- Page 1 INTELLIGENT REPEATER MODULE (IRM) INSTALLATION GUIDE CABLETRON SYSTEMS, P.O. Box 5005, Rocheter, NH 03867-5005...
- Page 3 Printed in the United States of America Order number: 9030033-03 July 91 LANVIEW is a registered trademark of Cabletron Systems, Inc. SPECTRUM, Remote LANVIEW/Windows, IRM, IRM/LM, MMAC-8, MMAC-8FNB, MMAC-5FNB, MMAC-3, MMAC-3FNB, PSM, PSM-R, MMAC-5PSM, THN-MIM, and LAN-MD are trademarks of Cabletron Systems, Inc.
-
Page 4: Fcc Notice
NOTICE This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: This equipment uses and generates and can radiate radio frequency energy and if not installed properly and used in accordance with the instruction manual, may cause interference to radio communications. -
Page 5: Table Of Contents
3.2.2 Setting the Default Setting Jumper (JP4)...3-3 3.2.3 Setting the THN-MIM Jumper (JP2) ...3-3 INSTALLING THE IRM...3-4 CONNECTING THE IRM TO THE NETWORK ...3-5 3.4.1 Connecting to the Network Via the AUI Port...3-5 3.4.2 Connecting to the Network Via the BNC Port...3-8 CHAPTER 4 TESTING AND LANVIEW INSTALLATION CHECK-OUT ...4-1... - Page 6 CONTENTS...
-
Page 7: Chapter 1 Introduction
INTRODUCTION Welcome to the Cabletron Systems Intelligent Repeater Module (IRM™) Installation Guide. We have designed this manual to serve as a simple installation and reference guide for the IRM, and to explain the capabilities and special features of the IRM. The IRM provides an IEEE 802.3 Repeater with network management capabilities for use in a... -
Page 8: Getting Help
Thin-Net Segment to the IRM. A standard 9 pin RS232 console port that allows you to access IRM/LM and a Reset Switch to initialize the IRM's processor are also built into the IRM's front panel. The IRM also incorporates Cabletron Systems' LANVIEW Status Monitoring and Diagnostics Systems. -
Page 9: Lanview Leds
FAIL 15 Pin DB-15 AUI Ports RESET Figure 1-1 Intelligent Repeater Module (IRM) LANVIEW LEDs 9 Pin RS232 Port Reset Switch BNC Port INTRODUCTION... -
Page 10: Repeater Functionality
Cabletron Systems' IRM/LM (Local Management) The IRM's network management capabilities provide the necessary management tools for the IRM to operate at its full capacity. Your ability to set up parameters within these network management capabilities ensures optimal performance of the IRM, and, hence, the network. -
Page 11: Related Manuals
INTRODUCTION For further specific information, refer to the applicable Network Management Package User's Manual. RELATED MANUALS The manuals listed below should be used to supplement the procedures and other technical data provided in this manual. The procedures will be referenced where appropriate, but will not be repeated. Cabletron Systems' LAN-MD User's Manual. - Page 12 INTRODUCTION...
-
Page 13: Chapter 2 Network Requirements/Specifications
2.1.1 AUI Port Requirements When connecting a network segment to the IRM, via a transceiver and an AUI Cable, the following requirements must be met: • Transceiver - The transceiver to which the IRM will be connected must meet Ethernet Version 2, or IEEE 802.3 standards. -
Page 14: Operating Specification
Length - The thin-net segment must be no longer than 185 meters. • Terminations - A 50 ohm terminator must be connected to the far ends of each thin-net segment. The BNC port on the IRM is not internally terminated. •... -
Page 15: Front Panel Indicators
When lit, this LED indicates that a problem has been detected with the IRM (red indicator). When lit, this LED indicates the IRM is detecting a collision signal from one of the segments connected to the MMAC (red indicator). -
Page 16: Console Port
6 Power Return 7 No Connection 8 Logic Ref. Connector Shell: When lit, this LED indicates the IRM is repeating a data packet received from the segment connected to the port (yellow indicator). When lit, this LED indicates that the... -
Page 17: Environmental Requirements
IEC, TW, VDE class A. Meets FCC part 15, Class A limits. WARNING: It is the responsibility of the person who sells the system of which the IRM will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions. -
Page 18: Physical Properties
NETWORK REQUIREMENTS/SPECIFICATIONS PHYSICAL PROPERTIES Dimensions: Weight: Unit: Shipping: 34.07D x 29.21H x 2.54W cm. (13.4D x 11.5H x 1.0 W inches) 0.85 kg (1.95 lbs) 1.34 kg (2.95 lbs) -
Page 19: Chapter 3 Installing The Irm
Cabletron Systems' Technical Support immediately. SETTING THE IRM JUMPERS On the IRM are five jumpers (See Figure 3-1). Three of the jumpers, JP2, JP4, and JP5, can be changed. JP1 is for Cabletron Systems use only and should not be changed from its default positions. JP3 is not used. - Page 20 Jumper Figure 3-1 IRM Jumper Locations will be saved if power should fail to the MMAC, or if the IRM is removed from the MMAC. When set to the disabled position, all parameters entered into the IRM will be lost after approximately 10 minutes.
-
Page 21: Setting The Default Setting Jumper (Jp4)
Setting the Default Setting Jumper (JP4) The repeater module is shipped with JP4 in its normal operating position, over pins 1 and 2, and should not require setting as part of the IRM installation. However, when necessary, the IRM's network management parameters can be set to their default values using the Default Setting Jumper (JP4, Fig 3-1). -
Page 22: Installing The Irm
Install the IRM into the MMAC as follows: 1. Power off the MMAC. 2. Slide the IRM (3, Fig. 3-2) into Slot 1(4) of the MMAC's (1) card cage. Be sure that the card is in the top and bottom slot guides. -
Page 23: Connecting The Irm To The Network
To connect to the network via either AUI Port: CAUTION: Be sure to disable the SQE test function on the transceiver will be connecting to the IRM's AUI Port. Failure to do so will result in improper operation of the IRM. Refer to the applicable transceiver manual. -
Page 24: Lanview Leds
INSTALLING THE IRM FAIL RESET Figure 3-3 LANVIEW LEDs LANVIEW LEDs... - Page 25 Figure 3-4 Connecting to the AUI Port. View A 1. Thin-Net Segment 2. Tee Connector 3. Thin-Net Segment Figure 3-5 Connecting to the BNC Port INSTALLING THE IRM 1. Slide Latch 2. AUI Port 3. AUI Connector View B 4. BNC Port...
-
Page 26: Connecting To The Network Via The Bnc Port
3. Attach the male connector on the AUI cable (3, Fig. 3-4) to the AUI port (2) on the IRM. 4. Move the slide latch (1) on the AUI Port to secure it to the lock post on the AUI connector. -
Page 27: Chapter 4 Testing And Lanview
IRM are also provided. INSTALLATION CHECK-OUT After the IRM is connected to the network, verify that packets can be passed between the two Ethernet network segments via the IRM. Two Ethernet node testers capable of generating valid data packets, such as Cabletron Systems' LAN-MDs™, are required for this procedure. -
Page 28: Using Lanview
FAlL (FAIL) LED When this red LED is lit, the CPU has detected a problem with the IRM. COLLISION PRESENT (CLN) LED When this red LED is flashing, this indicates that a collision is being detected on one of the segments connected to the MMAC. - Page 29 FAIL Reset Switch RESET Figure 4-1 LANVIEW LED’s TESTING AND LANVIEW LANVIEW LEDs...
-
Page 30: Using The Reset Switch
USING THE RESET SWITCH The IRM incorporates a recessed Reset Switch, located between the AUI ports. See Figure 4-1. This Reset Switch will initialize the IRM processor. This will not initialize the Battery backed-up RAM where your network management parameters are stored.
