- Page 1 LasTec Articulator Model 325EFJ Owner’s Manual Manual Part Number: Man-325EFJ LasTec A Division of Wood-Mizer Products, Inc. 7865 N County Rd 100E Lizton, Indiana 46149 Phone (317) 892-4444 Fax (317) 892-4188 www.lastec.com...
-
Page 3: Table Of Contents
Every 25 Operating Hours................5-1 Every 50 Operating Hours................5-2 Every 500 Operating Hours................5-2 Annual ......................5-2 Model 325EFJ Articulator Specifications............5-3 Model 325EFJ Articulator Maintenance Chart..........5-5 Table of Contents LASdoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 4: To The Owner
You should now fill out the warranty registration form (located in the back of this section) and mail or fax it to LasTec. This form must be completed and returned to the factory within thirty (30) days of purchase in order to validate the warranty. Please do not hesi-... -
Page 5: Lastec Product Warranty
90 days from the date of delivery of the new LasTec product to the original purchaser. Under no circumstances will it cover any merchandise or components thereof, which, in the opinion of the company has been subjected to negligent handling, misuse, alteration, accident, or repairs made with any parts other than those obtainable through LasTec. -
Page 6: Servicing The Articulator
Be sure to complete the following LasTec Warranty Registration Form and return to LasTec within 30 days of the purchase of your Articulator. This will aid you, LasTec, and your LasTec dealer in the warranting and servicing of your Articulator. - Page 7 Who referred you to the Articulator? Who was the salesman that assisted you? Please check the box to your left if you would not allow Lastec to use your company's name for marketing purposes. Go to www.lastec.com for latest changes in this manual.
- Page 8 Go to www.lastec.com for latest changes in this manual.
-
Page 9: Safety Information
Be familiar with and follow all safety rules in this manual as well all safety rules for any related equipment. Safety Information 325EFJ/Odoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 10: Safety Guards And Covers
-- never operate the Articulator with any of the safety covers removed! Safety is a primary concern in the design and manufacture of all LasTec products. Unfor- tunately, our extensive efforts to provide safe equipment can be negated by a single care- less act of an operator. -
Page 11: Preparational Safety Rules
Always perform the pre-operation equipment inspection (Section 3) and the appro- priate maintenance schedule (Section 5) before operating the Articulator. Do not change the engine governor settings or over-speed the engine. Safety Information 325EFJ/Odoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 12: Operational Safety Rules
Reduce speed on slopes and in sharp turns to minimize potential tipping or loss of control. Use caution when changing directions on slopes. Be alert for holes in the terrain as well as any other hidden hazard. Always drive 325EFJ/Odoc100499 Safety Information Go to www.lastec.com for latest changes in this manual. -
Page 13: Maintenance Safety Rules
Articulator. Always use personal protection equipment such as eye, hand, head, and ear pro- tection when performing any service or maintenance to the tractor or Articulator. Safety Information 325EFJ/Odoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 14: Storage Safety Rules
Sand chipped or scratched areas and re-paint them to prevent rust during storage. Lubricate all moving parts of the tractor and Articulator to prevent rust during stor- age. Safety Information 325EFJ/Odoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 15: Initial Set-Up
Use the supplied coupler adapters. Be sure that all rubber O-rings are in place before installing. 12. Approximate the position of the Articulator in front of the tractor. Initial Set-Up 325EFJ/Odoc061600 Go to www.lastec.com for latest changes in this manual. -
Page 16: Hydraulic Motor
If the belt you are check- ing is new, and the idler tensioner goes to its maximum stroke without adequately tightening the belt, it is likely you have installed the wrong size belt. Contact your LasTec dealer for the proper belt lengths for your Articulator. -
Page 17: Deck Belts
If the belt you are check- ing is new, and the idler tensioner pivots to its maximum stroke without adequately tightening the belt, it is likely you have installed the wrong size belt. Contact your LasTec dealer for the proper belt lengths for your Articulator. -
Page 18: Blades
Keep all personnel clear of all controls while inspecting, adjusting, changing, or performing maintenance to the blades! The Model 325EFJ Articulator utilizes three individual 25” high-lift blades, located under each articulated cutting deck. NEVER go near, or expose yourself or others in any way to the blades while the engine is... -
Page 19: Deck Cutting Height
NEVER attempt to change the cutting deck height while the engine is running! The Model 325EFJ Articulator has a standard cutting range of 1" to 4 1/2", in 1/4" incre- ments. If you wish to change the deck cutting height, do so before attempting to operate the Articulator. -
Page 20: General
Check that the discharge chute is clear of debris, properly mounted, and in good condi- tion. Inspect entire Articulator for loose or entangled parts, debris, obstructions, neglected tools, or any other possible safety hazards, equipment hazards or projectile hazards. Initial Set-Up 325EFJ/Odoc061600 Go to www.lastec.com for latest changes in this manual. -
Page 21: Pre-Operation Equipment Inspection Checklist
Inspect entire Articulator for loose or entangled parts, debris, obstructions, or neglected tools. Perform all safety, set-up, and pre-operation procedures listed in your tractor manual. Complete the appropriate maintenance checklist (section 5). Initial Set-Up 325EFJ/Odoc061600 Go to www.lastec.com for latest changes in this manual. -
Page 22: Operating Procedures
NEVER raise the Articulator into transport position while the PTO is engaged! The Model 325EFJ Articulator can easily be lifted and transported by the tractor. Once the deck lift chains are adjusted, simply lift the arms to their maximum height. This will allow for easy transpor, transport over curbs and other obstructions, as well as extending the overall life of the Articulator. - Page 23 If the Articulator appears to be operating correctly, slowly increase the tractor idle until the hydraulic motor is operating at the tractor manufacturer’s recommended operating RPM. DO NOT EXCEED THIS RPM DURING OPERATION OF THE ARTICULATOR. 325EFJ/Odoc100499 Operating Procedures Go to www.lastec.com for latest changes in this manual.
-
Page 24: Ground Speed
25" push mower set at the same height as the Articu- lator. If the mower cuts without scalping, the Articulator should be able to handle the area. Operating Procedures 325EFJ/Odoc100499 Go to www.lastec.com for latest changes in this manual. -
Page 25: Cutting Wet Grass
Cutting Wet Grass Operation of the Articulator is not adversely affected by wet cutting conditions. However, a slower ground speed is recommended for improved grass discharge and reduced turf tear. 325EFJ/Odoc100499 Operating Procedures Go to www.lastec.com for latest changes in this manual. -
Page 26: Maintenance
Perform the appropriate maintenance procedures listed in your tractor manual. Every 25 Operating Hours Complete the 8 Hour Maintenance Checklist. Grease all wheel hubs. Maintenance 325EFJ/Odoc052400 Go to www.lastec.com for latest changes in this manual. -
Page 27: Every 50 Operating Hours
Annual As an annual maintenance program, LasTec recommends the installation of a com- plete K611 Model 325EFJ Articulator Rebuild Kit. Contact your LasTec dealer for more information about the K611 Kit. After installation of the complete K611 Model 325EFJ Articulator Rebuild Kit, com- plete the 8, 25, 50, &... -
Page 28: Model 325Efj Articulator Specifications
(8) 9” x 3” Pneumatic Tires - 50 PSI Deck EFJ1 Belt Goodyear Insta-Power 85890 Deck EFJ2 Belt (Deck Drive) Goodyear Insta-Power 85360 Deck EFJ3 Belt Goodyear Insta-Power 85870 Maintenance 325EFJ/Odoc052400 Go to www.lastec.com for latest changes in this manual. - Page 29 Go to www.lastec.com for latest changes in this manual.
- Page 30 LASTEC This Page Has Been Intentionally Left Blank Go to www.lastec.com for latest changes in this manual.
