Mustek DV5500 Getting Started

82-149-00060
DV5500 DOCK STATION
GETTING STARTED
Thank you for purchasing the Mustek DV 5500 Dock Station.
We have included this convenient Getting Started to help with the
basic operations.
HOW TO CONTACT US
Website:
http://www.mustek.com
Customer Service:
(General Info)
Email: cservices@mustek.com
Fax: (949) 788-3670
Technical Support
Email: tsupport@mustek.com
Phone: (949) 788-3600
Address:
15271 Barranca Parkway,
Irvine, CA 92618
PACKAGE CONTENTS
• Remote Control
• USB Cable
• AV Cable
• Getting Started
• Power Adapter
All manuals and user guides at all-guides.com
1 Product Tour
TV out
USB port
DC in jack
1
Turn off the power on your device.
2 Close the LCD screen on your device.
Place the device onto the Dock Station.
3
Be sure the rubber cushion is fi rmly sealed onto the Dock Station and
your device is facing the correct direction and steps on the socket of
the Dock Station.
4 Plug in the power adapter to the Dock station and connect the other
end to the wall outlet.
With the device attached, connect the USB cable to the USB port on the
5
Dock Station.
6 Connect the other end of USB cable to your computer.
7
Connection Socket
Print
E-mail
Sensor
Mass Storage/PC Cam
Power
Mass Storage
1 Press A to turn on the Dock Station. The default mode is Mass
1
Storage.
MAX Console or Easy Transfer will launch automatically according
to your Auto Launch Setting.
PC Cam
2
1 Press A to turn on the Dock Station.
3
2 Press B on the Dock Station.
Your default PC Cam application will launch automatically according
to your Auto Launch Setting.
E-mail
1 Press A to turn on the Dock Station.
4
2 Press C on the Dock Station.
A new E-mail will open up attaching the E-mail marked fi les
alongside. (A warning message will appear if your total size exceeds
2 MB)
A B
C D
