Insérez 4 x pied réglable (1) dans 2 x cadre latéral (A).
Fixez 4 x barre transversale (B) à 2 x cadre latéral (A) à l'aide de 16
x vis (2).
Insert 4 x adjustable foot (1) into 2 x side frame (A).
Attach 4 x cross brace (B) to 2 x side frame (A) using 16 x screw (2).
ASSEMBLY INSTRUCTIONS
Description
QTÉ/QTY
Cadre latéral
2
Side frame
Barre transversale
4
Cross brace
Panneau
2
Panel
9400343
-by-step instructions.
No.
Illustration
1
Pied réglable
Adjustable foot
Vis
2
Screw
Vis
3
Screw
Description
QTÉ/QTY
4
16
8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bouclair 9400343
Summary of Contents for Bouclair 9400343
- Page 1 ASSEMBLY INSTRUCTIONS 9400343 IMPORTANT AVERTISSEMENT IMPORTANT -by-step instructions. WARNING Illustration Description Illustration Description QTÉ/QTY QTÉ/QTY Cadre latéral Pied réglable Side frame Adjustable foot Barre transversale Screw Cross brace Panneau Screw Panel Insérez 4 x pied réglable (1) dans 2 x cadre latéral (A).
