EmberGlo AR60 Installation, Service Instructions & Parts

Installation, Service Instructions & Parts
CAUTION: This steamer to be used with
distilled water only (demineralized). Without treated
water, deposits can build up in steam generators causing
reduced steam volume and eventual stoppage of steam
production. Clogged or limed steam generators caused
by use of non-distilled water will not be covered under the
terms of the warranty.
AR Series -Self Contained Water Reservoir and Pump - Stain-
less steel construction, Top injecting, portable, removable water
drawer, manual pump or timer, 6' - 3 wire cord.
Special Note: The AR Series requires distilled or demineral-
ized water. Clogged or limed generators caused by use of
non-treated water will not be covered under the terms of the
warranty.
Specifi cations:
• 120 volts 60HZ AC 1500 watts, max 13 amp
• 240 volts 60HZ AC 1500 watts, max 6.3 amp
(240V model is Export Only and not UL listed)
• Manual water pump operation
• Closed generator
• Drawer style steamer
Warranty
See the back of this manual for warranty.
This warranty does not apply to damages resulting from
accident, misuse, abuse or alteration.
No equipment may be returned without written authorization
from EmberGlo (or Midco) . Returned goods must be shipped
prepaid to the factory.
EmberGlo
A Div of Midco® International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
toll free 866.705.0514
tel 773.604.8700
fax 773.604.4070
web www.emberglo.com
e-mail sales@emberglo.com
SAFETY INFORMATION TERMS: The following terms are used to identify hazards, safety precaution of
special notations and have standard meanings throughout this manual. They are printed in all capital letters
using a bold type face as shown below, and preceded by the exclamation mark symbol. When you see the
safety alert symbol and one of the safety information terms as shown below, be aware of the hazard potential.
DANGER: Identifi es the most serious hazards which will result in severe personal injury or
death.
WARNING: Signifi es a hazard that could result in personal injury or death.
CAUTION: Identifi es unsafe practices which would result in minor personal injury or product and
property damage.
Quality Designed for Proven Performance
AR60
Front Open
Self Contained Water Supply
Counter Top Steamer
Two Th irds Size Pan
120V and 240V Models
(240V Model for Export ONLY)
Models Description
AR60 Manual Operation with Water Pan
AR60 Manual Operation with Water Pan
Warranty Form must be fi lled in and returned to EmberGlo to
validate warranty. See warranty page for return instructions.
This manual contains suffi cient information for installation of the
EmberGlo Steamer in normal locations.
In the United States, installation must conform with local codes.
PURCHASER: Retain these instructions for future use.
Post in a prominent location near the steamer.
CAUTION: Cooking equipment should be used in
an environment protected by an automatic fi re suppression
system. Consult the National Fire Protection Association NFPA
Code 96 or the latest edition of Standards for Installation of
Equipment for Removal of Smoke and Grease-Laden Vapors
From Commercial Cooking Equipment.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating
and maintenance instructions thoroughly before install-
ing or servicing this equipment.
AVOID ERROR IN PARTS SELECTION. When ordering use
complete EMBERGLO Part Number and Description. Furnish
Model Number, Bill of Material Number and Serial Number (if
available) from the specifi cation plate found on the product.
IMPORTANT: Availability of parts as well as specifi cations are
subject to change without notice. Please consult factory for
item availability.
Volts BOMs
120V 5400400
240V 5400406
718
U L
8471 11
