MT6333FSO
63" Acrylic Clawfoot Freestanding Bathtub
INSTALLATION MANUAL
ATTENTION
• Carefully read the instructions before starting the installation
• This bathtub should be installed by an experienced plumber
• Waste pipe and drain trap are not supplied. Connect to an existing drain pipe.
If you are missing any parts, please stop and contact us immediately 1-855-480-2915
PAGE 1
Advertisement
Related Manuals for miseno MT6333FSO
Summary of Contents for miseno MT6333FSO
- Page 1 MT6333FSO 63” Acrylic Clawfoot Freestanding Bathtub INSTALLATION MANUAL ATTENTION • Carefully read the instructions before starting the installation • This bathtub should be installed by an experienced plumber • Waste pipe and drain trap are not supplied. Connect to an existing drain pipe.
-
Page 2: Tools Required
CAUTION You will need at least two people to install this product properly. In order to reduce the risks of personal injuries, do not support or lift the bathtub by the rim. Provide adequate support under the feet. The distributor is not responsible for any damage to the unit or personal property caused by improper installation. -
Page 3: Specification
SPECIFICATION Measures: inch [millimeter] 41 5/16” [1050] 63” [1600] 58.2gal 83.8lbs 0.22m 38kg PAGE 3... - Page 4 FLOOR TRACING TEMPLATE Rough-in zone for water supply pipes Zone for P-Trap & Waste Outlet floor cut-out Extra zone for P-Trap & Waste Outlet floor cut-out 24 13/16” [630mm] 23 1/4” [590mm] Drain 22 5/8” [575mm] 21 5/8” [550mm] 21 1/4” [540mm] 10 13/16”...
- Page 5 IMPORTANT • Drawings are for reference ONLY. • This guide illustrates installation best practices. • Carefully read the instructions before starting the installation. • This bathtub should be installed by an experienced plumbing • Make sure the floor drain is already installed and is compliant with your local regulations. •...
- Page 6 FAUCET INSTALLATION ON THE BATHTUB (OPTIONAL) Zone for deck Mounted faucet 25 9/16” [650] 4” [100] 4” [100] Measures: inch [millimeter] 1. Locate where you will drill the holes into the acrylic, and stick masking tape onto that area. This will prevent the acrylic from chipping and protect the finish from scratches.
- Page 7 GUIDELINES FOR BATHTUB DRAIN INSTALLATION INSTALLATION (Option #1) Installation using a standard PVC P-Trap is done similarly. Option #1 1. Install the P-Trap by screwing it to the preinstalled bathtub drain outlet. Use Teflon tape and/or sealant. Then, as shown in the illustration, connect the P-Trap to the Flexible Tube. 2.
- Page 8 INSTALLATION (Option #2) Installation using a standard PVC P-Trap is done similarly. Option #2 1. Screw the supplied Adapter to the preinstalled bathtub drain. Use Teflon tape and/or sealant to seal the threads. 2. Connect the P-Trap to the Adapter using PVC pipe sealant to adequately join the two parts. 3.
- Page 9 SECUREMENT BEFORE AFFIXING YOUR TUB TO THE FLOOR, MAKE SURE YOU HAVE INSTALLED YOUR FAUCET (IF APPLICABLE) AND THAT YOU HAVE CHECKED FOR LEAKS. 1. Test for leaks by filling up the tub and let it drain. Then check all plumbing connections for leaks. 2.
