Summary of Contents for Cadillac 2011 STS

Page 107: Table Of Contents
..........3-3 Keyless Access System .
Page 108 ..... . . 3-41 Ultrasonic Rear Parking Assist (URPA) ..3-41 Side Blind Zone Alert (SBZA) ....3-44 Lane Departure Warning (LDW) .
Page 109 Leaving children in a vehicle with the keyless access transmitter is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keyless access transmitter in the vehicle and they could be seriously injured or killed if caught in the path of a closing window.
Page 110: Keyless Access System
Your vehicle has a Keyless Access System with pushbutton start. See Ignition Positions on page 3 26 for information on starting the vehicle. In an emergency, contact Cadillac Roadside Service. See Roadside Service on page 8 8. See Radio Frequency Statement on page 8 20...
Page 111 If there is a decrease in the RKE operating range, try this: Check the distance. The transmitter may be too far from the vehicle. Stand closer during rainy or snowy weather. Check the location. Other vehicles or objects may be blocking the signal. Take a few steps to the left or right, hold the transmitter higher, and try again.
Page 112 Other conditions can affect the performance of the transmitter. See Keyless Access System on page 3 4. Press once to lock the doors. The light on the front doors comes on and the turn signals flash. is pressed twice, the horn will also sound. See Lights Flash at Lock and Horn Chirps at Lock under Vehicle Personalization on page 3 59 to change the feedback feature.
Page 113 Only keyless access transmitters programmed to this vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Each vehicle can have up to four transmitters programmed to it.
Page 114 7. A beep sounds once programming in complete. The DIC displays READY FOR 3 or 4, or MAX # FOBS LEARNED. 8. Remove the transmitter from the transmitter pocket and press twice on each newly programmed transmitter to complete the process. 9.
Page 115 7. The DIC reads WAIT 10 MINUTES and counts down to zero. 8. The DIC displays OFF/ACC TO LEARN again. 9. Press Acc. on the ignition switch. 10. Steps 7, 8 and 9 will be repeated two more times. 11. A beep sounds and the DIC reads READY FOR FOB 1.
Page 116: Remote Vehicle Start
1. Separate the transmitter with a flat, thin object inserted into the slot on the side of the transmitter. 2. Remove the old battery. Do not use a metal object. 3. Insert the new battery, positive side facing down. Replace with a CR2032 or equivalent battery. 4.
Page 117 3. If it is the first remote start since the vehicle has been driven, repeat these steps, while the engine is still running, to extend the engine running time by 10 minutes. Remote start can be extended one time. If the vehicle is left running it will automatically shut off after 10 minutes unless a time extension has been done.
Page 118 The remote start feature will not operate if any of the following occur: The check engine light is displayed. See Check Engine Light under Malfunction Indicator Lamp on page 4 62. The valet lockout switch is on. The keyless access transmitter is in the vehicle. The vehicle's hood is open.
Page 119: Power Door Locks
Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. Locking your doors can help prevent this from happening. There are several ways to lock and unlock your vehicle. From the outside: Pull the front door handle. If you have the keyless access transmitter, the vehicle recognizes the transmitter and automatically unlocks the door.
Page 120: Rear Door Security Locks
The vehicle was programmed so when the doors are closed, the ignition is on, and the shift lever is moved out of P (Park), all the doors will lock. The front doors can still be opened from the inside while the doors are locked.
Page 121: Trunk
The vehicle can be programmed to sound the horn three times and unlock the driver's door when all doors are closed and there is a keyless access transmitter inside the interior of the vehicle. When the driver's door is reopened, the key in reminder chime will sound continuously.
Page 122: Keyless Access System Operation
There are three ways to open the trunk lid. Press this button located on the driver's door. The vehicle must be in P (Park) or N (Neutral) and the valet mode turned off. To disable valet mode, see Valet Lockout Switch on page 3 24.
Page 123 To open the door: 1. Pull the rear seat armrest down. 2. If the door is locked, insert the key into the lock and turn it counterclockwise. 3. Press the button above the lock and lower the door. To open the trunk lid, pull the emergency trunk release handle located in the trunk on the other side of the door opening.
Page 124 Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 125: Power Windows
Leaving children in a vehicle with the keys is dangerous for many reasons. Children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function and they could be seriously injured or killed if caught in the path of a closing window.
Page 126 Any window can be lowered or raised all the way without holding the switch. Press the front of the window switch to the second position and release to activate the express-down feature. To stop the window, briefly pull up the switch. Lift the front of the switch briefly to activate the express up feature.
Page 127 If express override is activated, the window will not reverse automatically. You or others could be injured and the window could be damaged. Before you use express override, make sure that all people and obstructions are clear of the window path. In an emergency, the anti pinch feature can be overridden in a supervised mode.
Page 128: Theft-Deterrent System
This vehicle has theft-deterrent features, however, they do not make it impossible to steal. Your vehicle has a theft-deterrent alarm system. The security light is located on the instrument panel cluster. If the ignition is off and a door is open, the security light will flash, reminding you to arm the theft-deterrent system.
Page 129 If a door, hood, or the trunk is opened without the keyless access transmitter, the horn will sound for 30 seconds and the lamps will flash for two minutes. The vehicle cannot be started without a keyless access transmitter. The Theft-Deterrent system will not arm if : The key is used to turn the key cylinder to the lock position.
Page 130: Valet Lockout Switch
The valet lockout switch is located inside the glove box. Press to turn the lockout feature off and allow the trunk to be opened with either the keyless access transmitter or the trunk release button located on the driver's door. Press to turn the lockout feature on.
Page 131 If the vehicle does not start and the keyless access transmitter appears to be undamaged, try another keyless access transmitter. Or, place the transmitter in the transmitter pocket. See NO FOBS DETECTED under DIC Warnings and Messages on page 4 76 for additional information.
Page 132 The vehicle has an electronic keyless ignition with pushbutton start. To shift out of P (Park), the vehicle must be running or in ACCESSORY mode and the regular brake pedal must be applied. Press to start the engine with your foot on the brake pedal.
Page 133 If the engine is off, press this button to turn on the accessory mode. ACCESSORY ACTIVE will display on the Driver Information Center (DIC). Accessory mode allows use of the audio system and windshield wipers. Accessory mode must be used if the vehicle must be towed or in motion when the engine is not running.
Page 134 2. When the engine begins cranking, let go of the button and the engine cranks automatically until it starts. If the battery in the keyless access transmitter is weak, the DIC displays KEY FOB BATTERY LOW. You can still drive the vehicle. See Battery Replacement under Keyless Access System Operation on page 3 5 for more information.
Page 135: Engine Coolant Heater
Move the shift lever to P (Park) and press the Acc. button located on the instrument panel. If the shifter is not in P (Park), the engine shuts off and the vehicle goes into the Accessory Mode. The DIC displays SHIFT TO PARK.
Page 136 The length of time the heater should remain plugged in depends on several factors. Ask a dealer in the area where you will be parking the vehicle for the best advice on this. There are several different positions for the shift lever.
Page 137 Use this gear to back up. At low vehicle speeds, you can also use R (Reverse) to rock your vehicle back and forth to get out of snow, ice, or sand without damaging the transmission. See If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow on page 5 22 for additional information.
Page 138 Driver Shift Control (DSC) allows you shift an automatic transmission similar to a manual transmission. To use the DSC feature: 1. Move the shift lever to the right from D (Drive) into the DSC area. When in DSC mode, the sport symbol will appear in the Driver Information Center (DIC).
Page 139: Parking Brake
If shifting is prevented for any reason, the selected gear will flash multiple times, indicating that the transmission has not shifted gears. The transmission will allow you to shift to the gear selected and will automatically downshift when the vehicle comes to a stop. This will allow for more power during take-off and passing.
Page 140 It can be dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake firmly set. The vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 141 Torque lock is when the weight of the vehicle puts too much force on the parking pawl in the transmission. This happens when parking on a hill and shifting the transmission into P (Park) is not done properly and then it is difficult to shift out of P (Park).
Page 142: Engine Exhaust
Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. Exposure to CO can cause unconsciousness and even death. Exhaust may enter the vehicle if: The vehicle idles in areas with poor ventilation (parking garages, tunnels, deep snow that may block underbody airflow or tail pipes).
Page 143: Shifting Into Park
death. Never run the engine in an enclosed area that has no fresh air ventilation. For more information, see Engine Exhaust on page 3 36. It can be dangerous to get out of the vehicle if the automatic transmission shift lever is not fully in P (Park) with the parking brake firmly set.
Page 144: Compass
Press to turn the compass on or off. When the ignition and the compass feature are on, the mirror displays the compass heading after a few seconds. If after few seconds, the display does not show a compass heading (for example, N for North), there may be a strong magnetic field interfering with the compass.
Page 145: Outside Power Mirrors
3. Once the zone number displays, press repeatedly until the correct zone number displays. Stop pressing the button and the mirror returns to normal operation. If C appears in the compass window, the compass may need calibration. See Compass Calibration listed previously. Controls for the outside power mirrors are located on the driver door.
Page 146 This feature assists the driver by improving rear obstacle detection and is useful in viewing the curb when parallel parking. The passenger and/or driver mirror tilts to a preselected position when the vehicle is in R (Reverse). This feature lets the driver view the curb when parallel parking. If further adjustment is needed after the mirror is tilted, the mirror switch may be used.
Page 147: Ultrasonic Rear Parking Assist (Urpa)
For vehicles with the URPA system, it operates at speeds less than 3 mph (5 km/h), and assists the driver with parking and avoiding objects while in R (Reverse). The sensors on the rear bumper are used to detect the distance to an object up to 5 feet (1.5 m) behind the vehicle and at least 10 inches (25.4 cm) off the ground.
Page 148 URPA comes on automatically when the shift lever is moved into R (Reverse). The rear display briefly illuminates to indicate the system is working. URPA operates only at speeds less than 3 mph (5 km/h). If the vehicle is above this speed, the red light on the rear display will flash.
Page 149 If the URPA system will not activate due to a temporary condition a red light will be shown on the rear URPA display when the shift lever is moved into R (Reverse). This occurs under the following conditions: The ultrasonic sensors are not clean. Keep the vehicle's rear bumper free of mud, dirt, snow, ice and slush.
Page 150: Side Blind Zone Alert (Sbza)
The vehicle may have a Side Blind Zone Alert (SBZA) system. Read this entire section before using the system. SBZA is only a lane changing aid and does not replace driver vision. SBZA does not detect: Vehicles outside the side blind zones which may be rapidly approaching.
Page 151 The SBZA detection zones do not change if the vehicle is towing a trailer. So be extra careful when changing lanes while towing a trailer. When the vehicle is started, both outside mirror displays will briefly come on to indicate that the system is operating.
Page 152 SBZA does not operate when the left or right corners of the rear bumper are covered with mud, dirt, snow, ice, slush, or in heavy rainstorms. For cleaning instructions, see Washing Your Vehicle on page 6 109. If the DIC still displays the SIDE BLIND ZONE SYSTEM UNAVAILABLE message after cleaning the bumper, see your dealer.
Page 153: Lane Departure Warning (Ldw)
If the vehicle has the LDW system. Read this entire section before using the system. The Lane Departure Warning (LDW) system does not steer the vehicle and is only an aid to help you stay in your driving lane. The LDW system may not: Provide you with enough time to avoid a lane change collision.
Page 154 LDW uses a camera located between the inside rearview mirror and the windshield to detect the lane markings. To turn LDW on or off, press the CONFIG hard key located on the navigation radio, then press . See Configure Menu in the index of the Navigation System manual.
Page 155 message may appear in the DIC to indicate that LDW is not working properly. If this message remains on after continued driving, the system needs service. Take the vehicle to your dealer. See DIC Warnings and Messages on page 4 76 for more information. message may appear in the DIC if LDW does not activate due to a temporary condition.
Page 156 Read the instructions completely before attempting to program the transmitter. Because of the steps involved, it may be helpful to have another person available to assist you in programming the transmitter. Be sure to keep the original remote control transmitter for use in other vehicles, as well as, for future programming.
Page 157 2. Locate in the garage, the garage door opener receiver (motor-head unit). Locate the Learn or Smart button. It can usually be found where the hanging antenna wire is attached to the motor-head unit and may be a colored button. Press this button.
Page 158 For questions or help programming the Universal Home Remote System, call 1-866-572-2728 or go to learcar2u.com. Most garage door openers sold before 1996 are Fixed Code units. Programming a garage door opener involves time-sensitive actions, so read the entire procedure before starting.
Page 159 The hand held transmitter can have between eight to 12 dip switches depending on the brand of transmitter. The garage door opener receiver (motor head unit) could also have a row of dip switches that can be used when programming the Universal Home Remote.
Page 160 The panel of switches might not appear exactly as they do in the examples above, but they should be similar. The switch positions on your hand-held transmitter could be labeled, as follows: A switch in the up position could be labeled as Up, +, or On.
Page 161 4. The indicator lights will blink slowly. Enter each switch setting from Step 2 into your vehicle's Universal Home Remote. You will have two and one-half minutes to complete Step 4. Now press one button on the Universal Home Remote for each switch setting as follows: If you wrote Left, press the left button in the vehicle.
Page 162: Center Console Storage
Press and hold the appropriate button for at least half of a second. The indicator light will come on while the signal is being transmitted. Any of the three buttons can be reprogrammed by repeating the instructions. The programmed buttons should be erased when the vehicle is sold or the lease ends.
Page 163: Convenience Net
increased stopping distance which can cause a crash and injury. Make sure the floor mat does not interfere with the accelerator or brake pedal. Use the following guidelines for proper floor mat usage. The original equipment floor mats were designed for your vehicle.
Page 164 To open the power sunroof to the vent position from the closed position, press and hold the passenger's side sunroof switch forward. The rear of the sunroof panel will tilt upward to the full vent position. The sunshade must be opened manually. The express close feature will operate from the open or partially open position.
Page 165: Programmable Automatic Door Locks
The vehicle has personalization that allows you to program certain features to a preferred setting for up to two drivers. The back of the keyless access transmitters are labelled 1 or 2. Additional keyless access transmitters programmed to the vehicle, as 3 and/or 4, do not have a number on the back and are not capable of being personalized.
Page 166 3. Turn on the radio by pressing the power/ volume knob. 4. Press the CNFG radio button or the tune/select knob located on the right side of the radio to enter the radio's main menu. 5. Turn the tune/select knob and scroll to SETUP. 6.
Page 167 3. Press the tune/select knob to turn on the DRIVER GREETING feature. You will see a cursor on the screen. 4. Turn the tune/select knob until you reach the first letter you want; the letter will be highlighted. There is a complete alphabet with both upper and lower case letters and the numbers zero through nine.
Page 168 This feature sounds the horn three times when the driver's door is closed and there is a keyless access transmitter left inside of the vehicle. This will only occur when the vehicle is off. ON (default) To program the vehicle to a different mode: 1.
Page 169 The climate control system will engage when the vehicle is started using the remote start feature. It will be at the same climate control setting that was last used by the driver using that keyless entry transmitter. If this feature is active, the rear defogger will engage when the vehicle is started using the remote start feature.
Page 170 If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed seat, mirror, and steering column position when the start button on the ignition is pressed. OFF (default) To program the vehicle to a different mode: 1.
Page 171 If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed exit position for the steering column when the vehicle is off, the shift lever is in P (Park), and the driver's door is opened. OFF (default) To program the vehicle to a different mode: 1.
Page 172 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle.
Page 173 This feature turns on the exterior lamps when the keyless access transmitter is used to unlock the vehicle. The lamps will remain on for about 20 seconds unless a door is opened, the ignition is in ACCESSORY, on, or START, or the keyless access transmitter is used to lock the vehicle.
Page 174 This feature allows you to set the amount of time you want the exterior lamps to remain on after you exit the vehicle. 0:00 seconds (off) 0:05 seconds (default) 0:15 seconds 0:30 seconds 1:30 minutes 2:00 minutes 3:00 minutes 4:00 minutes 3-68 To determine the mode to which the vehicle is programmed or to program the vehicle to a...
Page 175 This feature allows the driver's door to automatically unlock when the ignition is turned off. OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu. 2.
Page 176 The feature allows the driver's door to automatically unlock when the transmission is shifted into P (Park). OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu.
Page 177 This feature automatically unlocks the appropriate front door when you approach the vehicle with the keyless access transmitter and pull the respective door handle. See Door Locks on page 3 12 for more information. OFF (default) To program the vehicle to a different mode: 1.
Page 178 This feature delays the locking of the vehicle's doors for eight seconds after a power door lock switch or the lock button on the keyless access transmitter is pressed. The eight second delay occurs after the last door is closed. If the keyless access transmitter is left inside of the vehicle, the doors will not lock.
Page 179 OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu. 2. Turn the tune/select knob until KEYLESS LOCK DELAY is highlighted. 3. Press the tune/select knob to switch back and forth between on and off.
Page 180 This feature allows you to adjust the volume level of the vehicle's warning chimes. The chime volume cannot be turned off, only adjusted. NORMAL (default) HIGH To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu.
Page 181 The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle by pressing the F6 (BACK) button, located on the radio, to return to the PERSONAL SETTINGS MENU.
Page 182 For vehicles with the base audio system, memory features are programmed and recalled through the radio from the DRIVER SELECTION and the DRIVER EXIT SETTINGS submenus. See Entering the Driver Selection Submenu and Entering the Driver Exit Settings Submenu later in this section for more information on recalling and programming the memory settings using the base audio system.
Page 183 The numbers on the back of each keyless access transmitter correspond to DRIVER 1 and DRIVER 2. If you would like to recall or store driver settings for the driver that does not correspond to the number on the back of the keyless access transmitter that you are using: 1.
Page 184: Exit Settings
To store driver settings: 1. Adjust your settings for the driver seat, the outside rearview mirrors, and the steering column to a comfortable driving position. 2. Enter the memory programming mode for your driver settings by following the instructions listed previously under Entering the Driver Selection Submenu.
Page 185 To recall exit settings: 1. Enter the memory programming mode for your exit settings by following the instructions listed previously under Entering the Driver Exit Settings Submenu. 2. From the DRIVER EXIT SETTINGS submenu, turn the tune/select knob to scroll to RECALL EXIT SETTINGS and press in the knob.
Page 186 3-80...
Page 187 ......4-3 Hazard Warning Flashers ..... . . 4-3 Horn .
Page 188 Engine Coolant Temperature Gauge ... 4-61 Tire Pressure Light ......4-62 Malfunction Indicator Lamp .
Page 189: Memory Seat, Mirrors And Steering Wheel
Press this button located on the console, near the shift lever, to make the front and rear turn signal lamps flash on and off. This warns others that you are having trouble. Press again to turn the flashers off. When the hazard warning flashers are on, the turn signals do not work.
Page 190 For vehicles with a heated steering wheel, the button for this feature is located on the steering wheel. Press to turn the heated steering wheel on or off. A light on the button displays when the feature is turned on. The steering wheel takes about three minutes to start heating.
Page 191 The lever returns to its starting position when it is released. If after signaling a turn or lane change the arrow flashes rapidly or does not come on, a signal bulb may be burned out. Have the bulbs replaced. If the bulb is not burned out, check the fuse.
Page 192 For vehicles with this feature, read the following section before using it. This vehicle has systems that operate on a radio frequency that comply with Part 15 of the Federal Communications Commission (FCC) rules and with Industry Canada Standards RSS 210/220/310. Operation is subject to the following two conditions: 1.
Page 193 The Forward Collision Alert (FCA) controls are located on the end of the multifunction lever. Turns the system off. Turns the system on. The Head-Up Display must be on and properly adjusted. If the HUD is not on, FCA will not be enabled and you will not be provided with FCA audible and visual warnings.
Page 194 The alert symbol will flash on the HUD and a warning beep will sound when driver action may be required. The driver warning is active when: You are approaching a vehicle too quickly. You are following a vehicle ahead much too closely.
Page 195 FCA may occasionally provide an unnecessary warning to guard rails, signs, and other stationary objects. This is normal operation, your vehicle does not need service. There are three messages that may appear on the Driver Information Center (DIC). They are CLEAN RADAR, RADAR CRUISE NOT READY and SERVICE RADAR CRUISE.
Page 196 The windshield wiper lever is on the right side of the steering column. Move the lever to select the wiper speed: Single wipe, move to release it. The lever will return to its original position. For several wipes, hold the lever in this position. Turns the windshield wipers off.
Page 197 The windshield washer button is located at the end of the windshield wiper lever on the right side of the steering column. Press and hold to spray windshield washer fluid on the windshield. The washer will spray until the button is released. The wipers will continue to clear the window for about six seconds after the button is released and then stop or return to the preset speed.
Page 198 With cruise control, a speed of about 40 km/h (25 mph) or more can be maintained without keeping your foot on the accelerator. Cruise control does not work at speeds below about 40 km/h (25 mph). If the brakes are applied, the cruise control shuts off. Cruise control can be dangerous where you cannot drive safely at a steady speed.
Page 199 Press to set the speed or to decrease the speed when cruise is already active. Press to disengage cruise control without erasing the set speed from memory. If the cruise button is on when not in use, it could get bumped and go into cruise when not desired.
Page 200 If the cruise control system is already activated, Press at the end of the lever until the desired speed is reached, then release it and the accelerator pedal. Move the cruise switch from to the desired speed is reached, then release it. To increase the vehicle speed in small amounts, move the switch briefly to done, the vehicle goes about 1.6 km/h (1 mph)
Page 201 When going downhill, you might have to brake to keep the vehicle speed down. When the brakes are applied the cruise control is disengaged. There are three ways to end cruise control. To disengage cruise control; step lightly on the brake pedal.
Page 202 The vehicle's braking during Adaptive Cruise Control is comparable to a person applying moderate pressure to the vehicle's brake pedal. To disengage Adaptive Cruise Control, apply the brake. If no vehicle is in your path, your vehicle will react like traditional cruise control. Adaptive Cruise Control will not apply hard braking or bring the vehicle to a complete stop.
Page 203 On slippery roads, fast changes in tire traction can cause needless wheel spinning, and you could lose control. Do not use cruise control on slippery roads. When weather limits visibility, such as when in fog, rain, or snow conditions, Adaptive Cruise Control performance is limited.
Page 204 If you operate Adaptive Cruise Control without your Head-up Display (HUD) properly adjusted, your Adaptive Cruise Control settings may not be visible. You could forget your settings and be startled by Adaptive Cruise Control response and even lose control. Keep your HUD on and properly adjusted when using Adaptive Cruise Control.
Page 205 This symbol appears on the Head-Up Display (HUD) to indicate that Adaptive Cruise Control is active. The number indicates the set speed. See Head-Up Display (HUD) on page 4 38 for more information. Make sure the set speed is visible on the HUD so you know the speed your vehicle will accelerate to if a vehicle is not detected in your path.
Page 206 To increase the set speed in small amounts, move the switch briefly to resume/increase. Each time this is done, the vehicle set speed increases by about 1.6 km/h (1 mph). Your vehicle will not reach the set speed until the system determines there is no vehicle in front of you.
Page 207 The range of selectable distances may not be appropriate for all drivers and driving conditions. If you prefer to travel at a following distance farther than Adaptive Cruise Control allows, disengage the system and drive manually. A graphic on the HUD indicates the selected following distance.
Page 208 The vehicle ahead symbol only appears on the HUD when a vehicle ahead is detected in your path. If this symbol does not appear, or disappears briefly, Adaptive Cruise Control will not respond to vehicles you may see ahead. 4-22 When the Adaptive Cruise Control radar is blocked by snow, ice, or dirt, it may not detect a vehicle ahead.
Page 209 Adaptive Cruise Control may not detect and react to stationary or slow moving vehicles or other objects ahead of you. You could crash into an object ahead of you. Do not use Adaptive Cruise Control when approaching stationary or slow moving vehicles or other objects. Adaptive Cruise Control may not detect and react to stationary or slow-moving vehicles or other objects ahead of you.
Page 210 To increase speed to pass a vehicle, use the accelerator pedal. While you are doing this, the system will not automatically apply the brakes. A PEDAL APPLIED ACC OVERRIDE message will appear on the HUD. See Head-Up Display (HUD) on page 4 38 for additional information.
Page 211 When following a vehicle and entering a curve, Adaptive Cruise Control could lose track of the vehicle in your lane and your vehicle could accelerate. When this happens, the vehicle ahead symbol will not appear on the HUD. Adaptive Cruise Control might detect a vehicle that is not in your lane and apply the brakes.
Page 212 Adaptive Cruise Control may lose track of the vehicle ahead and accelerate up to your set speed while entering or on highway exit ramps. You could be startled by this acceleration and even lose control of the vehicle. Disengage Adaptive Cruise Control before entering a highway exit ramp.
Page 213 The set speed memory is erased from memory by moving the Adaptive Cruise Control switch to the ignition is turned off. There are three messages that may appear on the DIC. They are SERVICE RADAR CRUISE, RADAR CRUISE NOT READY and CLEAN RADAR. These messages will appear to indicate a problem with the Adaptive Cruise Control.
Page 214 Turns the exterior lamps on and off automatically depending upon how much light is outside of the vehicle. The automatic lights may be disabled even if the control is in the AUTO position. To enable automatic lighting do any of the following: Turn the headlamp control from AUTO to off and release the switch.
Page 215 been turned on, it remains on each time the vehicle is started. Additionally, the IntelliBeam system must be enabled. To enable the System, turn the exterior lamp control to AUTO, with the turn signal/multifunction lever in its starting position. The High-Beam On Light appears on the instrument panel cluster when the high-beams are on.
Page 216 IntelliBeam may not turn off the high-beams if the system cannot detect other vehicle's lamps because of any of the following: The others vehicle's lamp(s) are missing, damaged, obstructed from view, or otherwise undetected. The other vehicle's lamp(s) are covered with dirt, snow and/or road spray.
Page 217 The light sensor is located on the inside of the vehicle at the back of the rearview mirror. Clean the light sensor window, periodically, using glass cleaner on a soft cloth. Gently wipe the sensor window. Do not spray glass cleaner directly on the surface of the sensor window.
Page 218 Daytime Running Lamps (DRL) can make it easier for others to see the front of your vehicle during the day. Fully functional daytime running lamps are required on all vehicles first sold in Canada. The DRL system comes on when the following conditions are met: It is still daylight and the ignition is on.
Page 219 The light sensor for the DRL is located on top of the instrument panel. If the sensor is covered, it will prevent it from sensing light, and the exterior lamps may come on when they are not needed. The fog lamp controls are located on the turn signal/multifunction lever.
Page 220 ® Twilight Sentinel can turn the lamps on and off for you. A light sensor on top of the instrument panel makes the Twilight Sentinel work, so be sure it is not covered. 4-34 With Twilight Sentinel the following will happen: When it is dark enough outside, the front turn signal lamps (DRL) will go off, and the headlamps and parking lamps will come on.
Page 221 Twilight Sentinel also provides exterior illumination as you leave the vehicle. If Twilight Sentinel has turned on the lamps when you turn off the ignition, the lamps will remain on until: The exterior lamp switch is moved from off to the parking lamp position.
Page 222 The entry lighting system turns on the reading and dome lamps and the backlighting to the exterior lamp control when a door is opened or if you press the remote keyless entry transmitter unlock button. If activated by the transmitter, the lighting will remain active for about 25 seconds.
Page 223 speed. For more battery saving information, see Battery Saver Active Message under DIC Warnings and Messages on page 4 76. The vehicle has Electric Power Management (EPM) that estimates the battery's temperature and state of charge. It then adjusts the voltage for best performance and extended life of the battery.
Page 224: Automatic Transmission Operation
If the HUD image is too bright, or too high in your field of view, it may take you more time to see things you need to see when it is dark outside. Be sure to keep the HUD image dim and placed low in your field of view.
Page 225 The HUD controls are located to the left of the steering wheel on the DIC control panel. Turn the brightness control knob fully counterclockwise to turn the HUD display off. Press to move the HUD display up or down on the windshield. HUD cannot be adjusted side to side.
Page 226 Check to see if: The HUD unit is covered. The brightness is adjusted properly. The HUD display is adjusted to the proper height. Ambient light in the direction the vehicle is facing is low. A fuse is blown. See Fuses and Circuit Breakers on page 6 115.
Page 227 The Speed Advisor can be set to show a speed alert when the vehicle speed exceeds the speed alert limit as set in the DIC menu. Depending on the level of the HUD on the vehicle, your HUD may work like either of the following: The HUD speedometer will turn red when the vehicle speed exceeds the speed alert limit.
Page 228 Accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. The vehicle has one outlet in front of the center console, one in the center console lid and there may be an additional outlet in the rear of the center console.
Page 229 The heating, cooling, and ventilation can be controlled for the vehicle with this system. A. Driver and Passenger F. Heated Seat Side Power Buttons G. Fan Control B. Ventilated Seat H. Defrost C. AUTO I. Rear Window Defogger D. Recirculation J.
Page 230 The display can be changed from English to metric units through the Driver Information Center (DIC). See DIC Operation and Displays on page 4 70. entire climate control system on or off. Turn the knob to increase or decrease the temperature inside the vehicle.
Page 231 This mode clears the windows of fog or moisture. Air is directed to the windshield and floor outlets, with some air directed to the side windows and outboard panel outlets. When this mode is selected, the system turns off recirculation and runs the air-conditioning compressor unless the outside temperature is at or below freezing.
Page 232 The rear window defogger uses a warming grid to remove fog or frost from the rear window. The defogger only works when the ignition is on or during remote start, if programmed. See Personal Settings Menu under Vehicle Personalization on page 3 59 for additional information.
Page 233 The solar sensor located on the instrument panel, near the windshield, monitors the solar heat. The interior temperature sensor located on the instrument panel to the right of the steering wheel, measures the temperature of the air inside the vehicle. The climate control system uses the information from these sensors to adjust the temperature, the fan speed and the air delivery, in order to maintain the selected...
Page 234 Use the lever located in the center of each outlet to change the direction of the airflow, either side-to-side or up and down. Use the thumbwheels to open or close the outlets to adjust the airflow. Turn the thumbwheel towards the vehicle door to open the outlets and allow the maximum amount of air to enter your vehicle.
Page 235 The vehicle has a rear climate control system. The base model includes air outlets in the rear of the center console for cooling and under-seat air outlets for heating. The temperature, amount of airflow, and the air delivery mode is controlled automatically by the front climate control system.
Page 236 Your vehicle may be equipped with a passenger compartment air filter. There are two types of filters available. There is a standard dust filter that traps small particles including pollen. There is, also, a dust/odor filter available that traps dust and pollen and uses a charcoal element to help reduce many offensive odors from entering your vehicle.
Page 237 4. Lift the inboard edge of the deflector to release the retention tab. 5. Lift and slide the water deflector toward the inboard side and remove it. 6. The top edge of the filter should be visible. Reach in and lift the filter out , pulling upward and toward the front of the vehicle.
Page 238 4-52...
Page 239 The speedometer shows the speed in both kilometers per hour (km/h) and miles per hour (mph). See DIC Operation and Displays on page 4 70 for more information. The odometer mileage can be checked without the vehicle running. The vehicle's odometer works together with the driver information center.
Page 240 For vehicles equipped with the passenger safety belt reminder light, several seconds after the engine is started, a chime sounds for several seconds to remind the front passenger to buckle their safety belt. The passenger safety belt light, located on the instrument panel, comes on and stays on for several seconds and then flashes for several more.
Page 241 If the airbag readiness light stays on after the vehicle is started or comes on while driving, it means the airbag system might not be working properly. The airbags in the vehicle might not inflate in a crash, or they could even inflate without a crash.
Page 242 Then, after several more seconds, the status indicator will light either ON or OFF, or either the on or off symbol to let you know the status of the right front passenger's frontal airbag. If the word ON or the on symbol is lit on the passenger airbag status indicator, it means that the right front passenger's frontal airbag is enabled (may inflate).
Page 243 If, after several seconds, both status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger sensing system. See your dealer for service. If the airbag readiness light in the instrument panel cluster ever comes on and stays on, it means that something may be wrong with the airbag system.
Page 244 The vehicle brake system consists of two hydraulic circuits. If one circuit is not working, the remaining circuit can still work to stop the vehicle. For normal braking performance, both circuits need to be working If the warning light comes on, there is a brake problem. Have the brake system inspected right away.
Page 245 For vehicles with the Antilock Brake System (ABS), this light comes on briefly when the engine is started. If it does not, have the vehicle serviced by your dealer. If the system is working normally the indicator light then goes off. If the ABS light stays on, turn the ignition off.
Page 246 The TCS warning light comes on briefly when the engine is started. If it does not, have the vehicle serviced by your dealer. If the Traction Control System (TCS) warning light comes on and stays on, there may be a problem with the TCS.
Page 247 The engine coolant temperature warning light comes on when the engine is very hot. This light also comes on briefly when the vehicle is started. If the light does not go out or comes on and stays on while driving, there may be a problem with the cooling system.
Page 248 For vehicles with a tire pressure monitoring system, this light comes on briefly when the engine is started. It provides information about tire pressures and the Tire Pressure Monitoring System. This indicates that one or more of the tires is significantly underinflated.
Page 249 This light should come on when the ignition is on, but the engine is not running, as a check to show it is working. If it does not, have the vehicle serviced by your dealer. If the check engine light comes on and stays on, while the engine is running, this indicates that there is an OBD II problem and service is required.
Page 250 If the light continues to flash, when it is safe to do so, stop the vehicle. Find a safe place to park the vehicle. Turn the vehicle off, wait at least 10 seconds, and restart the engine. If the light is still flashing, follow the previous steps and see your dealer for service as soon as possible.
Page 251 Some state/provincial and local governments may have programs to inspect the on-vehicle emission control equipment For the inspection, the emission system test equipment is connected to the vehicle s Data Link Connector (DLC). The DLC is under the instrument panel to the left of the steering wheel.
Page 252 For vehicles with an oil pressure light, if there is a problem with the oil, the light may stay on after the engine is started, or comes on while driving. This light indicates that oil is not going through the engine quickly enough to keep it lubricated.
Page 253 For information regarding this light and the vehicle's security system, see Theft-Deterrent System on page 3 22. The fog lamp light comes on when the fog lamps are in use. The light goes out when the fog lamps are turned off. See Fog Lamps on page 4 33 for more information.
Page 254 This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 4 5 for more information. The fuel gauge shows approximately how much fuel is in the fuel tank. It works only when the engine is on.
Page 255 The Driver Information Center (DIC) gives you the status of many of your vehicle's systems. The DIC is also used to display warning/status messages. All messages will appear in the DIC display located at the bottom of the instrument panel cluster, below the tachometer and speedometer.
Page 256 The Driver Information Center (DIC) has different modes which can be accessed by pressing the four DIC buttons located on the instrument panel, to the left of the steering wheel. If your vehicle does not have a Head-Up Display (HUD), these are the buttons for the DIC.
Page 257 If the vehicle has a HUD, these are the buttons for the DIC. Press the top or bottom of this button to scroll through the available vehicle information displays which include digital speed display, if your vehicle has this feature, fuel range, fuel economy, fuel used, average speed, timer, battery voltage, tire pressure, engine oil life, if your vehicle has this feature, and display units.
Page 258 The following display menu items can be displayed by pressing the information button. If the vehicle has this display, it shows the vehicle's speed digitally in either miles per hour (mph) or kilometers per hour (km/h). This display shows the approximate number of remaining miles (mi) or kilometers (km) you can drive without refilling the fuel tank.
Page 259 This display shows the average speed of the vehicle in miles per hour (mph) or kilometers per hour (km/h). This average is calculated based on the various vehicle speeds recorded since the last reset of this display. To reset AVG MPH, press the reset button. The display will return to zero.
Page 260 This display shows the current battery voltage. If the voltage is in the normal range, the value will display. For example, the display may read 13.2 BATTERY VOLTS. If the voltage is low, the display will have LOW after it. If the voltage is high, the display will have HIGH after it.
Page 261 This display allows you to select between English and metric units of measurement if your vehicle has the uplevel DIC. Press the reset button to switch between English and metric units. This display shows no information. This display shows a graphic that indicates the amount of boost the engine is receiving in either pounds per square inch (psi) or kilopascals (kPa).
Page 262 Messages are displayed on the DIC to notify the driver that the status of the vehicle has changed and that some action may be needed by the driver to correct the condition. Multiple messages may appear one after another. The text messages are the same for both the base audio and Navigation systems unless otherwise indicated.
Page 263 This symbol appears with this message. This message displays when a problem with the charging system has been detected. Have your vehicle serviced by your dealer. This message displays when the system detects that the battery voltage is dropping beyond a reasonable level.
Page 264 This symbol appears with this message. This message displays when the electrical system is charging less than 10 volts or the battery has been drained. If this message appears immediately after starting the engine, it is possible that the generator can still recharge the battery.
Page 265 This message displays when the pressure in one or more of the vehicle's tires Is low. It also gives the location of the tire. The low tire pressure warning light will also comes on. See Tire Pressure Light on page 4 62. If a tire pressure message appears on the DIC, stop as soon as you can.
Page 266 This symbol appears with this message. This message displays when the engine coolant temperature is too hot. Stop and allow the vehicle to idle until it cools down. See Engine Coolant Temperature Warning Light on page 4 61. See Overheated Engine Protection Operating Mode on page 6 32 for information on driving to a safe place in an emergency.
Page 267 This message displays when your vehicle is in an overheated engine operating mode. If this message appears, the vehicle has determined that continued operation at the existing engine speed may lead to engine overheating. The vehicle automatically limits engine RPMs to prevent engine overheating. You may notice the vehicle upshifting early or reduced speeds while this message is displayed.
Page 268 This symbol appears with this message. This message displays when the hood is not closed completely. Make sure that the hood is closed completely. See Hood Release on page 6 12. This message displays when the outside temperature is cold enough to create icy road conditions. Adjust your driving accordingly.
Page 269 This message displays if the vehicle does not detect the presence of a keyless access transmitter when you have attempted to start the vehicle or a vehicle door has just closed. The following conditions may cause this message to appear: Driver-added equipment plugged into the accessory power outlet on the center console is causing interference.
Page 270 This message displays when the keyless access transmitter is not detected inside the vehicle while you are trying to turn the ignition off. Your vehicle may be near a strong radio antenna signal causing the keyless access system to be jammed. The vehicle remains in ACCESSORY until OFF or START has been pressed or 10 minutes has expired.
Page 271 This message displays when you need to press down on the brake pedal while pressing the start button on the electronic keyless ignition when trying to start your vehicle. See Starting the Engine on page 3 27 for more information. This message displays when the Adaptive Cruise Control system is not activating due to a temporary condition.
Page 272 This message displays if there is a problem with the airbag system. Have your vehicle serviced by your dealer immediately. See Airbag Readiness Light on page 4 54 for more information. This message displays when a problem with the panic brake assist system has been detected.
Page 273 For vehicles with the Active Steering with Enhanced StabiliTrak option, in some cases when the SERVICE STABILITY SYS message is displayed, a larger degree of steering wheel input at low vehicle speeds and a smaller degree of steering wheel input at higher vehicle speeds may be required.
Page 274 This message displays when the suspension system is not operating properly. Have your vehicle serviced by your dealer. If your All-Wheel Drive (AWD) vehicle has the Active Steering with Enhanced StabiliTrak option and the suspension system needs service, the Enhanced StabiliTrak system may be operating in the Stability Secure Mode and the STABILITY SECURE MODE message will display.
Page 275 If your vehicle has the Side Blind Zone Alert (SBZA) system, this message displays when the SBZA system has been turned off. See Side Blind Zone Alert (SBZA) on page 3 44 and DIC Operation and Displays on page 4 70 for more information. If your vehicle has the Side Blind Zone Alert (SBZA) system, this message displays when the SBZA system is disabled because the sensor is blocked and cannot...
Page 276 This message displays any time the StabiliTrak system or Enhanced StabiliTrak system is actively assisting with directional control of the vehicle. Slippery road conditions may exist when this message is displayed, so adjust your driving accordingly. This message may stay on for a few seconds after StabiliTrak stops assisting with directional control of the vehicle.
Page 277 If your All-Wheel Drive (AWD) vehicle has the Active Steering with Enhanced StabiliTrak option, this message displays when the Stability Touring Mode is re-activated by using the traction control button after: Driving in the Stability Competitive Mode. The stability control system is turned off by the driver.
Page 278 This message displays when the transmission fluid in your vehicle is too hot. Stop the vehicle and allow it to idle until the transmission cools down or until this message is removed. 4-92 This symbol appears with this message. This message displays when the trunk is not closed completely.
Page 279 Here are more messages that you can receive on your Driver Information Center (DIC). To acknowledge a message and read another message that may have come on at the same time, press the reset button. ACCESSORY ACTIVE See Ignition Positions on page 3 26. KNOWN FOB See Matching Transmitter(s) to Your Vehicle under Keyless Access System Operation on...
Page 280 Determine which radio the vehicle has and read the following pages to become familiar with its features. Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others. Do not give extended attention to entertainment tasks while driving.
Page 281 To adjust the time: 1. Press ,located on the radio, to enter the main menu. 2. Turn until SET CLOCK displays. 3. Press to select SET CLOCK. 4. Turn to adjust the time. 5. Press to update the time and VEHICLE TIME UPDATED displays.
Page 282 The audio system has RDS features that are available for use only on FM stations that broadcast RDS information. With RDS: Stations can be selected based on programming Stations with traffic announcements can be selected Announcements concerning local and national emergencies can be received.
Page 283 To scan preset stations: 1. Press and hold for more than two seconds until a beep sounds and PSCAN displays. The radio goes to the first preset station, plays for five seconds, then goes to the next preset station. 2. Press and release to stop scanning.
Page 284 Up to 30 stations (six FM1, six FM2, six AM, six XM1 and six XM2), can be programmed on the six numbered pushbuttons. To program preset stations: 1. Tune to a station and select the equalization, DSP, or PTY (program type) setting if desired. 2.
Page 285 To adjust the bass, midrange, and treble: 1. Press to enter the main menu. 2. Turn until BASS-MID-TREBLE displays. 3. Press to enter the tone settings. 4. Press to scroll through the settings. 5. Turn to increase or to decrease the bass, midrange, or treble.
Page 286 To adjust the balance or fade: 1. Press to enter the main menu. 2. Turn until BALANCE FADER displays. 3. Press to enter the settings. 4. Press to scroll to BALANCE or FADER. 5. Turn to adjust the BALANCE to the right or the left speakers and the FADER to the front or the rear speakers.
Page 287 Displays if the current RDS station has a message. The message can display the artist, song title, call in phone numbers, etc. If the entire message does not display, parts of the message appear every three seconds until the message is completed. MSG disappears from the display once the completed message has displayed.
Page 288 PTY lets the radio search for stations with specific types of music. When this feature is turned on, the PTYs display above the pushbuttons in place of the programmed preset stations. Not all stations support PTYs and the radio may not go to all of the stations with that music type when pressing the pushbutton.
Page 289 Displays when the THEFTLOCK system has been activated. Take the vehicle to your dealer for service. XM is a satellite radio service that is based in the 48 contiguous United States and 10 Canadian provinces. XM Satellite Radio has a wide variety of programming and commercial-free music, coast-to-coast, and in digital-quality sound.
Page 290 Press to listen to the tracks in a random, rather than sequential order. RANDOM displays. Press again to turn off random play. RANDOM disappears from the display. Press to hear a track over again. REPEAT displays. Press again to turn off repeat play. REPEAT disappears from the display.
Page 291 If the radio is on, the lased CD loaded begins to play automatically. CD displays and the number of the CD and the track number displays. Press to go to the previous CD. Press to go to the next CD. Press to go to the previous track.
Page 292 Radios with the MP3 feature are capable of playing an MP3 CD-R disc. For more information on how to play an MP3 CD-R disc, see Using an MP3 on page 4 108 later in this section. The sound quality of the CD player can be reduced because of: The CD R quality.
Page 293: Display Keys
The air is very humid. If so, wait about an hour and try again. The format of the CD might not be compatible. See Using an MP3 on page 4 108 later in this section. A problem may have occurred while burning the CD.
Page 294 The MP3 player will only play CD-R discs. It can read and play a maximum of: 50 folders. 11 folders in depth 50 playlists 10 sessions 255 files All folders, playlists, sessions and files over the maximum are ignored. When recording an MP3 disc, make sure that: Playlists use an .m3u or .wpl extension.
Page 295 CD's that do not have playlists play the tracks in the following order: 1. The first file in the root directory plays. 2. After all files from the root directory have played, files in the folders play. 3. After playing the last file from the last folder, play restarts with the first file in the root directory.
Page 296 Press to go to the first track in the previous folder. Press and hold F1 to reverse quickly within a track. Release to resume playback. REV and the elapsed time of the track displays. Pressing F1 while in folder random mode goes to the previous folder and plays the tracks in that folder in random order.
Page 297 Single tracks or folders can be repeated. To repeat the current track, press and release F4 RPT until RPT TRCK displays. To repeat the tracks in the current folder, press and release F4 RPT until RPT FLDR displays. To turn repeat off, press and release F4 RPT until NORMAL displays.
Page 298 or any others, can be blocked at a customer's request, by calling 1-800-929-2100 in the U.S. and 1-877-438-9677 in Canada. The encryption code in the receiver is being updated, and no action is required. This process should take no longer than 30 seconds. The system is functioning correctly, but the vehicle is in a location that is blocking the XM signal.
Page 299 If this message does not clear within a short period of time, the receiver or antenna could have a fault. Consult with your dealer. If this message does not clear within a short period of time, the receiver could have a fault.
Page 300 Use the buttons located on the steering wheel to operate the Bluetooth system. See Audio Steering Wheel Controls on page 4 124 for more information. Press to answer incoming calls, to confirm system information, and to start voice recognition. A Bluetooth cell phone must be paired to the Bluetooth system and then connected to the vehicle before it can be used.
Page 301 The system can list all cell phones paired to it. If a paired cell phone is also connected to the vehicle, the system responds with is connected after that phone name. 1. Press and hold for two seconds. 2. Say Bluetooth. 3.
Page 302 The system can store up to 30 phone numbers as name tags in the Hands Free Directory that is shared between the Bluetooth and OnStar systems. The following commands are used to delete and store phone numbers. This command will store a phone number, or a group of numbers as a name tag.
Page 303 To delete all name tags: 1. Press and hold for two seconds. 2. Say Delete all name tags. The list command will list all stored numbers and name tags. 1. Press and hold for two seconds. 2. Say Directory. 3. Say Hands Free Calling. 4.
Page 304 1. Press and hold for two seconds. 2. After the tone, say Re dial. Once connected, the person called will be heard through the audio speakers. When an incoming call is received, the audio system mutes and a ring tone is heard in the vehicle. Press and begin speaking to answer the call.
Page 305 Audio can be transferred between the Bluetooth system and the cell phone. The cell phone must be paired and connected with the Bluetooth system before a call can be transferred. The connection process can take up to two minutes after the ignition is turned to ON/RUN.
Page 306 1. Press 2. Say Dial. 3. Say the number or name tag to send. Unless information is deleted out of the in vehicle Bluetooth system, it will be retained indefinitely. This includes all saved name tags in the phone book and phone pairing information.
Page 307 SEEK LOCAL/DISTANT SET CLOCK SET DATE INFO (Information) LANG LANGUAGE SETUP the the bass, midrange and treble features of the audio system to be adjusted. See Setting the Tone (Bass/ Treble) under Radio(s) on page 4 95 for more information. This item allows the the balance and fader features of the audio system to be adjusted.
Page 308 This item allows the RDS radio station messages broadcast by a radio station to be viewed. See MSG (Message) under Radio(s) on page 4 95 for more information. This item allows the audio system to seek only local radio stations with the strongest signal or to seek all radio stations with a strong signal in a large area.
Page 309 The following submenus are available when this item is selected: PERSONAL SETTINGS MENU DRIVER SELECTION DRIVER EXIT SETTINGS CONFIGURE DISPLAY KEYS The following choices are available for programming. This item turns the entire list of personalization features on or off, and allows a preferred setting for up to two people to be programmed.
Page 310 The vehicle has audio steering wheel controls and they could differ depending on the vehicle s options. 4-124 Some audio controls can be adjusted at the steering wheel. Press to go to the next or previous radio station with a strong signal in the selected band while listening to the radio.
Page 311 silence the vehicle speakers only. Press and release again to turn the sound on. For vehicles with a navigation system, press and hold for two seconds to initiate speech recognition. See Voice Recognition in the Navigation System manual for more information. For vehicles with a navigation system and ®...
Page 312 XM Satellite Radio Service gives digital radio reception from coast-to-coast in the 48 contiguous United States, and in Canada. Just as with FM, tall buildings or hills can interfere with satellite radio signals, causing the sound to fade in and out. In addition, traveling or standing under heavy foliage, bridges, garages, or tunnels may cause loss of the XM signal for a period of time.
Page 313 Defensive Driving ....... 5-2 Drunk Driving ........5-2 Control of a Vehicle .
Page 314 Defensive driving means always expect the unexpected. The first step in driving defensively is to wear your safety belt See Safety Belts: They Are for Everyone on page 2 14. Assume that other road users (pedestrians, bicyclists, and other drivers) are going to be careless and make mistakes.
Page 315 Police records show that almost 40 percent of all motor vehicle-related deaths involve alcohol. In most cases, these deaths are the result of someone who was drinking and driving. In recent years, more than 17,000 annual motor vehicle-related deaths have been associated with the use of alcohol, with about 250,000 people injured.
Page 316 See Brake System Warning Light on page 4 58. Braking action involves perception time and reaction time. Deciding to push the brake pedal is perception time. Actually doing it is reaction time. Average reaction time is about three fourths of a second.
Page 317 This vehicle has the Antilock Brake System (ABS), an advanced electronic braking system that helps prevent a braking skid. When the engine is started and the vehicle begins to drive away, ABS checks itself. A momentary motor or clicking noise might be heard while this test is going on, and it might even be noticed that the brake pedal moves a little.
Page 318 ABS allows the driver to steer and brake at the same time. In many emergencies, steering can help more than even the very best braking. This vehicle has a Brake Assist feature designed to assist the driver in stopping or decreasing vehicle speed in emergency driving conditions.
Page 319 StabiliTrak comes on automatically whenever the vehicle is started. To help assist with directional control of the vehicle, always leave the system on. StabiliTrak can be turned off, however, by using the Traction Control System (TCS)/StabiliTrak button. See Traction Control System (TCS) on page 5 9. If cruise control is being used when StabiliTrak activates, it will automatically disengage.
Page 320 To assist with directional control of the vehicle, always leave the system on. Stability control can be turned off however, by using the TC button. See Traction Control System (TCS) on page 5 9. The STABILITY SYS OFF message will be displayed on the DIC. See DIC Warnings and Messages on page 4 76.
Page 321 When the vehicle is started, Stability control comes on automatically in the Stability Touring Mode. To change from Stability Touring Mode to Stability Off Mode, press and hold the TC button until the STABILITY SYS OFF message is displayed on the DIC.
Page 322 TCS automatically comes on whenever the vehicle is started. To limit wheel spin, especially in slippery road conditions, the system should always be left on, but TCS can be turned off if needed. When TCS is turned off on a vehicle with AWD, the system may still be working.
Page 323 Vehicles with a limited-slip rear axle can give more traction on snow, mud, ice, sand or gravel. It works like a standard axle most of the time, but when traction is low, this feature allows the drive wheel with the most traction to move the vehicle.
Page 324 See DIC Warnings and Messages on page 4 76. The normal power steering system is still operational. You might notice that the center position of the steering wheel is changed and that more steering effort at low speeds and less steering effort at high speeds is required.
Page 325 There are times when steering can be more effective than braking. For example, you come over a hill and find a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 326 The vehicle's right wheels can drop off the edge of a road onto the shoulder while driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that the vehicle straddles the edge of the pavement.
Page 327 In a skid, a driver can lose control of the vehicle. Defensive drivers avoid most skids by taking reasonable care suited to existing conditions, and by not overdriving those conditions. But skids are always possible. The three types of skids correspond to the vehicle's three control systems.
Page 328 Night driving is more dangerous than day driving because some drivers are likely to be impaired alcohol or drugs, with night vision problems, or by fatigue. Night driving tips include: Drive defensively. Do not drink and drive. Reduce headlamp glare by adjusting the inside rearview mirror.
Page 329 Wet brakes can cause crashes. They might not work as well in a quick stop and could cause pulling to one side. You could lose control of the vehicle. After driving through a large puddle of water or a car/vehicle wash, lightly apply the brake pedal until the brakes work normally.
Page 330 To prepare your vehicle for a long trip, consider having it serviced by your dealer before departing. Things to check on your own include: Windshield Washer Fluid: Reservoir full? Windows clean inside and outside? Wiper Blades: In good shape? Fuel, Engine Oil, Other Fluids: All levels checked? Lamps: Do they all work and are lenses clean? Tires: Are treads good? Are tires inflated to recommended pressure?
Page 331 Driving on steep hills or through mountains is different than driving on flat or rolling terrain. Tips for driving in these conditions include: Keep the vehicle serviced and in good shape. Check all fluid levels and brakes, tires, cooling system, and transmission. Going down steep or long hills, shift to a lower gear.
Page 332 Drive carefully when there is snow or ice between the tires and the road, creating less traction or grip. Wet ice can occur at about 0°C (32°F) when freezing rain begins to fall, resulting in even less traction. Avoid driving on wet ice or in freezing rain until roads can be treated with salt or sand.
Page 333 Being stuck in snow can be in a serious situation. Stay with the vehicle unless there is help nearby. If possible, use the Roadside Service on page 8 8. To get help and keep everyone in the vehicle safe: Turn on the Hazard Warning Flashers on page 4 3.
Page 334 To save fuel, run the engine for only short periods as needed to warm the vehicle and then shut the engine off and close the window most of the way to save heat. Repeat this until help arrives but only when you feel really uncomfortable from the cold.
Page 335 Turn the steering wheel left and right to clear the area around the front wheels. Turn off any traction or stability system. Shift back and forth between R (Reverse) and a forward gear, spinning the wheels as little as possible. To prevent transmission wear, wait until the wheels stop spinning before shifting gears.
Page 336 A vehicle specific Tire and Loading Information label is attached to the vehicle's center pillar (B-pillar). With the driver's door open, you will find the label attached below the door lock 5-24 post (striker). The Tire and Loading Information label shows the number of occupant seating positions (A), and the maximum vehicle capacity weight (B) in kilograms and pounds.
Page 337 Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. Determine the combined weight of the driver and passengers that will be riding in your vehicle. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs.
Page 338 Vehicle Capacity Weight for Example 1 = Subtract Occupant Weight @ 150 lbs (68 kg) × 2 = Available Occupant and Cargo Weight = 5-26 1,000 lbs (453 kg) 300 lbs (136 kg) 700 lbs (317 kg) Vehicle Capacity 1,000 lbs Weight for (453 kg) Example 2 =...
Page 339 Vehicle Capacity Weight for Example 3 = Subtract Occupant Weight @ 200 lbs (91 kg) × 5 = Available Cargo Weight = Refer to your vehicle's Tire and Loading Information label for specific information about your vehicle's capacity weight and seating positions.
Page 340 The Certification label also shows the maximum weights for the front and rear axles, called the Gross Axle Weight Rating (GAWR). Never exceed the GVWR or the GAWR for either the front or rear axle. Do not load the vehicle any heavier than the Gross Vehicle Weight Rating (GVWR), or either the maximum front or rear Gross Axle Weight Rating (GAWR).
Page 341 When you carry something inside the vehicle, secure it whenever you can. Do not leave a seat folded down unless you need to. Consult your dealer or a professional towing service if the disabled vehicle must be towed. See Roadside Service on page 8 8.
Page 342 The vehicle was not designed to be towed with all four wheels on the ground. If the vehicle must be towed, use a dolly. See Dolly Towing later in this section for more information. 5-30 Rear wheel drive vehicles can be towed using a dolly. To tow the vehicle using a dolly, follow these steps: 1.
Page 343 3. Firmly set the parking brake. See Parking Brake on page 3 33. 4. Put the transmission in P (Park). 5. Secure the vehicle to the dolly following the manufacturer's instructions. 6. Use an adequate clamping device designed for towing to ensure that the front wheels are locked into the straight position.
Page 344 Trailering is different than just driving the vehicle by itself. Trailering means changes in handling, acceleration, braking, durability and fuel economy. Successful, safe trailering takes correct equipment, and it has to be used properly. The following information has many time-tested, important trailering tips and safety rules.
Page 345 Three important considerations have to do with weight: The weight of the trailer. The weight of the trailer tongue. The total weight on the vehicle's tires. How heavy can a trailer safely be? It should never weigh more than 1,000 lbs (450 kg). But even that can be too heavy.
Page 346 After loading the trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they are not, adjustments might be made by moving some items around in the trailer. Be sure the vehicle's tires are inflated to the upper limit for cold tires.
Page 347 Does the trailer have its own brakes? Be sure to read and follow the instructions for the trailer brakes so they are installed, adjusted and maintained properly. Because the vehicle has StabiliTrak into the vehicle's hydraulic brake system. If you do, both brake systems will not work well, or at all.
Page 348 Hold the bottom of the steering wheel with one hand. Then, to move the trailer to the left, move that hand to the left. To move the trailer to the right, move your hand to the right. Always back up slowly and, if possible, have someone guide you.
Page 349 Reduce speed and shift to a lower gear before starting down a long or steep downgrade. If the transmission is not shifted down, the brakes might have to be used so much that they would get hot and no longer work well. On a long uphill grade, shift down and reduce the vehicle's speed to around 45 mph (70 km/h) to reduce the possibility of the engine and the transmission...
Page 350 1. Apply and hold the brake pedal while you: Start the engine Shift into a gear Release the parking brake 2. Let up on the brake pedal. 3. Drive slowly until the trailer is clear of the chocks. 4. Stop and have someone pick up and store the chocks.
Page 351: Overheated Engine Protection
..........6-4 Accessories and Modifications .
Page 352 Tire Pressure Monitor System ....6-60 Tire Pressure Monitor Operation ....6-62 Tire Inspection and Rotation .
Page 353 ......6-114 Vehicle Identification Number (VIN) ... 6-114 Service Parts Identification Label .
Page 354 For service and parts needs, visit your dealer. You will receive genuine GM parts and GM-trained and supported service people. Genuine GM parts have one of these marks: When non dealer accessories are added to the vehicle, they can affect vehicle performance and safety, including such things as airbags, braking, stability, ride and handling, emissions systems, aerodynamics, durability, and electronic systems like antilock brakes,...
Page 355 Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems, many fluids, and some component wear by-products contain and/or emit these chemicals.
Page 356 This vehicle has an airbag system. Before attempting to do your own service work, see Keep a record with all parts receipts and list the mileage and the date of any service work performed. See Things added to the outside of the vehicle can affect the airflow around it.
Page 357 At a minimum, gasoline should meet ASTM specification D 4814 in the United States or CAN/CGSB 3.5 or 3.511 in Canada. Some gasolines contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT). We recommend against the use of gasolines containing MMT.
Page 358 Gasolines containing oxygenates, such as ethers and ethanol, and reformulated gasolines might be available in your area. We recommend that you use these gasolines, if they comply with the specifications described earlier. However, E85 (85% ethanol) and other fuels containing more than 10% ethanol must not be used in vehicles that were not designed for those fuels.
Page 359 Fuel vapor burns violently and a fuel fire can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the fuel pump island. Turn off the engine when refueling. Do not smoke near fuel or when refueling the vehicle.
Page 360 While refueling, hang the tethered fuel cap from the hook on the fuel door. Fuel can spray out on you if you open the fuel cap too quickly. If you spill fuel and then something ignites it, you could be badly burned. This spray can happen if the tank is nearly full, and is more likely in hot weather.
Page 361 If a fire starts while you are refueling, do not remove the nozzle. Shut off the flow of fuel by shutting off the pump or by notifying the station attendant. Leave the area immediately. Never fill a portable fuel container while it is in the vehicle.
Page 362 An electric fan under the hood can start up and injure you even when the engine is not running. Keep hands, clothing, and tools away from any underhood electric fan. Things that burn can get on hot engine parts and start a fire.
Page 363 2. Then go to the front of the vehicle and find the secondary hood release lever. The lever is located under the front edge of the grille near the center. Push the release lever up and raise the hood. Before closing the hood, be sure all the filler caps are on properly.
Page 364 6-14...
Page 365 After you have removed the sight shields (if equipped): A. Underhood Fuse Block. See B. Remote Negative (-) Terminal. See C. Remote Positive (+) Terminal. See D. Battery. See E. Passenger Compartment Air Filter. See F. Power Steering Fluid Reservoir. See G.
Page 366 To ensure proper engine performance and long life, careful attention must be paid to engine oil. Following these simple, but important steps will help protect your investment: Always use engine oil approved to the proper specification and of the proper viscosity grade. See Selecting the Right Engine Oil.
Page 367 If the oil is below the cross-hatched area at the tip of the dipstick, add one liter/quart of the recommended oil and then recheck the level. See Selecting the Right Engine Oil for an explanation of what kind of oil to use. For engine oil crankcase capacity, see the location of the engine oil fill cap.
Page 368 Selecting the right engine oil depends on both the proper oil specification and viscosity grade: Use and ask for engine oils with the dexos certification mark. Oils meeting the requirements of your vehicle should have the dexos the container. This certification mark indicates that the oil has been approved to the dexos Your vehicle was filled at the factory with dexos approved engine oil.
Page 369 SAE 5W-30 is the best viscosity grade for the vehicle. Do not use other viscosity oils such as SAE 10W 30, 10W 40, or 20W-50. Cold Temperature Operation: In an area of extreme cold, where the temperature falls below 29°C ( 20°F), an SAE 0W-30 oil should be used.
Page 370 Used engine oil contains certain elements that can be unhealthy for your skin and could even cause cancer. Do not let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 371 Reset the system whenever the engine oil is changed so that the system can calculate the next engine oil change. To reset the system: 1. Press the up or down arrow to scroll the DIC to show OIL LIFE. 2. Once the XXX% ENGINE OIL LIFE menu item is highlighted, press and hold the RESET button until the percentage shows 100%.
Page 372 Inspect the air cleaner/filter at the scheduled maintenance intervals and replace it at the first oil change after each 80 000 km (50,000 mile) interval. See information. If you are driving in dusty/dirty conditions, inspect the filter at each engine oil change. To inspect the air cleaner/filter remove the filter from the vehicle and lightly shake the filter to release loose dust and dirt.
Page 373 It is not necessary to check the transmission fluid level. A transmission fluid leak is the only reason for fluid loss. If a leak occurs, take the vehicle to the dealer service department and have it repaired as soon as possible.
Page 374 The cooling system allows the engine to maintain the correct working temperature. A. Electric Engine Cooling Fan(s) (Out of view) B. Mechanical Engine Cooling Fan (If equipped) (Out of view) C. Coolant Surge Tank and Pressure Cap 6-24 An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury.
Page 375 Heater and radiator hoses, and other engine parts, can be very hot. Do not touch them. If you do, you can be burned. Do not run the engine if there is a leak. If you run the engine, it could lose all coolant. That could cause an engine fire, and you could be burned.
Page 376 Adding only plain water or some other liquid to the cooling system can be dangerous. Plain water and other liquids, can boil before the proper coolant mixture will. The vehicle's coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.
Page 377 The vehicle must be on a level surface when checking the coolant level. The coolant surge tank and pressure cap are located on the driver's side of the vehicle, toward the rear of the engine compartment. See for more information on location.
Page 378 You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Do not spill coolant on a hot engine. Steam and scalding liquids from a hot cooling system can blow out and burn you badly.
Page 379 2. Then keep turning the pressure cap slowly, and 3. Fill the coolant surge tank with the proper ® remove it. DEX-COOL coolant mixture, to slightly above the FULL COLD/FROID line on the side of the coolant surge tank. 6-29...
Page 380 4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose getting hot. The upper radiator hose is the largest of the hoses which comes out of the radiator, on the passenger side of the vehicle.
Page 381 Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Turn it off and get everyone away from the vehicle until it cools down. Wait until there is no sign of steam or coolant before you open the hood.
Page 382 If the engine coolant temperature gauge is no longer in the overheat zone or an overheat warning no longer displays, the vehicle can be driven. Continue to drive the vehicle slow for about 10 minutes. Keep a safe vehicle distance from the car in front of you. If the warning does not come back on, continue to drive normally.
Page 383 for reservoir location. It is not necessary to regularly check power steering fluid unless you suspect there is a leak in the system or you hear an unusual noise. A fluid loss in this system could indicate a problem. Have the system inspected and repaired.
Page 384 When you need windshield washer fluid, be sure to read the manufacturer's instructions before use. If you will be operating your vehicle in an area where the temperature may fall below freezing, use a fluid that has sufficient protection against freezing. The CHECK WASHER FLUID message will appear on the Driver Information Center (DIC) when the fluid level is low.
Page 385 The brake master cylinder reservoir is filled with DOT 3 brake fluid. See reservoir location and access. There are only two reasons why the brake fluid level in the reservoir might go down: The brake fluid level goes down because of normal brake lining wear.
Page 386 DOT 3 brake fluid is recommended. DOT 4 brake fluid is also compatible with the vehicle's brake system parts. However, if DOT 4 fluid is used, it is recommended that the brake hydraulic system be flushed and refilled with new DOT 4 fluid at a regular maintenance service every two years.
Page 387 The brake wear warning sound means that soon the brakes will not work well. That could lead to a crash. When the brake wear warning sound is heard, have the vehicle serviced. Some driving conditions or climates can cause a brake squeal when the brakes are first applied or lightly applied.
Page 388 Refer to the replacement number on the original battery label when a new battery is needed. See location. Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling.
Page 389 1. Check the other vehicle. It must have a 12-volt battery with a negative ground system. 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles are not touching each other. If they are, it could cause a ground connection you do not want.
Page 390 Your vehicle has a remote negative ( ) ground location, as shown in the illustration. It is located on the passenger side front shock tower. See You should always use this remote ground location, instead of the terminal on the battery. 6-40 An electric fan can start up even when the engine is not running and can injure you.
Page 391 Using an open flame near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water. You do not need to add water to the battery installed in your new vehicle.
Page 392 6. Connect the red positive (+) cable to the positive (+) terminal of the dead battery. Use a remote positive (+) terminal if the vehicle has one. 7. Do not let the other end touch metal. Connect it to the positive (+) terminal of the good battery. Use a remote positive (+) terminal if the vehicle has one.
Page 393 A. Heavy, Unpainted Metal Engine Part or Remote Negative ( ) Terminal B. Good Battery or Remote Positive (+) and Remote Negative ( ) Terminals C. Dead Battery or Remote Positive (+) Terminal To disconnect the jumper cables from both vehicles, do the following: 1.
Page 394 A. Drain Plug B. Fill Plug To get an accurate reading, the vehicle should be on a level surface. 6-44 If the level is below the bottom of the filler plug hole, located on the transfer case, you'll need to add some lubricant.
Page 395 To get an accurate reading, the vehicle should be on a level surface. If the level is below the bottom of the filler plug hole, located on the rear axle, you'll need to add some lubricant. Add enough lubricant to raise the level to the bottom of the filler plug hole.
Page 396 A. Drain Plug B. Filler Plug To get an accurate reading, the vehicle should be on a level surface. If the level is below the bottom of the filler plug hole, located on the front axle, you may need to add some lubricant.
Page 397 For the proper type of replacement bulbs, see For any bulb changing procedure not listed in this section, contact your dealer. The low beam high intensity discharge lighting system operates at a very high voltage. If you try to service any of the system components, you could be seriously injured.
Page 398 To replace a back-up lamp bulb: 1. Open the trunk. See 2. Pull out the push pins holding down the top portion of the cloth cover. 3. Fold the cover down slightly and locate the lamp assembly. 6-48 4. Turn the socket counterclockwise and pull it straight out to remove it from the lamp assembly.
Page 399 Windshield wiper blades should be inspected for wear or cracking. See It's a good idea to clean or replace the wiper blade assembly on a regular basis or when worn. For proper windshield wiper blade length and type, see To replace the wiper blade assembly, do the following: 1.
Page 400 Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your vehicle Warranty booklet for details. For additional information refer to the tire manufacturer. Poorly maintained and improperly used tires are dangerous.
Page 401 If your vehicle has 255/45ZR18 size tires, they are classified as low profile performance tires. These tires are designed for very responsive driving on wet or dry pavement. You may also notice more road noise with low profile performance tires and that they tend to wear faster.
Page 402 Useful information about a tire is molded into its sidewall. The examples below show a typical passenger vehicle tire and a compact spare tire sidewall. 6-52 The tire size is a combination of letters and numbers used to define a particular tire's width, height, aspect ratio, construction type, and service description.
Page 403 The type of cord and number of plies in the sidewall and under the tread. manufacturers are required to grade tires based on three performance factors: treadwear, traction, and temperature resistance. For more information Maximum load that can be carried and the maximum pressure needed to support that load.
Page 404 The type of cord and number of plies in the sidewall and under the tread. and numbers following the DOT (Department of Transportation) code is the Tire Identification Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured.
Page 405 The three digit number indicates the tire section width in millimeters from sidewall to sidewall. A two digit number that indicates the tire height to width measurements. For example, if the tire size aspect ratio is 60, as shown in item C of the illustration, it would mean that the tire's sidewall is 60 percent as high as it is wide.
Page 406 The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has built up heat from driving. See The weight of a motor vehicle with standard and optional equipment including the maximum capacity of fuel, oil, and coolant, but without passengers and cargo.
Page 407 Designated seating positions. The side of an asymmetrical tire that has a particular side that faces outward when mounted on a vehicle. The side of the tire that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same moldings on the other sidewall of the tire.
Page 408 individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. A label permanently attached to a vehicle showing the vehicle's capacity weight and the original equipment tire size and recommended inflation pressure. See Tire and Loading Information Label under Tires need the correct amount of air pressure to operate effectively.
Page 409 Check your tires once a month or more. Do not forget to check the compact spare tire, if your vehicle has one. The compact spare should be at 60 psi (420 kPa). For additional information regarding the compact spare tire, see Use a good quality pocket-type gauge to check tire pressure.
Page 410 Driving at high speeds, 160 km/h (100 mph) or higher, puts an additional strain on tires. Sustained high-speed driving causes excessive heat build up and can cause sudden tire failure. You could have a crash and you or others could be killed.
Page 411 Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly under inflated tire causes the tire to overheat and can lead to tire failure. Under inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle's handling and stopping ability.
Page 412 This vehicle may have a Tire Pressure Monitor System (TPMS). The TPMS is designed to warn the driver when a low tire pressure condition exists. TPMS sensors are mounted onto each tire and wheel assembly, excluding the spare tire and wheel assembly, if the vehicle has one.
Page 413 Factory-installed Tire Inflator Kits use a GM approved liquid tire sealant. Using non-approved tire sealants could damage the TPMS sensors. See for information regarding the inflator kit materials and instructions. The TPMS will not function properly if one or more of the TPMS sensors are missing or inoperable.
Page 414 Each TPMS sensor has a unique identification code. Any time you replace one or more of the TPMS sensors or rotate your vehicle's tires, the identification codes will need to be matched to the new tire/wheel position. The sensors are matched to the tire/wheel positions in the following order: driver side front tire, passenger side front tire, passenger side rear tire, and driver side rear tire using a TPMS diagnostic tool.
Page 415 10. After hearing the confirming single horn chirp for the driver side rear tire, a double horn chirp will sound to signal the tire matching mode is no longer active. Press the push button ignition switch to Acc. 11. Set all four tires to the recommended air pressure level as indicated on the tire and loading information label.
Page 416 When rotating P235/50R17 size tires or 255/45ZR18 size tires, always use the correct rotation pattern shown here. If the vehicle has a compact spare tire, do not include the compact spare tire in the tire rotation. After the tires have been rotated, adjust the front and rear inflation pressures as shown on the Tire and Loading Information label.
Page 417 Various factors, such as maintenance, temperatures, driving speeds, vehicle loading, and road conditions influence when you need new tires. One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining.
Page 418 need replacement tires, GM strongly recommends that you get tires with the same TPC Spec rating. This way, your vehicle will continue to have tires that are designed to give the same performance and vehicle safety, during normal use, as the original tires.
Page 419 Winter tires with the same speed rating as your original equipment tires may not be available for H, V, W, Y and ZR speed rated tires. If you choose snow tires with a lower speed rating, never exceed the tire's maximum speed capability. Mixing tires could cause you to lose control while driving.
Page 420 Your vehicle's original equipment tires are listed on the Tire and Loading Information label. See information about the Tire and Loading Information label and its location on your vehicle. If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, including its braking, ride and handling characteristics, stability, and...
Page 421 Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by treadwear, traction, and temperature performance.
Page 422 A tire marked C may have poor traction performance. Warning: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a...
Page 423 If you need to replace any of your wheels, wheel bolts, wheel nuts, or Tire Pressure Monitor System (TPMS) sensors, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, wheel nuts, and TPMS sensors for your vehicle.
Page 424 If your vehicle has P255/45R17, P255/45ZR18, or 255/45ZR18 size tires, do not use tire chains, as there is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension, or other vehicle parts. The area damaged by the tire chains could cause you to lose control of the vehicle and you or others may be injured in a crash.
Page 425 A rear blowout, particularly on a curve, acts much like a skid and may require the same correction you would use in a skid. In any rear blowout remove your foot from the accelerator pedal. Get the vehicle under control by steering the way you want the vehicle to go.
Page 426 If the vehicle has the tire sealant and compressor kit shown above, see the operating instructions that follow. 6-76 If the vehicle has the tire sealant and compressor kit shown above, follow the operating instructions under Tire Sealant and Compressor Kit (With Selector Switch).
Page 427 Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation.
Page 428 Read and follow all of the tire sealant and compressor kit instructions. The kit includes: A. Air Compressor E. Pressure Gauge B. Tire Sealant Canister F. Air Only Hose (Black) C. Power Plug G. Sealant/Air Hose (Clear) D. On/Off Button 6-78 Read and follow the safe handling instructions on the label adhered to the sealant canister.
Page 429 When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for five minutes. This will help to inflate the tire faster. If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place.
Page 430 6. Plug the power plug (C) into the accessory power outlet in the vehicle. Unplug all items from other accessory power outlets. See If the vehicle has an accessory power outlet, do not use the cigarette lighter. If the vehicle only has a cigarette lighter, use the cigarette lighter.
Page 431 11. Unplug the power plug (C) from the accessory power outlet in the vehicle. 12. Turn the sealant/air hose (G) counterclockwise to remove it from the tire valve stem. 13. Replace the tire valve stem cap. 14. Replace the sealant/air hose (G), and the power plug (C) back in their original location.
Page 432 To use the air compressor to inflate a tire with air only and not sealant: If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning flashers. See 6-82 important safety warnings.
Page 433 8. Plug the power plug (C) into the accessory power outlet in the vehicle. Unplug all items from other accessory power outlets. See If the vehicle has an accessory power outlet, do not use the cigarette lighter. If the vehicle only has a cigarette lighter, use the cigarette lighter.
Page 434 To remove the sealant canister: 1. Unlock the air only hose (F) from the sealant canister (B) by pulling up on the lever. 2. Pull the air only hose (F) from the sealant canister (B). 3. Unwrap the sealant/air hose (G) from the compressor (A).
Page 435 To install a new sealant canister: 1. Align the sealant/air hose (G) with the slot in the air compressor. 2. Push the sealant canister (B) down and turn it clockwise. 3. Wrap the sealant/air hose (G) around the air compressor channel to stow it in its original location.
Page 436 If the vehicle has the tire sealant and compressor kit shown above, follow the operating instructions under Tire Sealant and Compressor Kit (Without Selector Switch). 6-86 Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle.
Page 437 Storing the tire sealant and compressor kit or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store the tire sealant and compressor kit in its original location.
Page 438 Read and follow the safe handling instructions on the label adhered to the sealant canister. Check the tire sealant expiration date on the sealant canister. The sealant canister should be replaced before its expiration date. Replacement sealant canisters are available at your local dealer. See Removal and Installation of the Sealant Canister following.
Page 439 If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning flashers. See important safety warnings. Do not remove any objects that have penetrated the tire. 1. Remove the tire sealant and compressor kit from its storage location.
Page 440 10. Inflate the tire to the recommended inflation pressure using the pressure gauge (C). The recommended inflation pressure can be found on the Tire and Loading Information label. See The pressure gauge (C) may read higher than the actual tire pressure while the compressor is on. Turn the compressor off to get an accurate pressure reading.
Page 441 19. Stop at a safe location and check the tire pressure. Refer to Steps 1 through 11 under Using the Tire Sealant and Compressor Kit without Sealant to Inflate a Tire (Not Punctured). If the tire pressure has fallen more than 68 kPa (10 psi) below the recommended inflation pressure, stop driving the vehicle.
Page 442 important safety warnings. 1. Remove the tire sealant and compressor kit from its storage location. See 2. Unwrap the air only hose (G) and the power plug (H). 3. Place the kit on the ground. 4. Remove the tire valve stem cap from the flat tire by turning it counterclockwise.
Page 443 14. Replace the air only hose (G) and the power plug (H) and cord back in its original location. 15. Place the equipment in the original storage location in the vehicle. The tire sealant and compressor kit has an accessory adapter located in a compartment on the bottom of its housing that may be used to inflate air mattresses, balls, etc.
Page 444 The tire sealant and compressor kit is located in the trunk. 1. Open the trunk. See 2. Remove the retainer that holds the tire sealant and compressor kit in place. 3. Remove the tire sealant and compressor kit from the foam container. To store the tire sealant and compressor kit, reverse the steps.
Page 445 To be even more certain the vehicle will not move, you should put blocks at the front and rear of the tire farthest away from the one being changed. That would be the tire, on the other side, at the opposite end of the vehicle.
Page 446 The equipment you will need is located in the trunk. To access to the compact spare tire and jacking equipment: 1. Open the trunk. See information. 2. Remove the compact spare tire cover. 6-96 for more 3. Pull the stow rod (A) to remove it. 4.
Page 447 The tools you will be using include the jack (A) and the wheel wrench (B). 1. Do a safety check before proceeding. See information. 2. Loosen all of the wheel nuts, but do not remove them yet, using the wheel wrench. Turn the handle about 180 degrees, then flip the handle back to the starting position.
Page 448 3. Find the vehicle's jacking location using the diagram above and corresponding V shaped notches located in the plastic molding on the vehicle's frame. The notches in the plastic molding are marked with a triangle shape. 4. Attach the wheel wrench to the jack. 6-98 Getting under a vehicle when it is jacked up is dangerous.
Page 449 Lifting a vehicle and getting under it to do maintenance or repairs is dangerous without the appropriate safety equipment and training. If a jack is provided with the vehicle, it is designed only for changing a flat tire. If it is used for anything else, you or others could be badly injured or killed if the vehicle slips off the jack.
Page 450 8. Raise the vehicle by turning the wheel wrench clockwise. Raise the vehicle far enough off the ground for the compact spare tire to fit under the vehicle. 6-100 9. Remove all the wheel nuts and the flat tire. Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time.
Page 451 to the vehicle. In an emergency, use a cloth or a paper towel to do this; but be sure to use a scraper or wire brush later, if needed, to get all the rust or dirt off. See Never use oil or grease on bolts or nuts because the nuts might come loose.
Page 452 Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque specification after replacing. Follow the torque specification supplied by the aftermarket manufacturer when using accessory locking wheel nuts.
Page 453 15. Tighten the wheel nuts firmly in a crisscross sequence as shown. Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.
Page 454 Use the following diagram as a guide for storing the compact spare tire and tools in the trunk: A. Compact Spare E. Jack Container Package Tire Cover (With Wheel Wrench and Jack) B. Stow Rod Cap F. Compact Spare Tire C.
Page 455 Driving with more than one compact spare tire at a time could result in loss of braking and handling. This could lead to a crash and you or others could be injured. Use only one compact spare tire at a time. Although the compact spare tire was fully inflated when the vehicle was new, it can lose air after a time.
Page 456 The vehicle's interior will continue to look its best if it is cleaned often. Although not always visible, dust and dirt can accumulate on the upholstery. Dirt can damage carpet, fabric, leather, and plastic surfaces. Regular vacuuming is recommended to remove particles from the upholstery.
Page 457 Do not clean the vehicle using: A knife or any other sharp object to remove a soil from any interior surface. A stiff brush. It can cause damage to the vehicle's interior surfaces. Heavy pressure or aggressive rubbing with a cleaning cloth.
Page 458 If any of the soil remains, a commercial fabric cleaner or spot lifter may be necessary. When a commercial upholstery cleaner or spot lifter is to be used, test a small hidden area for colorfastness first. If the locally cleaned area gives any impression that a ring formation may result, clean the entire surface.
Page 459 Use a clean cloth moistened in warm, soapy water (use mild dish washing soap). Dry the wood immediately with a clean cloth. Vacuum around a speaker cover gently, so that the speaker will not be damaged. Clean spots with just water and mild soap.
Page 460 Rinse the vehicle well, before washing and after to remove all cleaning agents completely. If they are allowed to dry on the surface, they could stain. Dry the finish with a soft, clean chamois or an all-cotton towel to avoid surface scratches and water spotting. High pressure car washes may cause water to enter the vehicle.
Page 461 If necessary, use non-abrasive cleaners that are marked safe for painted surfaces to remove foreign matter. Exterior painted surfaces are subject to aging, weather and chemical fallout that can take their toll over a period of years. To help keep the paint finish looking new, keep the vehicle garaged or covered whenever possible.
Page 462 The vehicle may have either aluminum or chrome-plated wheels. Keep the wheels clean using a soft clean cloth with mild soap and water. Rinse with clean water. After rinsing thoroughly, dry with a soft clean towel. A wax may then be applied.
Page 463 To clean the tires, use a stiff brush with tire cleaner. If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to parts repaired or replaced to restore corrosion protection. Original manufacturer replacement parts will provide the corrosion protection while maintaining the vehicle warranty.
Page 464 This legal identifier is in the front corner of the instrument panel, on the driver side. It can be seen through the windshield from outside. The VIN also appears on the Vehicle Certification and Service Parts labels and certificates of title and registration. The eighth character in the VIN is the engine code.
Page 465 The vehicle has an airbag system. Before attempting to add anything electrical to the vehicle, see The headlamp wiring is protected by fuses in the fuse block. An electrical overload will cause the lamps to turn off. If this happens, have the headlamp wiring checked right away.
Page 466 6-116...
Page 467 The underhood fuse block is located in the front of the engine compartment on the passenger side of the vehicle. See for more information on location and removal procedure for the front compartment underhood sights shields. To access the fuses, push in the tabs located on each side of the fuse block cover, then lift the cover off.
Page 468 Easy Key Module (EKM), Instrument EKM/I/P MDL Panel Module (I/P MDL) Even Ignition Coils, Even Fuel EVEN COILS Injectors FOG LAMP Front Fog Lamps FRT PWR Front Accessory Power Outlet OUTLET FUEL COOL Fuel Cooling HORN Horn Heated Headlamp Washer, Air Quality WASH/AQS Sensor Heads-Up Display, Steering Column...
Page 469 Instrument Panel Module-Voltage V/CHK Check Wipe/Wash Module Assembly WPR SW/VICS Rain Sensor, Wiper Switch A/C CMPRSR Air Conditioning Compressor Clutch CLTCH Accessory, Rain Sensor, Headlamp ACCY Washer Relay Coil, Windshield Wiper/Washer Module Brake Vacuum Pump VAC PUMP FAN S/P Cooling Fan Series/Parallel FOG LAMP Fog Lamps FRT BLWR...
Page 470 To remove the rear seat cushion, do the following: 1. Pull up on the front of the cushion to release the front hooks. 2. Pull the cushion up and out toward the front of the vehicle. 6-120 To reinstall the rear seat cushion, do the following: A safety belt that is not properly routed through the seat cushion or is twisted will not provide the protection needed in a crash.
Page 471 will not be there to work for the next passenger. The person sitting in that position could be badly injured. After reinstalling the seat cushion, always check to be sure that the safety belts are properly routed and are not twisted. 1.
Page 472 The vehicle may not have all the fuses listed below. 6-122...
Page 473 Amplifier SPARE Spare Theft Sensors, Auto Shifter, Power THEFT/SHFT Sounder Magnetic Ride Control Module MRTD MDL (Option) REAR DR MDL Rear Door Modules Electronic Level Control, Exhaust ELC EXH Solenoid (Option) Driver Door Module, Front Door SubWoofers (Option) Infotainment (Export Only), TV/VICS/SCM Supervisory Control Module (Option) REAR HTD/...
Page 474 SPARE Spare Electronic Level Control, Compressor ELC CMPRSR (Option) Left Rear Taillamp, Position Lamps LT POS (Option) Right Rear Taillamp, Position Lamps RT POS (Option) Ignition 3 Rear Taillamps, Position Lamps STDBY LAMP (Option) TRUNK RELSE Trunk Release Motor Reverse Lamps, Rear Parking Aid, BCK/UP LAMP Inside Rearview Mirror 6-124...
Page 475 6-125...
Page 476 Sensing and Diagnostic Monitor, Automatic Occupant Sensor, AIRBAG/IGN Passenger Supplemental Inflatable Restraint CNSTR/VENT Canister Vent Solenoid SPARE Spare Front Passenger Door Module, Right FRT PDM Power Subwoofer FUEL PUMP Fuel Pump HTD STR Heated Steering Wheel RF HTD/ Front Passenger Heated Seat, SEAT/XM S-Band Antenna...
Page 477 SPARE Spare FUEL PUMP Fuel Pump INT LAMP Interior Lamps REAR DEFOG Rear Defogger REAR/FOG Rear Fog Lamps (Option) RUN/CRNK Ignition 1 SPARE Spare STOP LAMP Stop Lamp WINDOW MTRS Power Window Motors Circuit Breaker TRUNK DIODE Trunk Release Splice Pack (Blue) 6-127...
Page 478 The following approximate capacities are given in metric and English conversions. See for more information. Air Conditioning Refrigerant R134a Brake Fluid Capacities Cooling System Engine Oil with Filter Fuel Tank Transmission Fluid 6-Speed Automatic (Pan Removal and Filter Replacement) Wheel Nut Torque All capacities are approximate.
Page 515: Appearance Care
Accessories and Modifications ..... . .6-4 Accessory Power ........3-27 Accessory Power Outlets .
Page 516: Automatic Transmission
Audio System ........4-94 Audio Steering Wheel Controls .
Page 517: Climate Control Systems
Carbon Monoxide Engine Exhaust ........3-36 Trunk .
Page 518: Customer Information
Convenience Net ........3-57 Coolant Engine ..........6-25 Engine Temperature Gauge .
Page 519: Electrical System
EDR ..........8-19 Electrical Equipment, Add-On .
Page 520: Fuel Economy
Fuel ..........6-6 Additives .
Page 521: Instrument Panel
Heated Seats ........2-4, 2-5 Heater Engine Coolant .
Page 522: Outside Automatic Dimming Mirror
Lights (cont.) Engine Coolant Temperature Warning ... . 4-61 Flash-to-Pass ........4-9 Front Fog Lamps .
Page 523: New Vehicle Break-In
Navigation System, Privacy ......8-20 Navigation/Radio System, see Navigation Manual ......... . 4-113 Net, Convenience .
Page 524: Rearview Mirrors
Phone ® Bluetooth ........4-113 Power Door Locks .
Page 525: Running The Vehicle While Parked
Replacement Parts Maintenance ........7-11 Reporting Safety Defects Canadian Government .
Page 526: Starting The Engine
Service ..........6-4 Accessories and Modifications .
Page 527 Tires ..........6-50 Aluminum or Chrome-Plated Wheels, Cleaning .
Page 528: Vehicle Personalization
Valet Lockout Switch ......3-24 Vehicle Control ..........5-3 Loading .
