Installation Instructions
Model Numbers:
Certified to:
- Certified for use with Adjustable Vented Platform (AVP), and Heat Distribution System (HDS) -
⚠
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
-WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire department
-Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
INSTALLER: Leave this manual with the appliance.
This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
A Division of R-Co. Inc. 2340 Logan Ave. Winnipeg, Manitoba Canada R2R 2V3 Ph.: (204) 632-1962
Single Side Units:
MQVL48N, MQVL48NE, MQVL48NE2, MQVL48LP,
MQVL48LPE, MQVL48LPE2
Bay Peninsula Units:
MQVLB48N, MQVLB48NE, MQVLB48NE2,
MQVLB48LP, MQVLB48LPE, MQVL48BLPE2
ANSI Z21.88-2017/CSA 2.33-2017 and CSA2.17-2017
VENTED GAS FIREPLACE HEATER
CONSUMER: Retain this manual for future reference.
Printed in Canada April 30, 2019 Part# 48MQVL-MAN17
ENCLAVE
Advertisement
Table of Contents
Related Manuals for R-Co Kingsman Marquis MQVL48N
Summary of Contents for R-Co Kingsman Marquis MQVL48N
- Page 1 This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. A Division of R-Co. Inc. 2340 Logan Ave. Winnipeg, Manitoba Canada R2R 2V3 Ph.: (204) 632-1962 Printed in Canada April 30, 2019 Part# 48MQVL-MAN17...
-
Page 2: Warnings
IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance. - Page 3 Warnings, Installations and Operations - Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;...
-
Page 4: Table Of Contents
MQVL48 / MQVLB48 Table of Contents Warnings................................. Table of Contents..............................Installation Requirements for the Commonwealth of Massachusetts..............Carbon Monoxide (CO) Detector..........................Pre-installation Questions and Answers......................... Operations and Maintenance Instructions......................Mobile Home/Manufactured Housing Installation....................INSTALLATION & FRAMING Framing Your Gas Fireplace........................... Fireplace Installations in Covered Outdoor Locations.................... - Page 5 MQ STONE Decorative Stone Set.......................... MQEMBER................................MQRBD3 - 5 Pc. Driftwood Log Set........................MQLOGF48D- 6 Pc. Driftwood Log Set........................Burner System Gas Line Installation / Gas Specifications Chart....................Millivolt System, Lighting, and Burner Control......................Annual Inspection List for Determining Safe Operation of a Direct Vent Gas Fireplace......... Troubleshooting the Gas Control System.......................
-
Page 6: Installation Requirements For The Commonwealth Of Massachusetts
Installation Requirements for the Commonwealth of Massachusetts In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth. When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the requirements listed below. -
Page 7: Pre-Installation Questions And Answers
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 8: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 9: Framing Your Gas Fireplace
MQVL48 / MQVLB48 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance. -
Page 10: Fireplace Installations In Covered Outdoor Locations
Fireplace Installations in Covered Outdoor Locations – FOR BASIC MILLIVOLT UNITS ONLY- NO FAN – NO LIGHTS- CAUTION – Installation of an indoor gas fireplace with an outdoor exposure is not covered under the (ANSI Z21.88 – CSA 2.22 or ANSI Z21.50 – CSA 2.33) standard(s) used to certify the indoor gas-fired fireplace. The Intertek safety certification will not apply to this installation method. -
Page 11: Marquis Mqvl48 / Mqvlb48 Units - Vented Chase Requirements
VENTED CHASE REQUIREMENTS MQVL48 / MQVLB48 FIREPLACE CHASE MUST BE VENTED AT TOP AND BOTTOM- Minimum 151 Chase Vent Openings LARGER than square inches free air opening at the top of the chase, and minimum 84 square the required minimums ARE allowed inches free air opening at the bottom of the chase. -
Page 12: Vl48Avp Optional Adjustable Vented Platform Base
VL48AVP Adjustable Vented Platform -OPTION The Adjustable Vented Platform is an optional installation base. Height is variable from approximately 14-3/4” to 27-1/4”. Venting slots are provided at the bottom and between the fireplace and the platform. INNER 9-3/4” SIDE 27-5/16” PANEL 14-13/16 14-13/16”... - Page 13 STEP TWO: ASSEMBLE TOP REAR BRACE INNER SIDE INNER PANEL INNER SIDE SIDE PANEL PANEL OUTER OUTER SIDE FRONT OUTER PANEL PANEL FRONT PANEL TILE LIP TILE LIP 2. Assemble Top using supplied screws. INNER SIDE PANEL INNER INNER SIDE SIDE PANEL PANEL...
-
Page 14: Framing - Platform Base
MQVL48 / MQVLB48 Framing – Platform Base A Platform Base has air opening requirements that must be met. Top of Platform Must Have Minimum 480 Square Inches Free Air Opening ⚠ DO NOT COVER TOP OF PLATFORM WITH A SHEET OF PLYWOOD. -
Page 15: Vl48Eg Grill Installation
VL48EG Grill Installation- -Option- Compatible with both Vented Chase and HDS Parts List: *This Grill Meets Minimum Opening Air Free Requirements* [1] Louver Grill (ready to paint) This Kit comes with two installation options: Outer Trim Grill Mount - For a Quick and simple installation. [1] Outer Trim Grill Mount (ready to paint) Hidden Grill Mount - For a very clean installation with only the grill [1] Upper Frame for Hidden Grill Mount... -
Page 16: Vl48Egs Side Grill
VL48EGS Side Grill Installation - MQVL48, MQVLB48 Option Not compatible with HDS System. ⚠ Grill openings must be within 2” of enclosure top. Contents of Kit: [Qty 2] Side Grill assemblies (ready to paint). This is to prevent excess heat from becoming trapped in the top of the chase. -
Page 17: Vl48Hds Optional Heat Distribution System
VL48HDS Optional Heat Distribution System -Option *Requires ZDV5FP6 Flex Pipe Kit (Contains 4 pcs. 5”diameter flex pipe 6’ long). Uses Kingsman VL48EG Grill Must be installed before front framing is in place. Minimum 151 Sq. In. Free Air Equivalent Plenum Connect only the two center pipes when venting to an optional secondary vent opening. -
Page 18: Clearance To Combustibles
MQVL48 / MQVLB48 Clearance to Combustibles Front (Furniture, etc. from glass) 36” [92cm] Side (Furniture, etc. from glass) 36” [92cm] Side (from Stand-offs of VLB48 or Corner Kit) 0” [0cm] ⚠ NOTE Back (from Stand-offs) 0” [0cm] If using insulation in vented chase (i.e. -
Page 19: Mantel Clearances / Adjacent Wall
MQVL48 / MQVLB48 Mantel Clearances SIDE VIEW (MQVLB48 Shown) A Combustible Mantel 151 sq. can be placed immediately in. Min. above the fireplace 3/4” 1 in. Min. opening. A Combustible Hearth can be placed immediately 28-1/2” below the fireplace (55” TV) opening. -
Page 20: Mqvl48 Single Side
MQVL48 Single Side Locating Your Appliance LOCATION KEY: Left Side Corner Flat on Wall 45° Corner As a Room Divider As an Island* Right Side Corner Exterior Wall Chase 20’ MAX *Island installation with a top vent is possible as long as the horizontal portion of the vent system does not 20’... -
Page 21: Nailing Tab Guide
MQVL48 Single Side -Nailing Tab Guide- [Qty] 4 Nailing Tabs are located on each side of the front frame. NOTE: If using the rear nailing tabs for cantilevered chase etc., refer to the Nailing Tab page for MQVLB48 Bay Peninsula. Flat (As Shipped) Pull up 90°... -
Page 22: Single Side Framing
MQVL48 Single Side Framing TOP VIEW Stud Stud BACK WALL FRAMING 18-7/8” Framing Flush with Face FRAMING OVER FRONT TOP OF FIREPLACE FRAMING FRONT FIREPLACE FRAMING IN FRONT OF FIREPLACE Variable – Can be built out to desired depth EXTENDED FRAMING FRONT FIREPLACE EXTENDED FRAMING IN FRONT OF FIREPLACE... -
Page 23: Using Tile Lip
MQVL48 Single Side - Using Tile Lip A Tile Lip is supplied for attachment above the fireplace opening. This can be used as a standard tile edging or as a mount bracket for other surfaces like drywall or plywood. Set to desired height and attach through holes in face of fireplace. -
Page 24: Vl48S1Bl / Vl48S1Ss -Surround Installation For Mqvl48
VL48S1BL / VL48S1SS -Surround Installation for MQVL48 -Option Surround is available in Painted Black (VL48S1BL) ASSEMBLY: or Stainless Steel with Black Sides (VL48S1SS). - Attach Side Fillers to Surround Frame with PARTS LIST: [Qty] 16 screws. - Surround Frame - [Qty 2] Black Side Fillers - [Qty 20] #6 Screws NOTE: DO NOT... -
Page 25: Mqvl48Sep Side Extension Panels
MQVL48 Single Side- MQVL48SEP Side Extension Panels -Option- Contents if Kit: Qty 2 – Side Extension Panels Qty 4 - #6 Black Screws 4” 18-3/16” 19-7/16” Framing Details: FROM EDGE OF FIREPLACE TO OUTSIDE OF 2 X 4 HORIZONTAL FRAMING ABOVE TOP OF 19-3/16”... -
Page 26: Mqvlb48 Bay Peninsula
MQVLB48 Bay Peninsula Locating Your Appliance LOCATION KEY: A. Corner Kit- Left Side B. Flat on Wall C. Corner Kit- Right Side D. Corner Kit- Left Side E. Corner Kit- Right Side F. 45° Corner G. As an Island* *Island installation with a top 20’... -
Page 27: Bay Peninsula Framing
MQVLB48 Bay Peninsula -Framing OPTION A: Framing Attached to Side of Fireplace- For building out around the fireplace. NOTE: Appliance and framing structures are not load bearing. SIDE VIEW -TOP VIEW- BACK WALL FRAMING ON TOP OF FIREPLACE VARIABLE Can be built out to desired depth EXTENDED FRAMING IN FRONT OF FIREPLACE... -
Page 28: Bay Peninsula Nailing Tabs And Framing
MQVLB48 Peninsula –Nailing Tabs and Framing OPTION A: Framing Attached to Side of Fireplace- For building out around the fireplace. Framing must be self- supporting. SIDE NAILING TAB Optional framing attached to side MIN. 151 of fireplace SQ. IN. ⚠ DO NOT COVER TOP OF PLATFORM WITH A SHEET OF PLYWOOD. - Page 29 VLBCK48 Corner Kit for MQVLB48 Peninsula Bay Option MUST BE INSTALLED BEFORE UNIT IS INSTALLED INTO FRAMING. CORNER KIT CAN BE INSTALLED AT EITHER END OF FIREPLACE. ⚠ Warning: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
-
Page 30: Vlbck48 Corner Kit
reinstalled from the IF USING inside corner of the PORCELAIN OR firebox. IF FLUTED LINERS: FIREPLACE IS Remove [Qty 4] ALREADY DT Screws from INSTALLED, outside and SIMPLY CUT install inside SCREWS WITH A firebox. ROTARY TOOL IF FIREPLACE IS ALREADY Place Heat Shield INSTALLED,... -
Page 31: Using Tile Lip
MQVLB48 Bay Peninsula - Using Tile Lip Drywall Drywall 84 Square Inches Free Air Minimum MQVLB48 Bay Peninsula -Facing Requirements Unit may be covered with combustible material (i.e. drywall) up to the fireplace opening. Option A: Open Chase at Ceiling Minimum 151 Sq. -
Page 32: Glass Door Front Removal / Installation
MQVL48 / MQVLB48 Glass Door Front Removal / Installation To remove Glass Door Front: Side Cover Panel x 2 (MQVL48) Corner Covers x 2 (MQVLB48) Side Cover Panel x 1 (VLBCK48 Corner Kit) 1. MQVL48: Remove [2ea] 10-24 wing nuts (or 3/8” nuts) to remove the Side Cover Panels. -
Page 33: Door And Glass Information
Door and Glass Information MQVL48 / MQVLB48 Glass Cleaning It will be necessary to clean the glass periodically. During startup, condensation, which is normal, forms on the inside of the glass, and causes dust, lint etc. to cling to the glass surface. Also, initial paint curing can deposit a slight film on the glass. -
Page 34: Mqvl48 / Mqvlb48 Glass Safety Barrier Installation / Removal
MQVL48 / MQVLB48– Glass Safety Barrier Installation / Removal INSTALL SIDE GLASS FIRST. DECAL ON GLASS SHOULD FACE OUTSIDE. 16-3/16” 16-3/16” 54-5/8” 14-3/8” FRONT GLASS PANEL [QTY 1] SIDE GLASS PANELS [QTY 2] GLASS SUPPORTS INSERT GLASS INTO CLIPS PLACE GLASS INTO GLASS SUPPORTS. -
Page 35: Component Locations
MQVL48 / MQVLB48 Component Locations TOP VIEW GAS LINE 120 VAC LIGHT LIGHT 120 VAC VALVE DRIVER OPTIONAL MODULE BATTERY TRANSFORMER REMOTE PAIRING BUTTON (LED) BACKUP (HALOGEN) (SW1 SWITCH) REMOTE PAIRING BUTTON (SW1 SWITCH) DCHS Cover for Optional Remote Receiver- Millivolt or Proflame 1 Systems Only PROFLAME 1 C/W REMOTE... -
Page 36: Halogen Lamps
MQVL48 / MQVLB48 Halogen Lights Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. LAMP LAMP TERMINAL POST PLATE Inside Firebox Bottom of Firebox 584-X10 HARNESS ULK TRANSFORMER YELLOW CONNECTOR GROUNDING STUD BATTERY BACKUP... -
Page 37: Led Lighting
MQVL48 / MQVLB48 LED Lighting Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. LED Light Strip is Located Under the Firebox. LED LIGHT STRIP 584-X10 HARNESS YELLOW CONNECTOR GROUNDING STUD PROFLAME 2 MODULE LED CONTROLLER... -
Page 38: Vl48Plb / Vl48Ple Porcelain Liner Installation
VL48PLB / VL48PLE Porcelain Liner Installation Option -VL48PLB- BACK PANEL KIT NOTE: If using VLBCK48 CORNER KIT, DO NOT USE BACK FILLER Inner Liner Panel from Corner Kit. Remove if installed. STEP ONE: Remove Liner Clips and screws from inside of firebox with a BACK LINER 1/4”... -
Page 39: Mqvl48Rgb Glass Back Liner Installation
MQVL48RGB Glass Back Liner Installation Option -MQVL48RGB - BACK PANEL KIT ⚠ CAUTION – NOT TEMPERED GLASS- 46-9/16” EXTREMELY FRAGILE – HANDLE WITH CARE 19-3/8” 19-1/16” GLASS BACK LINER NOTE: If using VLBCK48 CORNER KIT and you are NOT installing a Glass End Panel, install Inner Liner Panel from Corner Kit before Corner Filler Corner Filler... - Page 40 STEP FIVE: Insert Corner Fillers if NOT using MQVL48RGE End Panels: IF YOU ARE NOT INSTALLING MQVL48RGE End Panels, Insert Corner Fillers behind sides of Glass Back Panel as shown and push Glass Back Panel into place. NOTE: If using VLBCK48 CORNER KIT and you are NOT installing a Glass End...
-
Page 41: Mqvl48Rge Glass End Panel Installation
MQVL48RGE Glass End Panel Installation Option -MQVL48RGE - END PANEL KIT ⚠ CAUTION – NOT TEMPERED GLASS- EXTREMELY FRAGILE – HANDLE WITH CARE RIGHT NOTE: MQVL48RGB must be installed first. Refer to instructions LEFT SIDE SIDE included in MQVL48RGB kit. GLASS GLASS NOTE: If using VLBCK48 CORNER KIT and you are NOT installing... - Page 42 STEP THREE: Engage Front Slot of Tab with DT Screw in side wall of firebox. There is no bottom attachment Screw. FRONT FIREBOX LEFT SIDE END PANEL Repeat actions for other side. NOTE: if you are using VLBCK48 CORNER KIT, only one End Panel will be used. ⚠...
-
Page 43: Mqvl48Rlfb / Mqvl48Rlfe Fluted Liner Installation
MQVL48RLFB / MQVL48RLFE Fluted Liner Installation Option -MQVL48RLFB- BACK LINER KIT NOTE: If using VLBCK48 CORNER KIT, remove Inner Liner Panel from Corner Kit if installed. STEP ONE: BACK LINER BACK LINER Remove Liner Clips from inside of firebox with a 1/4” hex driver. -MQVL48RLFE- END LINER KIT LEFT RIGHT... -
Page 44: Mq Glass
MQVL48 / MQVLB48 MQ Dealer Accessories The following Accessories are available through MQ Dealers only. GLASS (MQG5W, MQG5C, MQG5A, MQG5B) ACCESSORY ITEM DESCRIPTION If you wish to use this media evenly spread the glass embers onto the false bottom and burner. Ensure the glass embers do not excessively MQG5W Decorative Glass 1/2”... -
Page 45: Mqrock2, Mqrock3, Mqrbd1
MQROCK2, MQROCK3, MQRBD1 - Place rocks randomly onto False Bottom. MQRock2 MQRock3 MQRBD1 NOTE Pilot Area Must Not Be Covered, as delayed ignition can occur. Do Not Cover any part of the burner tube with logs as sooting may occur. ... -
Page 46: Mqrbd3 - 5 Pc. Driftwood Log Set
MQRBD3 -5 Piece Driftwood Log Set- Can be used with MQ Glass, MQ Rock, MQ Stone or MQ Ember. Follow instructions for these accessories. ⚠ NOTE LOG 1 For best flame pattern it LOG 3 is essential to spread supplied Crushed Glass or MQEMBER directly LOG 4... -
Page 47: Mqlogf48D- 6 Pc. Driftwood Log Set
MQVLV48 / MQVLB48 MQLOGF48D ⚠ WARNING: Failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Place Glass onto front area of Burner and over lights. -
Page 48: Gas Line Installation / Gas Specifications Chart
MQVL48 / MQVLB48 Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA - B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 49: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING This appliance has a pilot which must be lighted by hand. When ... -
Page 50: Annual Inspection List For Determining Safe Operation Of A Direct Vent Gas Fireplace
Annual Inspection List for Determining Safe Operation of a Direct Vent Gas Fireplace Refer to this checklist for proper maintenance, safe use, and operation. See each section for more specific information. 1. Inspect and operate all pressure relief mechanisms (i.e., relief dampers, spring loaded door latches) installed on your appliance to verify relief mechanisms are free from obstruction to operate. -
Page 51: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not light. Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is electrode at pilot. -
Page 52: Burner System Maintenance
Burner System Maintenance MQVL48 / MQVLB48 It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. ⚠ -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance. -
Page 53: Gas Conversion Part A
-Gas Conversion Part A- MQVL48 / MQVLB48 Models: MQVL48N, MQVL48NE, MQVL48NE2, MQVL48LP, MQVL48LPE, MQVL48LPE2, MQVLB48N, MQVLB48NE, MQVLB48NE2, MQVLB48LP, MQVLB48LPE, MQVL48BLPE2 Kit Number Description Pilot Orifice Burner Orifice Brass Nipple Air Shutter Hi/Lo Regulator Brass (1000-255) 48VL-CKLP LP Conversion 1001-P167SI 1000-253 1001-P202SI Fully Open -Millivolt-... -
Page 54: Gas Conversion For Top Convertible Pilot - Part B
Gas Conversion for Top Convertible Pilot – Part B (series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 55: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C... -
Page 56: Burner Tube Removal
MQVL48 / MQVLB48 False Bottom Removal (Media Tray) In order to access the Burner Tube and Burner Pan, the False Bottom must be removed. STEP 1:MQVLB48 Units Remove Retainers from STEP 2: Remove the [Qty 8] Screws shown below. each end of False Bottom. -
Page 57: Proflame
Proflame 1 -IPI Electronic Ignition System- Overview The IPI system is an advanced burner controller that provides you with the option of having either a Standing-Pilot, or an Remote Receiver intermittent igniting system. This alternating Module mode is controlled by the CPI/IPI Switch (Optional) (Continuous Pilot Ignition/Intermittent Pilot Ignition) located on the IPI System Box. -
Page 58: Remote Control Operation
Proflame 1 -Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat. -
Page 59: Proflame 1 Parts List
Proflame 1 -IPI System Parts List- PART NO. DESCRIPTION 1006-P002SI Valve IPI Hi/Lo NG 11. 1002-P012SI IPI Stepper Kit - LP 907.012 1006-P003SI Valve IPI Hi/Lo LP 12. 1002-P013SI IPI Stepper Kit - NG 907.013 1002-P302SI IPI Ignition Board 13. 1002-P014SI IPI Reg Kit - LP Hi-Lo 907.014 1002-P047SI Pilot Assembly-LP -24”... -
Page 60: Configuration #2: Remote On/Off And Manual Hi/Lo Capabilities
Proflame 1- Configuration #2: Remote ON/OFF and Manual HI/LO Capabilities OPTIONAL: For units with remote HI/LO capabilities, a modulating servo is required to be installed on the valve. The connectors to this servo must be connected to the Remote Harness as shown. SCHEMATIC PICTURE NOTE: Fan Option... -
Page 61: Configuration #3: Remote On/Off, Variable Hi/Lo, And Fan Capabilities
Proflame 1- Configuration #3: Remote ON/OFF, variable HI/LO, and fan capabilities Refer to the fan installation/removal section for fan installation. NOTE: This Configuration is not available on all models of SCHEMATIC fireplace. Check with your dealer. NOTE: Fan Option PICTURE is not available on some models of fireplace. -
Page 62: Operating The Receiver Without Batteries- Millivolt And Proflame 1
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 63: Electronic Ignition Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A. -
Page 64: Proflame
Proflame 2 –NE2 / LPE2 -IPI System Parts List- IPI PROFLAME 2 - COMPONENT PARTS IPI - PF1 and PF2 Common Components PART NO. DESCRIPTION PART NO. DESCRIPTION 1005-P001SI Valve IPI Proflame PF2 885.001 NG - Stepper 12. 1002-P033SI TC - Pilot Burner IPI (Assembled) NG 199.033 1005-P002SI Valve IPI Proflame PF2 885.002 LP - Stepper 13. -
Page 65: Proflame 2 Module And Remote Control
Proflame 2 Module and Remote Control PRESS BUTTON REMOTE PAIRING BUTTON (SW1 Switch) Pairing Remote Control Press the SW1 button until you hear three beeps. Install the 3 AAA batteries in the battery bay, located on the Within 10 seconds press the button again until you base of the Remote Control. -
Page 66: Cold Climates - Cpi Setting - Proflame 2 Remote Control
Cold Climates – CPI Setting - Proflame 2 Remote Control Use the CPI setting during cold weather, otherwise the fireplace may have a hard time starting up and establishing a LCD Display flame. The CPI (Continuous Pilot Ignition) setting will keep the ON / OFF Key firebox and fireplace exhaust vent warm during cold weather. -
Page 67: Proflame 2 Remote Control Operation
Proflame 2 Remote Control... - Page 68 Note: When Smart Thermostat is activated, manual flame height adjustment is disabled. Note: This function is only available in Room Thermostat or Smart Thermostat Control Mode.
-
Page 70: Venting Vent Termination
Vent Terminal Clearances Clearances are to the edge of the terminal plate. Add 6-3/4” to clearances to arrive at centerline. Local codes or regulations may require different clearances. WARNING: A HORIZONTAL VENT CERTIFIED GUARD (SAFETY CAGE) IS AVAILABLE WHEN REQUIRED BY LOCAL CODES. Canadian installations US installations Clearance above grade, veranda,... -
Page 71: General Vent Installation
General Vent Installation Information This gas appliance is approved to be vented either through the side wall or vertically through the roof. Only Kingsman Flex (Z-Flex) Venting Kits and components specifically approved and LABELED for this stove may be used. This appliance is also approved for use with 5 x 8 M&G-Duravent Direct Vent system (Model DV-GS Series) and Snorkel, BDM Pro Form Direct Vent, Ameri-Vent FRAMING DIMENSION Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp. -
Page 72: Venting Routes And Components
Venting Routes And Components Venting Routes and Components Since it is very important that the vent system maintain its How to Use the Horizontal Vent Table balance between the combustion air intake and the flue gas 1. Determine the height of the system and the number of exhaust, certain limitations as to vent configurations apply and bends required. -
Page 73: Venting Straight Up Through Roof
Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... - Page 74 -Restrictor- Remove for Runs Under 15 Feet Clearances in horizontal venting. Z58VT Clearance to perpendicular wall 24 inches (60 cm). (Recommended to prevent re- circulation of exhaust products. For additional requirements check local codes.) 24” 18” MIN Clearance above highest point of exit on roof 18 inches (45cm) 43ft...
-
Page 75: Approved For Power Vent Pvh58
Approved for Power Vent PVH58 - This appliance is approved for use with the Kingsman PVH58 Horizontal Power Vent - The PVH58 Horizontal Power Vent Termination is intended for use where standard venting configurations are not possible. NOTE: MODELS EQUIPPPED WITH MILLIVOLT/ STANDING PILOT IGNITION: Downward vertical vent runs are NOT permitted. -
Page 76: Pvh58 Parts List
PVH58 Parts List PVH58 HORIZONTAL POWER VENT TERMINATION: Listed for Canada and USA NUMBER DESCRIPTION MQVL48 / MQVLB48 VENTING AND VENTING ADAPTERS -For Power Vent installations where flex pipe will be used up to the Power Vent unit: Z58PVA Flex Connector Set- ZDV5FC (5” Flex Connector), ZDV8FC (8” Flex Connector) * One 12”... -
Page 77: Fireplace Models
MQVL48 / MQVL48B Fireplace Models MARQUIS FIREPLACES Single Side Fireplaces Peninsula Bay Fireplaces MQVL48N (Millivolt) Fireplace Heater rated, NG, MQVLB48N Peninsula Bay Fireplace (Millivolt), Heater Ceramic Glass, Low E Tempered Glass rated, NG, Ceramic Glass, Low E Tempered Safety Barrier, Lights Safety Glass Barrier, Lights MQVLB48LP Peninsula Bay Fireplace (Millivolt) Heater... -
Page 78: Mqvl48 / Mqvl48B Parts List
MQVL48 / MQVL48B Parts List VL48PLB Porcelain Liner - Back Fireplace Part Numbers VL48PLE Porcelain Liner – Ends Part No. Description MQVL48RGB Reflective Glass Liner - Back MQVL48RGE Reflective Glass Liner – Ends (L&R) Optional Corner Kit / Wall Surround / Side Extensions Safety Barrier Glass and Screen VLBCK48 Corner Kit- Can be installed at either end... -
Page 79: Warranty
1001-P167SI Orifice Pilot LP 977.167 TC SIT Control Variable Speed KBWC-13BV 1000-085 1001-P633SI Valve Nova LP Hi/Lo 0820651 FP15GC Stainless Steel Gas Connector 1001-P634SI Valve Nova NG Hi/Lo 0820652 3927ZDV- Bulb 10W 12V 64418 or [Sylvania 1001-P713SI Pilot Burner LP 199.713 TC SIT P779-1 58691] (light bulbs NOT covered under 1001-P714SI... -
Page 80: Limited Lifetime Warranty
This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada. The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
