Summary of Contents for Soho SO-255WUI
- Page 1 User Manual Smart Air Purifier with WiFi and AutoSenseAI SO-255WUI Helps Protect From: Allergens Pet Dander Smoke & Odours Bacteria...
-
Page 3: Table Of Contents
Auto Off Timer �������������������������������������������������������������������������������������������������������������������������������7 Child Lock ��������������������������������������������������������������������������������������������������������������������������������������7 Memory Function ���������������������������������������������������������������������������������������������������������������������������7 4� INITIAL SET UP OF YOUR SO-255WUI AIR PURIFIER ����������������������������������� 8 Installing the Filter ��������������������������������������������������������������������������������������������������������������������������8 Plugging The Power Adaptor ���������������������������������������������������������������������������������������������������������8 5� GETTING THE MOST FROM YOUR SO-255WUI AIR PURIFIER���������������������� 8 6�... -
Page 4: Important Safety And Operation Instructions
3. This appliance is ONLY to be used with the power adaptor provided with the appliance� 4. DO NOT remove the power adaptor from the power socket until the SO-255WUI Air Purifier has been turned off� 5. DO NOT remove the power adaptor from the power socket by pulling the cord�... - Page 5 23. DO NOT block or cover the air inlets or outlets with laundry, clothes, curtains, etc� 24. The SO-255WUI Air Purifier can be placed on the floor or on a dry, stable, level surface at least 50cm away from walls, curtains or other appliances�...
-
Page 6: Specifications
2�8 Power Adaptor for SO-255WUI Input: 110-240V~,50/60Hz, 0�8A Output: 24V =, 1500mA Model: GA-0362401500A 2. GETTING TO KNOW YOUR SO-255WUI AIR PURIFIER Control Panel 2. 360° Air Inlet 3. DC IN Port for Power Adaptor 4. Air Outlet Grille 5. Air Quality Indicator 6. -
Page 7: Air Quality Indicator
5 seconds to reset the filter� AUTO OFF TIMER Choose a preset time and start the count down to zero� This is when the SO-255WUI Air Purifier will go into standby mode� CHILD LOCK Turn on CHILD LOCK mode to stop unintentional change of functions by screen touch�... -
Page 8: Initial Set Up Of Your So-255Wui Air Purifier
LOCK the packaging� cover� *After installing the filter for the first time, please refer to “Operating Your SO-255WUI Air Purifier” on page 9 to learn how to reset the filter indicator. PLUGGING THE POWER ADAPTOR Insert the connector at the end of power adaptor into DC IN Port on the purifier unit and insert the power adaptor into a power socket all the way to the base�... -
Page 9: Control & Fuctions
POWER ON/OFF Plug the SO-255WUI into an appropriate electrical outlet� 2. Tap POWER to turn on the SO-255WUI Air Purifier� Tap it again to turn it off after using� 3. The air quality indicator will illuminate and may change to a different colour depending on air quality�... -
Page 10: Auto Mode
AUTO MODE Tap SPEED repeatedly to select AUTO Mode� 2. When Mode is enabled, the fan speed is adjusted intelligently according to the air quality� SLEEP MODE In SLEEP MODE, the purifier operates at a lower speed and quietly� The lighting is switched off for quiet sleep�... -
Page 11: Child Lock
2H -> 4H-> 8H->12H->Timer OFF� To cancel, tap repeatedly to Timer OFF or turn off the unit� The timer will flash WIFI three times to confirm your setting� 2. When time reaches zero, the SO-255WUI Air Purifier will enter standby mode�... -
Page 12: Wifi
Refer to “SOHO LIFE APP SETUP” on page 12 detailed pairing instructions� 8. SOHO LIFE APP SETUP You can control your purifier with the “SOHO LIFE” free App through a WIFI network� 8.1 WHAT YOU NEED TO GET STARTED Network Specifications ✓... - Page 13 8.3 APP ACCOUNT REGISTRATION 1. To register, select ‘SIGN UP’� 2. You must read and agree to the privacy policy to use the App� 3. Then enter your email address� 4. Select ‘GET VERIFICATION CODE’ then retrieve the code sent to your email� 5.
- Page 14 8.4 SETTING ‘PERSONAL INFORMATION’ ON THE APP The App allows you to edit your profile photo, nickname and time zone� 1. Select ‘HOME’ on the menu at the bottom of the screen� 2. Click on the ‘ A vatar’ icon at the top left of the screen�...
- Page 15 NOT always be named clearly, especially if you have re-named your home WiFi network� • For your SO-255WUI PureHome Connect Smart Purifier to work, you will need to pair it to the 2�4GHz WiFi network, which has a greater range and a stronger and more reliable signal�...
- Page 16 Then click ‘+’ on the top right of the screen to add a new device� Tap ‘ADD MANUALLY’, then click on the icon for PureHome Connect Air Purifier ‘SO-255WUI’� Choose a 2�4GHz WiFi network and enter the password for the network� Click ‘NEXT’�...
- Page 17 7. The Soho App supports two methods of pairing your device to the App� Choose one of the two methods, starting with ‘EZ MODE’� If pairing with ‘EZ MODE’ is not successful, try ‘AP MODE’� A. HOW TO PAIR USING THE DEFAULT ‘EZ MODE’...
- Page 18 B. HOW TO PAIR USING USING ‘AP MODE’ Check that ‘AP MODE’ is selected on the top right of the screen� Check that the Soho SO-255WUI Air Purifier is plugged in and powered at the socket� Confirm the SO-255WUI Air Purifier is in standby mode, i�e� all functions are off�...
- Page 19 You will be prompted to connect to the purifier’s hotspot� Click ‘GO TO CONNECT’ and select the device hotspot name leading with “SMARTLIFE” and return to the Soho Life App and continue the process of adding your new device� The Soho Life App will start to scan and connect to...
- Page 20 3. Confirm Wi-Fi password is correct and the same Wi-Fi network is used on your smartphone 4. Confirm the SO-255WUI Air Purifier is powered, with all functions turned off (in standby mode) and WIFI indicator is rapidly blinking (in pairing mode)�...
-
Page 21: Operation
9. OPERATION 9.1 SETTING OPTIONS 1. SWITCH: Tap to turn the SO-255WUI Air Purifier on and off� 2. MODE: Tap to switch between Auto, Sleep or Manual mode of operation� 3. SPEED: Tap to change purifier fan to Low Speed, Medium Speed or High Speed�... -
Page 22: 10� Automation
10. AUTOMATION There are various ways you can enhance your smart product experience� Automation lets you control your SO-255WUI Air Purifier based on other conditions such as: • Weather changes (example: when local temperature is greater than 28°C) • Schedule (example: 7:00am every morning) •... -
Page 23: Cleaning & Maintenance
We recommend you clean your purifier and filter once every two weeks� Clean filter with a vacuum cleaner� Make sure the SO-255WUI Air Purifier is switched off and disconnected from the power outlet and allow all parts to cool before cleaning or storing�... -
Page 24: 12� Troubleshooting
12. TROUBLESHOOTING The problems that you may encounter when using the machine are listed below� If you are unable to solve the problem according to following information, please contact customer care� PROBLEM POSSIBLE SOLUTION The filter indicator • You have neglected the prompt to replace filter� When the light flickers, and light flickers, you should replace the filter�... -
Page 25: 13� Warranty Terms & Conditions
Soho services, relating to or arising out of your breach of any provision of these terms, your misuse of the Soho services, or your unauthorized modification or alteration of products or software�... -
Page 26: 16� Limitations & Liability
Soho� Any liability for negligence is limited to direct losses usually and typically foreseeable in such case� Should the claim for damages be based on wilful... - Page 28 v1�0 w w w � s o h o h o m e � c o m � a u ANOTHER All Images, Information and Content are Copyright © 2021 DIRECTED Directed Electronics Australia Pty Ltd. All Rights Reserved. BRAND www.directed.com.au | www.directed.co.nz...
