- Page 1 Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia Installation, Operation & Maintenance Manual BDS Series – Submersible Borehole Stainless Steel Pump...
- Page 2 Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia EXCLUSIVE SECURITY STICKERS All pumps & motors have exclusive designed hologram security sticker with unique serial number certifying that the said products are original and genuine produced by Stellar Pump Australia. To validate if product purchased is original &...
-
Page 3: Table Of Contents
------------------------------------------------------------------------------ Page 9 SECTION I: INTRODUCTION STELLAR BDS Series submersible borehole stainless steel pumps are designed for extreme high in head. The said series is made in stainless steel with built-in non return valve. Cost economical, space saving, high quality & wide series of applications in deep wells, thermal well, reservoir, canals &... -
Page 4: Section Ii: General Practice
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia SECTION II. GENERAL PRACTICE 1. Do not operate the pump without proper procedure of priming (pump volute flooded with water). 2. Do not operate the pump if water has sand sediment of more than 50g/m 3. -
Page 5: Section V: Installation
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia SECTION V. INSTALLATION 1. Deep well The well must be complied with necessary codes. b. Quality of water inside the well must be checked, free from any excess mud or sand to avoid overheat of motor and damaging the internal parts of the pump. -
Page 6: Section Vi: Operation Procedure
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia 4. Wiring Connections for Submersible Electric Motors Procedure of installation of submersible wires and cables for submersible electric motor shall be in accordance to related electrical code & local regulations. b. Submersible wire or cable sizes must be appropriate to Kilowatt (kw) or Horsepower (hp) rating of electric motor including voltage drop. -
Page 7: Section Vii: Maintenance Procedure
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia 3. Pump Stop Necessary valves & fittings are required to protect the pump from water hammer effects when stopping the operation. Please refer to plumbing and/or water system codes & local regulations for reference. -
Page 8: Section Viii: Spare Parts
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia SECTION VIII. SPARE PARTS 1. Recommended Spare Parts for BDS Submersible Borehole Stainless Steel Pump Intermittent duty *Item Description Impeller Strap * Refer to Section IX for reference Continuous operation *Item Description Impeller Strap... -
Page 9: Section X: Trouble Shooting
Installation, Operation and Maintenance (IOM) Manual Stellar Pump Australia SECTION X. TROUBLE SHOOTING Problems Causes Recommended Solutions No discharge flow 1. Trap air or leak at main riser 1. Remove trap air or repair column pipe leak. 2. Impeller clogged 2.
