Page 1: Installation Manual
Installation Manual for MEMC Silvantis 72-cell Photovoltaic Modules P290 M320 Silvantis Silvantis... -
Page 2: Table Of Contents
Installation Manual: MEMC Silvantis P290 | M320 1 of 13 Table of Contents 1.0 INTRODUCTION ..........................2.0 PHOTOVOLTAIC MODULES PRODUCT CODE ................ 3.0 MODULE OVERVIEW ..................................................3.1 MAINTENANCE ..................3.2 STORAGE, UNPACKING, AND HANDLING ............................3.3 SAFETY 4.0 MECHANICAL INSTALLATION ..................... -
Page 3: Introduction
2 of 13 1.0 INTRODUCTION The purpose of this guide is to provide general information regarding the proper installation and handling of MEMC photovoltaic modules that serve residential, commercial, and industrial segments. System design, construction, and commissioning should be performed by qualified personnel only. -
Page 4: Storage, Unpacking, And Handling
Installation Manual: MEMC Silvantis P290 | M320 3 of 13 3.2 STORAGE, UNPACKING, AND HANDLING • Packaged modules must be stored in a dry and ventilated area. • Packaged modules must not be exposed to rain, snow, hail or other environmental conditions that may compromise the packaging material and the modules. -
Page 5: Mechanical Installation
• Mechanical structures should not contact the module backsheet under any expected load conditions • Consider the following factors during system design, which will influence performance: MEMC solar modules produce the most power when they are pointed directly at the sun, and should be tilted for optimum system performance. - Page 6 Installation Manual: MEMC Silvantis P290 | M320 5 of 13 • Precaution should be taken to avoid damage to the glass surface with or without anti-reflective coating due to improper handling during installation. • Mechanical structures should not contact the module backsheet under any expected load conditions.
-
Page 7: Electrical Installation
• There is no limit to the maximum number of series strings that can be combined in parallel. However, when doing so, each string must include overcurrent protection with a maximum rating of 15A. MEMC recommends the use of DC rated fuses or overcurrent protection devices with the appropriate maximum voltage rating. -
Page 8: Grounding
• The module junction box should not be opened or modified in any way in the field. • Additional grounding holes may be added only with the express written consent of MEMC. New grounding holes must be © Copyright 2012 MEMC Electronic Material... -
Page 9: Disclaimer Of Liability
MEMC in writing, or if the product is installed in an environment for which it was not designed. MEMC shall not be liable for special, indirect, consequential, contingent or incidental damages related to or arising from the installation or use of the product by purchaser under any circumstances. -
Page 10: Mechanical And Electrical Parameters And Specifications
Installation Manual: MEMC Silvantis P290 | M320 9 of 13 7.0 MECHANICAL AND ELECTRICAL PARAMETERS AND SPECIFICATIONS 7.1 SILVANTIS P290 DETAILS P280BCC P285BCC P290BCC P295BCC P300BCC P305BCC Silvantis P290 Multi-crystalline Modules P280BMC P285BMC P290BMC P295BMC P300BMC P305BMC TEMPERATURE COEFFICIENTS AND PARAMETERS Nominal Operating Cell Temperature (NOCT) (°C) - Page 11 Installation Manual: MEMC Silvantis P290 | M320 10 of 13 7.0 MECHANICAL AND ELECTRICAL PARAMETERS AND SPECIFICATIONS 7.1 SILVANTIS M320 DETAILS M305BCC M310BCC M315BCC M320BCC M325BCC M330BCC Silvantis M320 Mono-crystalline Modules M305BMC M310BMC M315BMC M320BMC M325BMC M330BMC TEMPERATURE COEFFICIENTS ELECTRICAL CHARACTERISTICS AND PARAMETERS 48.0 ±...
-
Page 12: Module Details
Installation Manual: MEMC Silvantis P290 | M320 11 of 13 IEC 61215, IEC61730, CE, UL 1730, and Safety Class II certifications ensure that MEMC solar products operate safely and comply with global electrical, performance, reliability, and fire safety codes. THE ENGINEERING DRAWING SHOWN BELONGS TO THE FOLLOWING LISTED SILVANTIS MODULE SERIES: P290 &... -
Page 13: Appendix
Installation Manual: MEMC Silvantis P290 | M320 12 of 13 8.0 APPENDIX 8.2 MODULE ILLUSTRATIONS Center Mount Option Bolt Stack Details 8.3 CLAMP DRAWINGS Dimension INCH Module Clip Dimensions 6.35 Minimum Support Dimensions © Copyright 2012 MEMC Electronic Material... -
Page 14: Pre-Mounted Cables And Connectors
© Copyright 2012 MEMC Electronic Material Controlled Document - MEMC Electronic Materials, Inc. Void if Printed or Electronically Duplicated. Information contained herein may not be revealed or disclosed to unauthorized persons or sent outside MEMC without prior authorization. Match printed version to documentation database.
