended for defrosting, cooking and steaming of food only. 32.Use gloves if you remove any heated food. 33.Caution! Steam will escape, when opening lids or wrapping foil. 34.If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle.
-
Page 7: Specifications
SPECIFICATIONS Power consumption: 230V~50Hz,1400W Output: 900W Grill Heater: 1200W Convection: 1350W Operating Frequency: 2,450MHz Outside Dimensions: 592mm(W) X 530mm(D) X 390mm(H) Oven Cavity Dimensions: 330mm(W) X 330mm(D) X 212mm(H) Oven Capacity: 25 litres Uncrated Weight: Approx.17.5kg BEFORE YOU CALL FOR SERVICE 1. - Page 8 INSTALLATION 1. Make sure all the packing materials are removed from 3. This Microwave Oven weighs kg and must be the inside of the door. placed on a horizontal surface strong enough to support this weight. 2. Inspect the oven after unpacking for any visual 4.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS -WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated; (Only for the model with grill function) -WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;...
-
Page 10: Feature Diagram
6. Do not insert any object into the openings on the outer removed from the oven, please remember that case. the food/liquid inside will be releasing the same 7. Do not at any time remove parts from the oven such as amount of steam and/or spitting when the lid is the feet, coupling, screws, etc. -
Page 11: Display Window
(1) DISPLAY WINDOW (3) G G rill (2) Conve (4) Micro Conve Grill Micro (6) G C ombi (5) Memory (7) Auto Menu Memory Combi Auto Menu (9) Pause/Cancel (8) Clock/Timer (10) Start Start Pause/ Clock/Timer Cancel (11) Defrost/Time Setting... - Page 12 P100 P100 P100 The longest microwave heating time is 60 minutes. Microwave power have 5 settings,and it’s P100 、 P70、 P50、 P30 and P10 from high to low power. 500g food Time setting...
- Page 13 Weight Menu Reheat Meat Potato Pizza Fish Chicken Touching Times 1000 1200 1400 1100 1600 1300 1300 1800 1500 1500 1000 2000 5. Memory cooking function: This function can memorize some useful cooking programes to avoid reseting time and power operation. a) If no memory has been set press "memory"...
- Page 14 ose 2 Clock/Timer Clock/Timer Clock/Timer imer Under standby situation, T o activate the child safety lock, press "Auto menu" and "Combi" at the same time for 2 seconds. Press "Auto menu" and "Combi" at the same time for 2 seconds again, it will unlock the machine.
- Page 15 SCHEMATIC DIAGRAM ( DOOR CLOSED,COOK OFF CONDITION) NOISE FILTER TRANSFORMER MAGNETRON H.V. RECTIFIER CONTROLLER THERMISTOR P( OUT) R4-1 T( IN) R4-2 SWA: THE FIRST DOOR SAFTY SWITCH L: LAMP SWB: THE SECOND DOOR SAFTY SWITCH FM: FAN MOTOR SWC: THE THIRD DOOR SAFTY CONTROL SWITCH TM: TURNTABLE MOTOR CM: CONVECTION MOTOR *CIRCUIT SUBJECT TO CHANGE WITHOUT NOTICE...
