Page 2: Table Of Contents
Contents CAPTIS PULSE LITE TECHNICAL INFORMATION ....................3 BEFORE YOU BEGIN ................................ 4 INSTALLATION ................................... 5 Mount your Captis Pulse Lite ............................. 5 Terminate the Sensor ..............................6 Best Practice Considerations ............................6 TROUBLESHOOTING ............................... 7 MAINTENANCE & SAFETY ............................8 Maintenance .................................. -
Page 3: Captis Pulse Lite Technical Information
CAPTIS PULSE LITE TECHNICAL INFORMATION 1 x Pulse Input Passive Suitable for Reed SW + Open Collector + Dry Contact Maximum Pulse Frequency 1000Hz Sensor Minimum Open Resistance 1.25MΩ Sensor Maximum Closed Resistance 60kΩ Physical Dimensions 95 x 105 x 60 mm Weight <... -
Page 4: Before You Begin
The contents of your Captis device box • A small flat blade screwdriver and crimping tool • An internet-connected device, such as a phone or tablet What’s in your Captis device box? • Captis Pulse Lite • Attachment bracket • Activation magnet • Amphenol... -
Page 5: Installation
4. Test connectivity Mount your Captis Pulse Lite Note: If the Captis Pulse Lite is to be installed underground or inside a metal cabinet, an external LTE antenna must be used. Ensure that your Captis device supports external antenna connection. The antenna lead must be routed to an open area where cell signal is less obstructed. -
Page 6: Terminate The Sensor
Terminate the Sensor Your Captis Pulse Lite is provided with a four-pin Amphenol plug that can be connected to one or two sensors and/or measurement devices. Use a crimping tool (not included) to ensure that the pins are securely fastened to the end of the sensor cable and insert into the appropriate receptacles of the Amphenol plug. -
Page 7: Troubleshooting
TROUBLESHOOTING SYMPTOM MEANING WHAT TO DO Device is working as it should, x20 Device is on/ awake. leave device to collect data. Device connected to LTE Device is working as it should, solid network. leave device to collect data. The device battery may be Use a different device and depleted, or a device fault may no LED status... -
Page 8: Maintenance & Safety
Note: Opening the Captis Pulse Lite device will void warranty and could cause significant damage to the device. Maintenance Your Captis Pulse Lite does not require any maintenance once installed. Your Captis Pulse Lite device uses a non-rechargeable Lithium ION battery, and there are no user serviceable parts inside the device.
