Inc.
Manual
Direct Therapy Device developed by:
umina
g
r
o
u
p

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TENDLITE and is the answer not in the manual?

Questions and answers

Related Manuals for Lumina TENDLITE

Summary of Contents for Lumina TENDLITE

  • Page 1 Inc. Manual Direct Therapy Device developed by: umina...
  • Page 3 QUICK START GUIDE Please also read the MANUAL before using your TENDLITE BOTTOM Holding the TOP UNSCREW the BOTTOM to access the battery compartment. Battery BOTTOM Poles Insert the Li-Ion Battery* provided on the battery compartment. - Positive Pole against the TOP...
  • Page 4 Button: ON/OFF/TIMER (60 seconds) Using the Button and Timer: - One Click to turn it ON and Start the first 1 minute Dose of Light. - Two Clicks subsequently to restart another dose of 1 minute. Repeat as needed, following the Dosage Chart below. Read General Usage and Dosage Guidelines (p.
  • Page 5 Simply treat your pain consistently with 3 quick treatments per day with the Tendlite, for up to 3 minutes each time per treatment spot. After 3 weeks of consistent red light therapy,...
  • Page 6 Tendlite time to provide optimal pain relief. After you have achieved maximum pain relief from your Tendlite, you may then consider slowly weaning yourself off of other medications or treatments. If you plan to reduce or stop a prescription medication, first consult with your physician.
  • Page 7 3) AVOIDING RE-INJURY OR AGGRAVATING A CHRONIC CONDITION. So you’re getting great pain relief from Tendlite and you want to go right back to all the things you couldn’t do while you were in pain, right? Remember, as good as you feel, you can easily re-injure yourself if you are not fully recovered from an acute injury.

  • Page 8: Table Of Contents

    2 | Indications of Use 6|Usage & Dosage 10.1 60-Day Money Back Guarantee Guidelines 10.2 1-YEAR Limited Warran- 3 | Medical Precautions ty on the TENDLITE® Device 6.1 Dosage Chart 10.3 5-YEAR LED Bulb Limited 7 |Troubleshooting Warranty 3.1 Contraindications 10.4 Warranty Steps 3.2 Other Warnings &...

  • Page 9: Introduction

    LED therapy. This device is designed to alleviate pain for certain indications. Please observe all safety precau- tions. Tendlite® Medical Device is FDA cleared under number K-100213 Class Please read the entire manual before operating the unit. 1.1 INCLUDED IN THIS PACKAGE •...

  • Page 10: Charging The Battery

    Rechargeable batteries need to be replaced over time. This time varies depending on storage, time and level of usage. When to charge: Charge the battery if your Tendlite is flickering during use, no longer has a strong beam of light or the timer is malfunctioning.

  • Page 11: Indications Of Use

    INDICATIONS OF USE Temporary relief of minor muscle and joint pain, arthritis and muscle spasm, relieving stiffness, promoting relaxation of muscle tissue, and to temporarily increase local blood circulation where heat is indicated. MEDICAL PRECAUTIONS 3.1 CONTRAINDICTIONS • Pregnancy - This device has not been tested for use by pregnant wom- en, infants, toddlers or children under the age of 13.

  • Page 12: Other Warnings & Precautions

    • Fever (body temperature higher than 100.4 F/38 C) • Do not treat body areas near a pacemaker. If you have a pacemaker consult your physician. (See F.A.Q. section of this manual) • If you have light triggered seizures 3.2 OTHER WARNINGS AND PRECAUTIONS •...
  • Page 13 • Wearing protective glasses over the eyes is recommended to prevent sensitivity or discomfort from intense light. This is an extra safety precaution for the eyes. Never stare directly into the light of the unit. • Do not treat near the eyes. •...
  • Page 14 • The unit is not to be used by a person who is woozy, under the infulence of drugs or alcohol or in any way at risk of falling asleep or losing consciousness while operating the unit. • Do not leave small children unattened with the device •...

  • Page 15: Safety Precautions

    • Do not stare directly at the light. It can be painful for sensitive eyes. • The Tendlite® device is made of electronic circuitry. Great care should be exercised when using, storing and carrying the device. • Do not lay unit (with power On) flat onto a plastic, wood or other heat sensitive surface.
  • Page 16 18650 Li-Ion Batteries. • ATTENTION: Do not use any other 18650 Li-Ion Battery than the one rated 3000mAh 3.7V. Another battery might damage the electronic circuit of the device by overpow- ering it. Find extra batteries for sale at www.tendlite.com/batteries...

  • Page 17: Directions For Use

    • With the unit pointed away from your eyes, turn the ON/OFF switch to ON position. The unit has a 1 minute timer. The Tendlite’s timer will provide a one (1x) 1 minute dose of light before going off automati- cally.

  • Page 18: Directions Of Use On Joints

    (3 doses). Then proceed to any additional spots and repeat the regimen. See DOS- AGE CHART page 24. • For large joints, it may be necessary to treat the entire joint area by treating it in sections. Treat 1 section at a time, by holding the Tendlite steady in place for 1 to...
  • Page 19 • Allow a day for full impact of treatment to begin. For chronic pain, repeat treatment 2 to 3 times daily for at least 3 weeks. Simple and easy use of your Tendlite®...

  • Page 20: Session Frequency

    UTE, after every 10 minutes ON. This will keep the unit from overheating. 5.3 TREATMENT PERIOD For best results, use the Tendlite® Device every day for three weeks, twice or three times per day from 1 minute (1 dose) to 3 minutes (3 doses) cycles per use. Many peo- ple start getting pain relief almost immediately and others in just a few days.

  • Page 21: Usage & Dosage Guidelines

    USAGE & DOSAGE GUIDELINES The TENDLITE® is pre-programmed with a 1 minute timer. It starts once you turn the device ON. The light goes off automatically after one minute. This is the minimum DOSE of the THERAPEUTIC LIGHT necessary per treatment spot*.
  • Page 22 NOTE: After the 1st dose, all subsequent doses are going to require 2 clicks: 1st click turns OFF the device and 2nd click turns ON again for one more minute. For example, if you are treating pain around the Carpal Tunnel area and your pain level is Average,you would shine the light for 2 one minute sessions per treatment spot of the wrist/ carpal tunnel area.
  • Page 23 Start by treating the back of your Next treat the front as well (another Continue the regiment along other Wrist (Carpal Canal) for 2 minutes 2 min.). painful spots of the wrist, forearm and upper arm as needed. *The Treatment Spot is an area covered by the red light beam. A small joint i.e. knuckle of a finger should have only one treatment spot because the light shines over the entire affected joint.
  • Page 24 Conversely, a knee may have several treatment spots, as the light will not cover the entire knee joint at one angle. You may need to position the light over 5 treatment spots or more to cover the entire affected area of injury.

  • Page 25: Dosage Chart

    Use the Dosage Chart below to find the best Dosage to treat your injury. Dosage Chart PAIN LEVEL Light Pain Average Pain Deep Pain 1 DOSE DOSAGE 1 DOSE 2 DOSES 3 DOSES DOSAGE Per Treatment Spot 1 min. per spot 2 mins.

  • Page 26: Troubleshooting

    • Is the power switch in ON position? Press the ON/OFF button to see if the device shuts off. If none of these remedies corrects the problem, contact customer sup- port at support@tendlite.com for return authorization and a customer support representative will contact you with instructions.

  • Page 27: Cleaning & Disinfecting

    This unit has no customer serviceable parts. Opening the case or tamper- ing with the light will void the warranty. 8.1 CLEANING AND DISINFECTING Use only a soft dry cloth to clean the exterior. Never use an abrasive cleanser or submerge in water or any other liquid. This device cannot be sterilized by any liquid or autoclave method.

  • Page 28: Technical Specification

    WARNING: If the unit will not be used for an extended period of time (1 month +), remove the batteries from the unit to avoid their Corrosion. TECHNICAL SPECIFICATIONS • Model: 204 - Tendlite® Medical Device • Voltage: 3.7 Vdc at 811 mA input • Power: 3 Watt LED - 1500 mW output •...

  • Page 29: Guarantee & Warranty

    GUARANTEE & WARRANTY 10.1 60-DAY MONEY BACK GUARANTEE Returns with Lumina Group are EASY! If you are not 100% satisfied with your purchase, you can return your order for a Full Refund of your purchase price. We believe that in order to have the best possible shopping experience, our customers should not have to worry with hidden fees, special catches or exceptions.
  • Page 30 We understand that you need to use the device in order to try it, just please be careful, avoiding dings and scratches. The Tendlite is build to last, with a strong and robust stainless-steel body, dings are very unlikely.

  • Page 31: Ty On The Tendlite® Device

    We warrant our products to be free from defects in material and workmanship for a period of one year from the date of the original retail purchase from Lumina Group Inc. (www.tendlite.com) or an authorized TENDLITE® distributor. This warranty excludes batteries or chargers.
  • Page 32 Lumina Group will test and replace your high perfor- mance LED bulb for a new one. Effective Date: November 10, 2016 REPLACEMENT IS LUMINA’S SOLE WARRANTY OBLIGATION. INCIDENTAL AND CONSE- QUENTIAL DAMAGES ARE EXCLUDED. Some states do not allow the exclusion or limita- tion of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

  • Page 33: Warranty Steps

    10.4 WARRANTY STEPS Step 1 - Contact TENDLITE® Customer Service at contact@tendlite.com to request Return Authorization. Step 2 - After Return Authorization is verified - Return the product to the designated location along with proof of purchase. The repaired device will be mailed back to you.
  • Page 34 • Your receipt or proof-of-purchase is from a non-authorized dealer. At Lumina Group, we offer an outstanding risk-free guarantee and stand behind the products we sell with excellent warranties and services. However, purchasing TEND- LITE® products from an unauthorized reseller may exclude you from these valuable op- tions.

  • Page 35: Faq

    Charging Indication The LED indicator will be RED and/or BLINKING when charging is active. The LED will be GREEN if the battery has a full charge or if the charger/ battery is unplugged. How long to fully charge the battery? 10+ hours to charge from empty.
  • Page 36 It is always best to check on the TSA website for policy updates, but at the time this was printed, LED lights, like those used in the Tendlite, are allowed on flights as carry on or checked baggage. Spare/loose batteries are not allowed as checked baggage. They may only be checked if installed inside your TenDlite.
  • Page 37 Is the red light a laser light? No, it is Red LED light. What wavelength of light is this unit producing? The Tendlite uses 660nm wavelength. What is the recommended usage/dose? Up to 3 minutes per area 3 times per day.
  • Page 38 Can this red light therapy help with wrinkles or skin rejuvenation? The Tendlite device is intended to deliver relief of joint and muscle pain, relieving stiff- ness, promoting relaxation of the muscle tissue and to temporarily increase local blood circulation.
  • Page 39 GUÍA DE INICIO RÁPIDO Por favor lea también el MANUAL COMPLETO en Español Online www.tendlite.com/ Manual-Espanol BASE TOPE Mientras sostiene el TOPE, desenrosque la BASE para poder acceder al compartimento de la batería. Polos de TOPE BASE la Batería Inserte la Batería de Iones de Litio* Incluida en el compartimento.
  • Page 40 Botón ENCENDIDO/APAGADO/CRONÓMETRO (1 minuto). Para utilizar el Botón y el Cronómetro: - Una pulsación para ENCENDERLO y comenzar la primera dosis de 1 minuto de luz. - Dos pulsaciones subsiguientes para reiniciar otra dosis de un minuto. Repita tantas veces como necesite, de acuerdo a la Tabla de Dosifi- cación ilustrada abajo: Dolor Ligero Dolor Fuerte...
  • Page 41 Para mejores resultados, utilice la unidad Tendlite® todos los días durante al menos tres semanas, dos veces al día, en ciclos de entre 1 y 2 minutos en cada punto.
  • Page 44 KEEP IN TOUCH Email Address support@tendlite.com Lumina Group Inc. www.tendlite.com 4640 Cass St #99153 San Diego - CA 92169 United States...
