Installation Manual
for MEMC Silvantis 60 cell Photovoltaic Modules
Product List:
MEMC-M235AMA, MEMC-M240AMA, MEMC-M245AMA, MEMC-M250AMA, MEMC-M255AMA,
MEMC-M240LMA, MEMC-M250LMA, MEMC-M260LMA, MEMC-M240AMC, MEMC-M245AMC,
MEMC-M250AMC, MEMC-M255AMC, MEMC-M260AMC,
MEMC-M240LMC, MEMC-M250LMC, MEMC-M260LMC
© Copyright 2012 MEMC Electronic Material
Advertisement
Table of Contents
Related Manuals for MEMC SunEdison MEMC-M235AMA
Summary of Contents for MEMC SunEdison MEMC-M235AMA
- Page 1 Installation Manual for MEMC Silvantis 60 cell Photovoltaic Modules Product List: MEMC-M235AMA, MEMC-M240AMA, MEMC-M245AMA, MEMC-M250AMA, MEMC-M255AMA, MEMC-M240LMA, MEMC-M250LMA, MEMC-M260LMA, MEMC-M240AMC, MEMC-M245AMC, MEMC-M250AMC, MEMC-M255AMC, MEMC-M260AMC, MEMC-M240LMC, MEMC-M250LMC, MEMC-M260LMC © Copyright 2012 MEMC Electronic Material...
-
Page 2: Table Of Contents
Installation Manual: MEMC Silvantis 60 cell PV Modules 2 of 15 Table of Contents 1.0 InTroduCTIon ..............................2.0 PhoTovoLTAIC ModuLES ProduCT CodE ..................3.0 ModuLE ovErvIEw ..................................................3.1 STorAgE, unPACkIng, And hAndLIng ..................................3.2 SAfETy ................................3.3 MAInTEnAnCE 4.0 MEChAnICAL InSTALLATIon ......................... -
Page 3: Introduction
MEMC photovoltaic module products, please contact MEMC. 2.0 PhoTovoLTAIC ModuLES ProduCT CodE This guide is to be used for MEMC Silvantis 60 cell photovoltaic (Pv) module installation. Please refer to the following module numbers before using the guide:... -
Page 4: Safety
• do not wear rings, jewelry, watches, or other metallic items while working with photovoltaic modules.eping. 3.3 MAInTEnAnCE Check modules, glass, and frames for damage. regularly inspect all MEMC Silvantis Solar Modules for safe electrical connections, sound mechanical connections, and freedom from shading and corrosion. If dirt or debris buildup becomes excessive, periodically clean the glass only with a soft cloth using mild, non-abrasive detergent and water. -
Page 5: Mechanical Installation
• Mechanical structures should not contact the module backsheet under any expected load conditions • Consider the following factors during system design, which will influence performance: MEMC solar modules produce the most power when they are pointed directly at the sun, and should be tilted for optimum system performance. - Page 6 Installation Manual: MEMC Silvantis 60 cell PV Modules 6 of 15 4.2A MounTIng ConfIgurATIonS uSIng BoLT MounT or CLAMP MounT oPTIonS BoLT MounT CLAMP MounT MounTIng ConfIgurATIonS LoAd PArAMETErS LoCATIonS LoCATIonS PErPEndICuLAr MounTIng Maximum (CASES 1 & 2) rear Load:...
-
Page 7: Module Installation Using Center Mounting Brackets
• Module clamps for center mounting must be based on MEMC approved extrusion and hardware. • for module loads higher than 2400 Pa, module clamps and hardware must be pre-approved by MEMC. 4.4 ModuLE InSTALLATIon uSIng ShArEd rAILS (M240/250/260LMA And M240/250/260LMC SPECIfIC) -
Page 8: Mechanical Installation Warnings
• Electrical characteristics are within plus or minus 5% of rated values for Isc, voc, Impp and vmpp. Modules may operate under conditions which may be significantly different than STC. MEMC suggests multiplying specified ratings by a minimum of 1.25* or more when specifying the system and balance of system components. 1.25* refer to local codes before planning and design of the system. -
Page 9: Grounding
• There is no limit to the maximum number of series strings that can be combined in parallel. however, when doing so, each string must include overcurrent protection with a maximum rating of 15A. MEMC recommends the use of dC rated fuses or overcurrent protection devices with the appropriate maximum voltage rating. -
Page 10: Electrical Installation Warnings
MEMC in writing, or if the product is installed in an environment for which it was not designed. MEMC shall not be liable for special, indirect, consequential, contingent or incidental damages related to or arising from the installation or use of the product by purchaser under any circumstances. -
Page 11: Mechanical And Electrical Parameters And Specifications
Temperature coefficients may vary by ± 10% Temperature coefficients may vary by ± 10% *refer 240w solar module and MEMC Silvantis 250w module data sheets for specific *refer 240w solar module and MEMC Silvantis 250w module data sheets for specific... - Page 12 Installation Manual: MEMC Silvantis 60 cell PV Modules 12 of 15 7.0 MEChAnICAL And ELECTrICAL PArAMETErS And SPECIfICATIonS Modules with corner cap and anti-reflective coating: Modules with anti-reflective coating: MEMC-M240/250/260LMC MEMC-M240/245/250/255/260AMC PhySICAL PArAMETErS PhySICAL PArAMETErS 1,658 x 990 x 50...
-
Page 13: Appendix
Installation Manual: MEMC Silvantis 60 cell PV Modules 13 of 15 8.0 APPEndIx 8.1 ModuLE dETAILS dimension InCh dimension InCh dimension InCh Module dimensions Mounting hole Spacing Cable Length for AMA and AMC 37.0 39.0 1,000 39.4 1,608 63.3 1,658 65.3... -
Page 14: Module Illustrations
Installation Manual: MEMC Silvantis 60 cell PV Modules 14 of 15 8.0 APPEndIx 8.1A ModuLE dETAILS (M240/250/260LMA And M240/250/260LMC SPECIfIC) — dIMEnSIonS: [InCh] MM Side view front view 8.2 ModuLE ILLuSTrATIonS Center Mount option Bolt Stack details © Copyright 2012 MEMC Electronic Material... -
Page 15: Pre-Mounted Cables And Connectors
Information contained herein may not be revealed or disclosed to unauthorized persons or sent outside MEMC without prior authorization. Match printed version to documentation database. MEMC Electronic Materials, Inc. 501 Pearl drive (City of o’fallon) St. Peters, Mo 63376 uSA | 1-636-474-5000 | www.sunedison.com | © Copyright 2012 MEMC Electronic Material...
