  • Page 1 FA77-B7119 Service Engineer’s Manual http://www.tyan.com...
  • Page 2 MITAC assumes no liability whatsoever, and ® disclaims any express or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MITAC retains the right to make changes to produce descriptions and/or specifications at any time, without notice.
  • Page 3 This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada. Notice for Europe (CE Mark) ● This product is in conformity with the Council Directive 2014/30/EU and 2014/35/EU. http://www.tyan.com...
  • Page 4 Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. VCCI-A ● この装置は、クラスＡ情報技術装置です。この装置を家庭環境で使用すると電波妨 害を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要 求されることがあります。 Safety: EN/IEC 60950-1 ● This equipment is compliant with CB/LVD of Safety: EN/IEC 60950-1. http://www.tyan.com...
  • Page 5 About this Manual This manual is intended for trained service technician/personnel with hardware knowledge of personal computers. It is aimed to provide you with instructions on installing your TYAN FA77-B7119. How this guide is organized This guide contains the following parts:...
  • Page 6 Safety and Compliance Information Before installing and using TYAN FA77-B7119, take note of the following precautions: ·Read all instructions carefully. ·Do not place the unit on an unstable surface, cart, or stand. ·Do not block the slots and opening on the unit, which are provided for ventilation.
  • Page 7 You must become familiar with the safety information in this guide before you install, operate, or service TYAN products. Symbols on Equipment Caution. This symbol indicates a potential hazard.
  • Page 8 · Make sure racks are coupled together if it is a multiple-rack installation. · Make sure the rack is level and stable before installing an appliance in the rack. · Make sure the leveling jacks are extended to the floor. http://www.tyan.com...
  • Page 9 If you do not ground the Green/Yellow tab, it can cause an electrical shock due to high leakage currents. · Do not place objects on AC power cords or cables. Arrange them so that no http://www.tyan.com...
  • Page 10 TYAN, your authorized TYAN partner, or their agents. Equipment Modifications · Do not make mechanical modifications to the system. TYAN is not responsible for the regulatory compliance of TYAN equipment that has been modified.
  • Page 11 – Liquid has been spilled on the product or an object has fallen into the product. – The product has been exposed to rain or water. – The product has been dropped or damaged. – The product does not operate normally when you follow the operating instructions. http://www.tyan.com...
  • Page 12 NOTE http://www.tyan.com...

  • Page 13: Table Of Contents

    Table of Contents Chapter 1: Overview............... 17     About the TYAN FA77-B7119 ..........17   Product Models ............... 18   Features .................. 19   Standard Parts List ..............30   1.4.1 Box Contents ..............30   About the Product ..............31  ...
  • Page 14 5.3.10 Network Stack Configuration ......... 152   5.3.11 CSM Configuration ............154   5.3.12 USB Configuration ............156   5.3.13 Hardware Health Configuration ........158   5.3.14 NVDIMM ADR Configuration ......... 160   5.3.15 OnBoard Device Configuration ........161 http://www.tyan.com...
  • Page 15 Appendix II: How to install Power Wire Clip ......231   Appendix III: Cable Connection Tables ........233   Appendix IV: Fan and Temp Sensors ......... 237   Appendix V: FRU Parts Table ............243   Appendix VI: Technical Support ..........245   http://www.tyan.com...
  • Page 16 NOTE http://www.tyan.com...

  • Page 17: Chapter 1: Overview

    FA77-B7119 not only empowers your company in nowadays IT demand but also offers a smooth path for future application usage. ® TYAN also offers the FA77-B7119 in a version that can support up to fourteen (14) ® internal hot-swappable 2.5” SATA HDD/SSD or NVMe SSD with Intel RSTe 5.0 support.

  • Page 18: Product Models

    Product Models The system board within the Tyan Barebone is defined by the following models: B7119F77V10E4HR-2T-N  : Intel-based platform B7119F77V14HR-2T-N  : Intel-based platform B7119F77V4HR-2T-N  : Intel-based platform Fabric CPU       Model Internal HDD Bays  ...

  • Page 19: Features

    Features TYAN FA77-B7119 (B7119F77V4HR-2T-N) Form Factor 4U Rackmount Chassis Model FA77 30.31" x 17.24" x 6.93" Dimension (D x W x H) System (770 x 438 x 176mm) Motherboard S7119GMRE Gross Weight 43.5 kg (95.9 lbs) Net weight 27.5 kg (60.6 lbs)
  • Page 20 LRDIMM 3DS *Follow latest Intel DDR4 Memory POR Memory channel 6 Channels per CPU Memory voltage 1.2V (11) PCI-E Gen3 x16 slots, (1) PCI-E Gen3 x16 Tyan PCI-E Mezzanine slot, Expansion Slots (1) PCI-E Gen3 x16 slot (OCP 2.0 slot) Pre-install TYAN...
  • Page 21 USB device/PXE via LAN/Storage, Feature User Configurable FAN PWM Duty Cycle, Console Redirection, ACPI sleeping states S4,S5, ACPI 6.1 Please refer to our AVL support Operating System OS supported list lists. CE (DoC) Class A Regulation VCCI Class A http://www.tyan.com...
  • Page 22 In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Manual (1) Quick Installation Guide Installation CD (1) TYAN Device Driver CD Package Contains (1) FA77-B7119 w/NV Tesla-aware Barebone FW Barebone TYAN FA77-B7119 (B7119F77V10E4HR-2T-N) Form Factor 4U Rackmount Chassis Model FA77 30.31"...
  • Page 23 LRDIMM 3DS *Follow latest Intel DDR4 Memory POR Memory channel 6 Channels per CPU Memory voltage 1.2V (11) PCI-E Gen3 x16 slots, (1) PCI-E Gen3 x16 Tyan PCI-E Mezzanine slot, Expansion Slots (1) PCI-E Gen3 x16 slot (OCP 2.0 slot) Pre-install TYAN...
  • Page 24 Monitors voltage for CPU, memory, Voltage System Monitoring chipset & power supply Over temperature warning indicator, Fan & PSU fail LED indicator Others Watchdog timer support Onboard Chipset Onboard Aspeed AST2500 Server Management AST2500 iKVM IPMI 2.0 compliant baseboard Feature management controller (BMC), http://www.tyan.com...
  • Page 25 In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Manual (1) Quick Installation Guide Installation CD (1) TYAN Device Driver CD Package Contains (1) FA77-B7119 w/NV Tesla-aware Barebone FW Barebone FA77-B7119 (B7119F77V14HR-2T-N) Form Factor 4U Rackmount Chassis Model FA77 30.31"...
  • Page 26 Power (TDP) wattage Up to 10.4/9.6 GT/s with Intel System Bus UltraPath Interconnect (UPI) support Intel C621 Chipset Switch IC (2) PLX PEX8796 Supported DIMM Qty (12)+(12) DIMM slots Memory DDR4 RDIMM/RDIMM 3DS / DIMM Type / Speed LRDIMM/LRDIMM 3DS 2666 http://www.tyan.com...
  • Page 27 LRDIMM 3DS *Follow latest Intel DDR4 Memory POR Memory channel 6 Channels per CPU Memory voltage 1.2V (11) PCI-E Gen3 x16 slots, (1) PCI-E Gen3 x16 Tyan PCI-E Mezzanine slot, Expansion Slots (1) PCI-E Gen3 x16 slot (OCP 2.0 slot) Pre-install TYAN...
  • Page 28 10° C ~ 35° C (50° F~ 95° F) Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F) Operating Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Package Contains Manual (1) Quick Installation Guide http://www.tyan.com...
  • Page 29 Installation CD (1) TYAN Device Driver CD (1) FA77-B7119 w/NV Tesla-aware Barebone FW Barebone NOTE: 1. The specifications are subject to change without prior notice. 2. Please visit our Web site for the latest specifications. http://www.tyan.com...

  • Page 30: Standard Parts List

    Standard Parts List This section describes FA77-B7119 package contents and accessories. Open the box carefully and ensure that all components are present and undamaged. The product should arrive packaged as illustrated below. 1.4.1 Box Contents FA77-B7119 Chassis Kit 4U chassis...

  • Page 31: About The Product

    About the Product The following views show you the product. 1.5.1 System Front View http://www.tyan.com...
  • Page 32 Solid On 8. Power Power Off Green Located Blue Solid On 9. ID Free Blue 10. HDD Activity Access Green Blinking BMC & HWM system Normal Amber alert event 11. Warning (＊) N+1 Redundant Alert Amber Solid On PSU Indication http://www.tyan.com...
  • Page 33 Blinking @ 1 Hz For 2.5”/3.5” Device SKU (M1291F77D-BP12E-4 HDD BP pre-installed) Color State Description NVME/SATA/SAS HDD HDD Fail LED Failed (Status LED) No failure found NVME/SATA/SAS HDD Ready HDD Power/Access LED NVME/SATA/SAS HDD Green Blinking (Active LED) Access Activity Power Disconnected http://www.tyan.com...

  • Page 34: System Rear View

    1.5.2 System Rear View Description PSU0 PSU1 PSU2 PSU3 PSU LED Power Wire Clip Jack OCP Option Area (M7119FA77-RIO pre-installed) (M7076-X540-2T LAN Card pre-installed in this picture) PCIE Gen3 x16 Slots http://www.tyan.com...
  • Page 35 AC cord unplugged or AC power Amber lost, with a second power supply in parallel still with AC input power FW Update Mode Blinking Green Warning: All PSUs have to be AC-ON at the same time before you power on the system. http://www.tyan.com...

  • Page 36: Ocp Option Area

    100 Mbps Active Green Blinking Green Solid On Link Green Solid On Yellow Solid On 1000 Mbps (1Gbps) Active Green Blinking Yellow Solid On Link Yellow Solid On Yellow Solid On 10 Gbps Active Yellow Blinking Yellow Solid On http://www.tyan.com...
  • Page 37 Green Solid On Green Solid On 100 Mbps Active Green Blinking Green Solid On Link 1000 Mbps Green Solid On Amber Solid On (1Gbps) Active Green Blinking Amber Solid On NOTE: “Left” and “Right” are viewed from the rear panel. http://www.tyan.com...

  • Page 38: System Top View

    PCIE Gen3 x16 OCP2.0 Slot for SAS Card (from CPU#1, M2217-L16-IO pre-installed) 20~24 PCIE Gen3 x16 Slots (FH/FL, GPU#1 ~ GPU#5) PCIE Gen3 x16 Slot (FH/FL) 26~30 PCIE Gen3 x16 Slots (FH/FL, GPU#6 ~ GPU#10) M7119FA77-IO PCIE Board NOTE: The system is pre-installed with S7119 motherboard. http://www.tyan.com...
  • Page 39 PCIE Gen3 x16 OCP2.0 Slot for SAS Card (from CPU#1, M2217-L16-IO pre-installed) 10~14 PCIE Gen3 x16 Slots (FH/FL, GPU#1 ~ GPU#5) PCIE Gen3 x16 Slot (FH/FL) 16~20 PCIE Gen3 x16 Slots (FH/FL, GPU#6 ~ GPU#10) M7119FA77-IO PCIE Board NOTE: The system is pre-installed with S7119 motherboard. http://www.tyan.com...
