PORTABLE STEREO FM RADIO WITH
CD-PLAYER AND CASSETTE
SCD-420
INSTRUCTION MANUAL
For information and support, www.lenco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCD-420 and is the answer not in the manual?

Questions and answers

Related Manuals for LENCO SCD-420

Summary of Contents for LENCO SCD-420

  • Page 1 PORTABLE STEREO FM RADIO WITH CD-PLAYER AND CASSETTE SCD-420 INSTRUCTION MANUAL For information and support, www.lenco.com...

  • Page 2: Class 1 Laser Product

    WARNING CLASS 1 LASER PRODUCT CAUTION CLASS 1 LASER PRODUCT INVISIBLE LASER RADIATION APPAREIL Á LASER DE CLASSE 1 WHEN OPEN AND INTERLOCKS PRODUCTO LASER DE CLASE 1 DEFEATED. AVOID EXPOSURE TO BEAM This product contains a low power laser device. Warning: Do not touch the lens.

  • Page 3: Location Of Controls

    LOCATION OF CONTROLS 1. VOLUME CONTROL 2. FUNCTION SWITCH 3. CARRYING HANDLE 4. CASSETTE PAUSE 5. CASSETTE STOP/EJECT 6. CASSETTE F.FWD 7. CD DOOR 8. CASSETTE REWIND 9. CASSETTE PLAY 10. OPEN / CLOSE CD DOOR AREA LCD DISPLAY 12. TUNING CONTROL 13.

  • Page 4: Clock Adjustment

    TURN ON / OFF THE SYSTEM Press the STANDBY button to turn the audio on. To change the audio mode between CD, RADIO AND TAPE , set the FUNCTION switch while the power is on. The audio mode is displayed. Turn off the unit by pressing the STANDBY button. " OFF " word will be shown on the display and then resume the current time. STANDBY CLOCK ADJUSTMENT The clock is displayed on LCD display at standby mode. 1. Press and hold the PROG / CLOCK-ADJ./PLAY MODE button, 2. Press the NEXT or BACK to select 12 hours or 24 hours display.

  • Page 5: Compact Disc Playback

    FOR BETTER RECEPTION AFTER LISTENING Turn off the unit by pressing the STANDBY button. COMPACT DISC PLAYBACK Insert a disc with the label side facing up. 1 . Turn on the unit by Close the disc holder. pressing the The disc will rotate and STANDBY button. the total tracks of the disc STANDBY will show on the display. 2 . Set to CD FUNCTION Press the PLAY/PAUSE button. Track number "01" & the symbol " " will be shown during normal compact disc playback. Open the disc holder by pushing the CD door open area.

  • Page 6: Play Mode

    REPEAT , REPEAT ALL AND MIX PLAYBACK Press PLAY MODE button during CD playback. CD plays with a single track repeat, all tracks repeat or randomly. PLAY MODE FOR NORMAL COMPACT DISC PLAYBACK Mode sequence REPEAT >> REPEAT ALL >> MIX >> CLEAR. During Mix mode, During Repeat 1 mode, display shows display shows LCD display During Repeat 2 mode, display shows LCD display PROGRAMMED PLAYBACK PROGRAMMED PLAYBACK Press the " PLAY/PAUSE " button to resume FOR NORMAL COMPACT DISC PLAYBACK programmed playback.

  • Page 7: Tape Playback

    TAPE PLAYBACK Set to TAPE Press the PLAY button. FUNCTION PLAY TAPE 2 . Insert the cassette. TO STOP PLAYBACK Press the STOP / EJECT button. TO INTERRUPT PLAYBACK Press the PAUSE button. To resume play, press the PAUSE button again. TO FAST WIND Press the REWIND or F.FWD button. Press the STOP/EJECT button to stop winding at the desired position.

  • Page 8: Specifications

    Power consumption: Speaker: 3" 8 OHM Phones jack: 3.5MM Power source: AC : 230V~50Hz DC : 12V ( 8 x 1.5V LR14/"C"/UM2 ) Dimensions: 288(L) x 238(D) x 155(H)mm Weight 2.2 KGS Due to continuing improvement, the features and the design are subject to change without notice. Guarantee Lenco offers service and warranty in accordance with the European law, which means that in case of repairs (both during and after the warranty period) you should contact your local dealer. Important note: It is not possible to send products that need repairs to Lenco directly. Important note: If this unit is opened or accessed by a non-official service center in any way, the warranty expires. This device is not suitable for professional use. In case of professional use, all warranty obligations of the manufacturer will be voided. Disclaimer Updates to Firmware and/or hardware components are made regularly. Therefore some of the instruction, specifications and pictures in this documentation may differ slightly from your particular situation. All items described in this guide for illustration purposes only and may not apply to particular situation. No legal right or entitlements may be obtained from the description made in this manual. Disposal of the Old Device This symbol indicates that the relevant electrical product or battery should not be disposed of as general household waste in Europe. To ensure the correct waste treatment of the product and battery, please dispose them in accordance to any applicable local laws of requirement for disposal of electrical equipment or batteries. In so doing, you will help to conserve natural resources and improve standards of environmental protection in treatment and disposal of electrical waste (Waste Electrical and Electronic Equipment Directive). CE Marking Products with the CE marking comply with the EMC Directive (2014/30/EU) and the Low Voltage Directive (2014/35/EU) issued by the Commission of the European Community.
