- Page 1 AL8C PASSTHROUGH WAREWASHER C/W HEAT RECOVERY UNIT OPERATOR MANUAL...
- Page 2 Information supplied in this manual is copyright. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical without the express permission of the author / publisher. 05/11/2018 Starline AL8C Operator Manual...
-
Page 3: Table Of Contents
Contents Contents Warning Contents 4. Safety Instructions Installation Diagram 6. Installation Instructions 8. Installation Checklist 9. Installation Troubleshooting 10. Operator Use Guide 11. Operator Troubleshooting 12. Schematic diagram 13. Accessories 14. Spare parts list 05/11/2018 Starline AL8C Operator Manual... -
Page 4: Warning
Installation and servicing must be carried out by a suitably qualified person in compliance with all local codes and standards including AS/NZS 3500.1. 05/11/2018 Starline AL8C Operator Manual... -
Page 5: Installation Diagram
Installation Diagram AL8C Installation Diagram • Part #: SAL80021 • Date: 25/09/2018 • Version: 05/11/2018 Starline AL8C Operator Manual... -
Page 6: Installation Instructions
• Flow rate: minimum 20 litres per minute. • Pressure: no greater than 350 kPa. NOTE: If above 350kPa fit pressure limiter valve (LPV). Do not use small diameter plastic supply lines. • Backflow prevention: Atmospheric Vacuum Breaker (AVB) fitted standard. 05/11/2018 Starline AL8C Operator Manual... - Page 7 We recommend consulting your local authority to ensure your site remains compliant. Installation Checklist • Complete attached Installation Checklist to ensure machine is installed and running correctly, and operator is familiar with operating procedures. 05/11/2018 Starline AL8C Operator Manual...
-
Page 8: Installation Checklist
USE LONG CYCLE WHERE POSSIBLE DRAINING THE MACHINE DRAIN THE MACHINE DAILY SHUT-DOWN AND DAILY CLEANING CHECK WASH ELEMENTS HAVE COOLED BEFORE CLEANING WEEKLY MAINTENANCE FULL MACHINE CLEAN INCLUDING WASH/RINSE ARMS PLANNED SERVICNG IMPORTANCE OF HAVING MACHINE SERVICED REGULARLY 05/11/2018 Starline AL8C Operator Manual... -
Page 9: Installation Troubleshooting
Cycle lengths can be adjusted by a qualified service agent accessing the WI- 200 Electronic timer. For adjustment instructions refer to the adjustment section of the service manual for this model or the WI-200 Timer service manual. 05/11/2018 Starline AL8C Operator Manual... -
Page 10: Operator Use Guide
Scrape and/or rinse trays, plates & glasses in cool water. Chemical Use a good quality non foaming commercial detergent and drying agent – do not use domestic detergents which will cause the wash tank to foam. 05/11/2018 Starline AL8C Operator Manual... -
Page 11: Operator Troubleshooting
** For issues that are likely due to poor water quality (scale building up, filters being required on other kitchen equipment etc.), we recommend you consult a local water specialist prior to calling in a dishwasher technician. IF PROBLEMS PERSIST CONTACT STARLINE SERVICE ON 0800 STARLINE 05/11/2018 Starline AL8C Operator Manual... -
Page 12: Schematic Diagram
Schematic Diagram AL8C Electronic Timer Schematic Diagram • Part #: 010186 • Date: 19/07/2018 • Version: 05/11/2018 Starline AL8C Operator Manual... -
Page 13: Accessories
Accessories AL8C Accessories • Part #: AL8C ACW • Date: 13/12/2017 • Version: 05/11/2018 Starline AL8C Operator Manual... - Page 14 • Lower & Upper Wash Connection Hose 6195 • Pressure Switch Hose 3067 150mm • Rinse Hose 600 60073 2000mm • Rinse Tee SS 600 60230 • Wash Pump Inlet Hose C200359 • Wash Pump Outlet Hose 61941 115mm 05/11/2018 Starline AL8C Operator Manual...
- Page 15 • Slip Ring Black Acetal 400 30191 • Temperature Gauge Probe Clamp 400 20066 • Wash Arm Assembly 400 10077 • Wash Arm Bush 190621C • Wash Arm End Screw 600 80072 • Wash Pump Inlet Filter 352 10026 05/11/2018 Starline AL8C Operator Manual...
- Page 16 Manufactured in New Zealand by Washtech Ltd. 414 Rosebank Road Avondale Auckland 1026 New Zealand PO Box 90548, Auckland 24HR Service 0800 Starline 09 829 0930 09 829 0935 E-mail info@washtech.co.nz www.starline.co.nz ISO9001 All Washtech products are designed and...
