- Page 1 PC6 OSCILLATOR Operation / Maintenance Manual SERIAL NO. ___________________ 4/10/2006 – MPC6...
- Page 2 CONTENTS UTILITIES / HOOK-UP ....................3 OSCILLATOR CYCLE RATE ..................5 ADJUSTMENT INSTRUCTIONS ............... 5 PC6 OSCILLATOR OPERATION / MAINTENANCE MANUAL CONTENTS...
- Page 3 UTILITIES / HOOK-UP 3/8” Dia. (9mm) supply tube (Use in-line 10µ air filter). Air Inlet: 20-60 psig (Model 110, 610) (1.4 – 4.1 bar) and 20-80 psig Air Supply: (Maxim 25, 50) (1.4 – 5.5 bar) clean dry air or nitrogen (Refer to pump operation manual for maximum temperature/pressure chart).
- Page 4 Figure 1-2 WARNING: Particulate, water and oils in the air supply can damage the oscillator. PAGE 4 PC6 OSCILLATOR OPERATION / MAINTENANCE MANUAL...
-
Page 5: Adjustment Instructions
OSCILLATOR CYCLE RATE Applications with low flow or highly viscous fluid may require a slower cycle rate for increased efficiency. A slower cycle rate will also decrease air consumption. ADJUSTMENT INSTRUCTIONS Pumping capacity is a function of air supply pressure and volume, suction head, suction line restrictions, discharge head, discharge line restriction, and fluid specific gravity and viscosity.
