Alula RE305 Quick Start Manual

Resolution Compatibles
The Temperature Sensor
overheat conditions. The sensor will alarm when the
temperature trip points are reached.

Features

• Indicates freeze and overheat warnings
• Industry-leading wireless range and battery life
• Secure encrypted wireless transmissions
• 5-year warranty

Enroll

the freeze input (ID ending in 0) by placing the
panel into wireless enrollment mode and then sending
an enrollment signal from the sensor.

Options for sending an Enrollment Signal

• Remove the battery tab and cover to trip
tamper
Overheat inputs and reed zones must be enabled to
function. Activate only as needed in order to extend
battery life.
To activate and enroll an overheat input (ID ending in
1):
• Remove magnet from reed switch
• Hold down tamper and install battery

Install

by mounting the sensor in the desired location
using two #4 or #6 screws. An optional cover-securing
screw is included. Alternatively, the sensor can also be
installed using 3M™ VHB™ tape.

Freeze or Heat alarms

temperature trip points are reached.

Temperature Trip Points

• Heat alarms when over 100°F (38°C)
• Heat restores when under 97°F (36°C)
• Freeze alarms when under 45°F (7°C)
• Freeze restores when over 48°F (9°C)
Use the panel installation guide to verify proper system setup.
RE305 Temperature Sensor
DSC
is used to detect freeze and
.
are transmitted when the
Compatible
®
Mounting Screw Holes
Cover-Securing Screw Hole
I
