North American AR151 Operating Instructions & Parts Manual

AR North America Operating Instructions & Parts Manual
AR North America Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Hose Reel
Description
This AR North America heavy gauge steel construction hose reel, bolt on design,
maximum pressure 5000 PSI, handles 250 feet of 3/8" pressure hose. Connect inlet
hose from washer to 3/8" inlet on the base. Connect outlet hose to the 3/8" F
swivel.
Specifications
AR151
PSI 5000
Hose Length 250'
Form Reel250
AR151
AR151
Figure 1 - AR151
