Senonics LLC (US & Europe Headquarters)
Minnow Battery Installation
This document will guide you through installing the battery and then resetting
your logger after a new battery is installed. This reset is needed in order to
set the "real time clock" after a loss of power.
1.
Remove the back cover (#1 Philips screwdriver)
2.
Remove the circuit board. Place the logger face down and press the edge
of the box to unseat the board and then pry it out using your fingernail.
3.
Insert the new battery with the + terminal up and then close the back
cover. Be careful not to over tighten the screws.
4.
Download and install the "Minnow Application Program" (Windows only)
from
http://senonics.com/support.html
5.
Open the application and go to the "Configuration Wizard"
6.
Plug the Minnow into the computers USB port
7.
The Connection Icon will be blue if connected (be patient the first time)
www.senonics.com
support@senonics.com
©
Senonics LLC
Minnow Logger
sales@senonics.com
Revision 1.02
