- Page 1 MR-9000TPT ETHERNET MULTIPORT REPEATER USER’S GUIDE The Complete Networking Solution Cabletron Systems, P.O. Box 5005, Rochester, N.H. 03867-0505...
- Page 3 Rochester N.H. 03867-0505 All Rights Reserved Printed in the United States of America Order number: 9030063-01 April 1992 LANVIEW is a registered trademark and MR-9000TPT and TPT-2 are trademarks of Cabletron Systems, Inc. Ethernet is a trademark of Xerox Corporation...
-
Page 4: Fcc Notice
Relocate the MR-9000TPT with respect to the antenna. • Move the MR-9000TPT away from the receiver. • Plug the MR-9000TPT into a different outlet so that the MR-9000TPT and the receiver are on different branch circuits. If necessary, you should consult the dealer or an experienced radio/ television technician for additional suggestions. -
Page 5: Table Of Contents
2.2 NETWORK DESIGN GUIDELINES ... 2-6 2.3 SITE SELECTION GUIDELINES ... 2-6 CHAPTER 3 INSTALLING THE MR-9000TPT 3.1 INSTALLING THE MR-9000TPT ... 3-1 3.2 POWERING UP THE MR-9000TPT ... 3-3 CHAPTER 4 USING LANVIEW 4.1 LANVIEW INDICATORS ... 4-1 CONTENTS... - Page 6 CONTENTS...
-
Page 7: Chapter 1 Introduction
The MR-9000TPT Multiport Repeater can connect up to eight twisted pair segments to a network segment of the same or different media, or you can use the MR-9000TPT as a stand-alone repeater for up to eight twisted pair segments. The MR-9000TPT can •... -
Page 8: Getting Help
INTRODUCTION 1.2 GETTING HELP If you need additional support related to the MR-9000TPT, or if you have any comments, suggestions, or questions concerning this manual, contact Cabletron Systems Technical Support at Cabletron Systems P.O. Box 5005 Rochester, N.H. 03867-0505 Phone: (603) 332-9400... -
Page 9: Chapter 2 Specifications And Requirements
CHAPTER 2 SPECIFICATIONS AND REQUIREMENTS 2.1 SPECIFICATIONS Listed below are the electrical and physical specifications of the MR-9000TPT. Cabletron Systems reserves the right to change these specifications at any time without notice. General Specifications Start of packet delay times Twisted pair in to... -
Page 10: Interface (Port 1 - 8)
SPECIFICATIONS AND REQUIREMENTS Minimum packet repeated: FAULT protection: RJ-45 Interface (Port 1 - 8) Transmitter Bandwidth: Signal amplitude (balanced): Idle signal frequency: 1.0 MHz normal; 0.9 to 1.1 MHz worst Idle turn-on delay: Output impedance: Receiver Receive threshold: Data frequency: Common mode rejection ratio: Near end crosstalk:... -
Page 11: Port Pin Configuration
SPECIFICATIONS AND REQUIREMENTS RJ-45 Port Pin Configuration Pin 1 Pin 2 Pin 3 Pin 4 No Connection Pin 5 No Connection Pin 6 Pin 7 No Connection Pin 8 No Connection Figure 2-1. RJ-45 Pin out AUI Interface (Port 9) Frequency range: RX and CP pair input impedance differential:... -
Page 12: Aui Connector Pin Configuration
Into a 150 foot twisted pair cable: Into a 6 inch twisted pair cable: Bit error rate: Power Supply The MR-9000TPT power supply senses and automatically adapts to the input voltage and frequency. Input frequency: 120 volts nominal: 220 volts nominal: Output Voltage:... -
Page 13: Environmental Requirements
IEC, TUV, VDE class A. Meets FCC part 15, Class A limits. NOTE: It is the responsibility of the person who sells the system to which the MR-9000TPT will be a part of to ensure that the total system meets allowed limits of conducted and radiated emissions. -
Page 14: Network Design Guidelines
2.3 SITE SELECTION GUIDELINES Before you set up your MR-9000TPT, be sure the selected site meets the following guidelines. • The surface area must be at least 21 inches wide, 18 inches deep and 6 inches high. -
Page 15: Chapter 3 Installing The Mr-9000Tpt
The bracket, screws, and cable ties are used to support the cables. 3.1 INSTALLING THE MR-9000TPT Installing the MR-9000TPT is a simple process of attaching the cable support bar, plugging in the AUI and twisted pair cables to the appropriate ports, and then connecting the repeater to an AC power source. - Page 16 INSTALLING THE MR-9000TPT Figure 3-1. Installation 5. Attach the cable segment(s) to the RJ-45 ports 1 - 8. 6. Plug the power cord into the power receptacle located next to the On/Off switch (4) on the back of the repeater.
-
Page 17: Powering Up The Mr-9000Tpt
3.2 POWERING UP THE MR-9000TPT When you turn on the MR-9000TPT, two LEDs on the front panel should illuminate: • The PWR LED (1, Fig. 3-2) indicates that the repeater is receiving power. • The XCVR PWR LED (2) indicates that the repeater is providing power to the transceiver connected to the repeater’s... - Page 18 INSTALLING THE MR-9000TPT Page 3-4...
-
Page 19: Chapter 4 Using Lanview
This section explains each of the MR-9000TPT LANVIEW LEDs. Power (PWR) When lit, this green LED indicates that the MR-9000TPT is receiving power. The On/Off switch is located on the back of the unit, next to the power cord connection. - Page 20 USING LANVIEW Receive (RECEIVE) This yellow LED flashes when the repeater port receives data from the network. The LED flash is pulse stretched for viewing effect. Collision (COLLISION) This red LED flashes when the repeater port detects a collision condition or a jabber packet on the network. The flash frequency may increase as network traffic increases since more collisions are likely to occur.
-
Page 21: Power Supply Cord
POWER SUPPLY CORD The mains cord used with this equipment must be a 2 conductor plus ground type with minimum 0.75 mm square conductors and must incorporate a standard IEC appliance coupler on one end and a mains plug on the other end which is suitable for the use and application of the product and that is approved for use in the country of application.
