INSTALLATION MANUAL
for frames:
Epson ELPMB50
Epson ELPMB51
Epson EB-L25000
Panasonic ET-RFD21
Panasonic FRAME-PF-PAN-21K
Panasonic ET-RFD91 / ET-RFD91-li
Panasonic FRAME-PF-PAN-13K
Only a quali ed installer should install this product.
Read these instructions carefully before installing this product.
The frames and projectors shown in the pictures of this manual only serve as an example.
The design of the frame and projector you are using may vary.
These installation instructions must always be handed over to the installing person.
2
3
3
4
4
5
Advertisement
Table of Contents
Related Manuals for Lang TH-SHORTY-150-8
Summary of Contents for Lang TH-SHORTY-150-8
-
Page 1: Table Of Contents
INSTALLATION MANUAL TH-SHORTY-150-8 Important safety notice Product description Maximum weight load information Installing the truss mount Adjustment options Dimensions & weight for frames: Epson ELPMB50 Epson ELPMB51 Epson EB-L25000 Panasonic ET-RFD21 Panasonic FRAME-PF-PAN-21K Panasonic ET-RFD91 / ET-RFD91-li Panasonic FRAME-PF-PAN-13K Only a quali ed installer should install this product. -
Page 2: Th-Shorty-150-8
Installation work should only be carried out by a quali ed technician. - If this product is not installed correctly, serious accidents may result. The maximum weight load for one TH-SHORTY-150-8 is 150 kg (330,69 lbs) - Do not exceed the maximum weight load in ceiling mount con gurations. -
Page 3: Product Description
Used for ceiling mount installations MAXIMUM WEIGHT LOAD INFORMATION Max. stacking possibilities for ceiling mounts using the following frames with correspondent projectors: Epson ELPMB51 Panasonic ET-RFD21 Epson ELPMB50 Epson EB-L25000 Frame Panasonic FRAME-PF-PAN-21K Panasonic ET-RFD91 / ET-RFD91-li Panasonic FRAME-PF-PAN-13K Truss mount TH-SHORTY-150-8... -
Page 4: Installing The Truss Mount
INSTALLING THE TRUSS MOUNT Place the truss mount on the rear side of the frame. Make sure that the 4 screws enter the 4 holes in the frame. Tighten the screws to secure the truss mount on the frame. ADJUSTMENT OPTIONS 360°... -
Page 5: Dimensions & Weight
DIMENSIONS & WEIGHT Weight: 8,80 kg... - Page 8 Made in Germany by Sager Metallbearbeitung www.lang-ag.com 03/17...
