FourStarGroup 1781391 Manual

Black computer stand
Hide thumbs

Advertisement

Quick Links

Download this manual
ITEM: 11211722W
UPC#4893948120017 MODEL: 1781391
BLACK COMPUTER STAND
STOP
Do you have any questions ? Missing small parts or hardware?
If you need assistance with the assembly of your COMPUTER
DESK please e-mail our Customer Service Department at:
support@fourstari.com or call us at 1-800-639-3803
Please let customer service know:
1. You purchased this item from Wal-Mart
2. The item description is: Computer Desk
3. The item number is 11211722W
4. The part number/letter and quantity needed
If you have this information ready, we will be able to process
your request promptly. Thank you
LOT#0708-00000
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE
REFERENCE.
Do not return to the store
DATE PURCHASED
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1781391 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FourStarGroup 1781391

Summary of Contents for FourStarGroup 1781391

  • Page 1 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. ITEM: 11211722W UPC#4893948120017 MODEL: 1781391 BLACK COMPUTER STAND Do not return to the store STOP Do you have any questions ? Missing small parts or hardware?

  • Page 2: Phillips Screwdriver

    CAUTION : 1. Read this instruction manual and keep it for reference. 2. Adult supervision is required due to small parts. 3. Assemble on soft surfaces to prevent damage to the product finish. 4. Recommended two people to assemble the product. 5.

  • Page 3: Parts And Hardware

    PARTS AND HARDWARE BEFORE YOU BEGIN, PLEASE FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP. Finished Part Name Line-art Drawing Size Quantity Material Finish Edges 3.8 x 3.8 x 47cm Long Tube Silver Short Tube Silver 3.4 x 3.4 x 24.4cm Extra Short Silver 3.4 x 3.4 x 12cm...
  • Page 4 ASSEMBLY INSTRUCTIONS Step 1. Place the DESKTOP (A) surface face down on a soft cloth/blanket in order to protect the surface. Place the INSERT CAPS (5) firmly into the openings, tap lightly with a hammer just enough for the inserts to remain lightly in the opening. Turn the desktop surface over on the soft cloth surface and apply gradual pressure to each corner until the INSERT CAPS (5) are firmly into the opening.
  • Page 5 Step 2. Carefully attach the EXTRA SHORT TUBES (3) to the INSERT CAPS (5). UNFINISHED SURFACE SOFT CLOTH 3 Extra Short Tube - 4 PCS...
  • Page 6 Step 3. Attach the 10” DRAWER SLIDES (6A) to the DRAWER SLIDE CROSSBAR (D) Using 10mm SCREWS (7). FINISHED EDGING SURFACE FINISHED SURFACE D Drawer Slide Crossbar - 2 PCS 6 Drawer Slide - 2 PCS 7 10mm Screw - 4 PCS...
  • Page 7 Step 4. Place the DRAWER SIDE CROSSBAR (D) upright & attach the APRON CROSSBAR (E) using 32mm SCREWS (8). UNFINISHED SURFACE UNFINISHED SURFACE FINISHED SURFACE UNFINISHED EDGING SURFACE FINISHED SURFACE E Apron Crossbar - 2 PCS 8 32mm Screw - 4 PCS...
  • Page 8 Step 5. Place the keyboard drawer ASSEMBLY FROM STEP 4 over the EXTRA SHORT TUBES (3) and then attach the LONG and SHORT TUBES (1 and 2) to hold it in place. UNFINISHED SURFACE SOFT CLOTH 1 Long Tube - 2 PCS 2 Short Tube - 2 PCS...
  • Page 9 Step 6. Place the BOTTOM CROSSBAR (G) over the SHORT TUBES (2). Then, attach the SHORT TUBES (2). Place the L&R CROSSBARS (F) over the LONG and SHORT TUBES (1 and 2), Then, attach SHORT TUBES (2) again. UNFINISHED SURFACE UNFINISHED SURFACE SOFT CLOTH...
  • Page 10 Step 7. Place the BOTTOM PANEL (B) on to the SHORT TUBES (2) and then attach the FOOTINGS (4). UNFINISHED SURFACE SOFT CLOTH B Bottom Panel - 1 PC 4 Foot - 4 PCS...
  • Page 11 Step 8. Attach the 10" DRAWER SLIDES (6B) to each side of the KEYBOARD DRAWER PANEL (C) Using 10mm SCREWS (7) , Then attach the KEYBOARD STOPPER (9) to the unfinished edging surface of the KEYBOARD DRAWER PANEL (C) using POWER PIN (10).
  • Page 12 Step 9. Carefully turn the computer workstation right side up. Then insert the KEYBOARD DRAWER PANEL (C) from STEP 8 at the top of the rolling mechanism FINISHED SURFACE FINISHED SURFACE FINISHED To clean the computer desk, wipe with soft, dry cloth.

This manual is also suitable for:

4893948120017
