Installation Service
CAUTION:
This steamer to be used with distilled water only
(demineralized).
Without treated water, deposits can build
up in steam generators causing reduced steam volume and
eventual stoppage of steam production. Clogged or limed
steam generators caused by use of non-distilled water will
not be covered under the terms of the warranty.
Warranty
Midco International Inc Warranty Policy
Exclusions Terms, Customer Requirements and Instructions
Only Authorized Service Providers are authorized to provide Warranty service on
all EmberGlo, a Division of Micdo International Inc., food equipment as described
under and Midco
®
International Warranty Policy. A list of providers can be found on
our web site: www.emberglo.com
Provisions:
In lieu of an implied warranty, all repairs and replacement parts furnished under
our Warranty shall be f.o.b. point of distribution, but the owner must pay the
necessary freight, delivery and labor costs involved when required. Any Federal,
State or Local taxes are also extra. This Warranty is effective for a period of 1 year
from the date of original installation. EmberGlo
Electric Food Preparation Equipment manufactured by Midco International, sold
under the EmberGlo trademark, are guaranteed to be free from defect in material
and workmanship under normal use and service for a period of 1 (one) year after
the date of original installation. Midco's obligation under this Warranty Policy shall
be limited to repairing or replacing, at our option, any part of said equipment which
Midco examination shall disclose to its satisfaction to be thus defective.
Exclusions:
This Warranty Policy does not apply to damages resulting from accident, misuse,
abuse or alteration, nor does it apply to limed steam generators, nor does it apply
to any consequential damages. Most geographical areas require the use of
distilled or demineralized water. Tap water is permissible only with ES Series
Steamers. Nor does it apply to Barbriq's®, briquettes, or rods used in gas broilers.
Midco's obligation will be the replacement of the product or parts removed.
Terms:
Under the terms of this Warranty Policy, models considered portable (devices with
EmberGlo
A Division of Midco International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
tel
773.604.8700
fax 773.604.4070
web www.emberglo.com
Manual & Parts
®
Char Broilers and EmberGlo
S S A A F F E E T T Y Y I I N N F F O O R R M M A A T T I I O O N N T T E E R R M M S S : :
special notations and have standard meanings throughout this manual. When you see the safety alert symbol
and one of the safety information terms, as shown below, be aware of the hazard potential.
DANGER: Identifies the most serious hazards which will result in sever personal injury or death.
WARNING: Signifies hazards that could result in personal injury or death.
CAUTION: Identifies unsafe practices which would result in minor personal injury or product and
property damage.
Quality Designed for Proven Performance
EmberGlo Model AR60T
cords and plug caps such as EmberGlo Steamers) must be taken or returned to
the nearest service provider, transportation prepaid, returned transportation
collect. Non-portable units with permanent wiring will be serviced on the
customer's premises. Under these terms, Midco agrees, within the terms of this
Warranty period, to make all repairs at no charge by the authorized service
provider. Labor and mileage charges submitted by any other provider not
authorized will be the responsibility of the customer.
Customer Requirements:
All charges related to repairs made afterr one (1) year, after the date of original
installation, during the Warranty period will be the responsibility of the customer
unless the registration card has been properly filled out and returned to Midco
International Inc. The product registration information is located on the product
I.D. plate.
If a part is defective due to workmanship or materials and is removed from the product
within the applicable warranty period and returned to Midco in accordance with the
following procedure described, Midco will, at its option, either repair or replace the part.
Call the factory for Instructions on returned goods.
No equipment may be returned without written
®
authorization from MIDCO. Returned goods must be
shipped prepaid to the factory.
WARNING: Improper installation and use of this
product could result in personal or property injury.
Specifications:
- 120 volts 60Hz AC 1500 watts 13 amp
- Automatic timer operation
- Single shot operation
- End of cycle buzzer
The following terms are used to identify hazards, safety precautions or
110
8471-13

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR60T and is the answer not in the manual?

Questions and answers

Summary of Contents for EmberGlo AR60T

  • Page 1 Without treated water, deposits can build up in steam generators causing reduced steam volume and cords and plug caps such as EmberGlo Steamers) must be taken or returned to eventual stoppage of steam production. Clogged or limed the nearest service provider, transportation prepaid, returned transportation steam generators caused by use of non-distilled water will collect.
  • Page 2: Installation

    RESULT IN SEVERE PERSONAL INJURY OR DEATH. ONLY A TRAINED EXPERIENCED SERVICE TECHNICIAN SHOULD ATTEMPT ANY REPAIR PROCEDURE. Qualified serviced agencies are available at most locations - Refer to EmberGlo listing of AUTHORIZED SERVICE AGENCIES included in Standard Equipment Catalog.
  • Page 3 AR60T Service Service Continued Figure 1. Wiring for AR60T Steamer Timers There are three timers in this system. Push-button Automatic Reset - times length of cycle in minutes and supplies power to the solid state timers. To determine if timer is functioning properly a volt meter or test lamp may be used.
  • Page 4 AR60T Service and Trouble Shooting Service Continued Figure 2. Generator Casting To clean generator assembly, separate casting from plate and clean lime from cavity in casting. Caution: Do not damage plate by scratching or polishing the finish. Information on use of the overheat label (8451-98) Caution: To prevent accidental shock, disconnect electrical plug from receptacle before attempting service.
  • Page 5 AR60T Service and Trouble Shooting and lime deposits from the discharge plate. Clean the groove of the discharge plate. To install the new gaskets in the discharge plate grooves, as shown in Figure 2, first apply a bead of Dow Corning 732 or General Electric 159 RTV silicon adhesive at the ends of the gasket then butt the two ends of the individual gasket.
  • Page 6 AR60T Exploded View Figure 4. AR60T Exploded View and Parts List...
  • Page 7 DELAYED INTVAL TIMER MOD 6013 8406-70 RECYCLE TIMER 606 - EXTERNAL RESISTOR 5693-00 RISER TUBE ASSEMBLY AR60T 8452-10 HOSE CLAMP (29/64”) 5600-64 PUMP RISER TUBING ASSEMBLY AR60T 5600-51 PUMP ASSEMBLY AR60T 5661-40 HEYCO MOUNT 5600-56 DIP TUBE ASSEMBLY AR60T 5661-80...
  • Page 8: Cooking Instructions

    Potatoes, whole (small) 20 minutes Potatoes, mashed (2 quarts) 6 minutes EmberGlo A division of Midco International Inc. 8471 13 4140 West Victoria Street * Chicago, Illinois 60646 tel 773.604.8700 fax 773.604.4070 web www.em b erglo.com email sales@emberglo.com Printed in USA...
