Senonics MINNOW LOGGER Quick Reference Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Minnow Logger
Quick Reference Guide
Senonics LLC
www.senonics.com
support@senonics.com
sales@senonics.com
MINNOW LOGGER
Quick Reference Guide
(Minnow 1.0T & Minnow 1.0TH)

Description

The Minnow Logger is a portable, battery operated,
temperature and humidity data logger able to store 65,520
samples of both temperature and humidity along with a time
stamp. The Minnow Logger runs off of a CR2450 coin cell
battery that enables it to run for over 4 years.
This Quick Reference Guide gets you started with the logger
with the most basic functions to have you up and running with
your logger in a matter of minutes.
The Minnow product today comes in two versions; Minnow
1.0T is a temperature only version and Minnow 1.0TH is a
temperature and humidity logger. This quick reference guide
applies for both versions.

Battery Installation

The Minnow logger runs from a standard coin cell battery. We recommend a CR2450 620mAH Coin cell
battery. There are different manufacturers but a good one is Panasonic CR-2450/G1AN. You can find it
easily on the web from different places such as www.digikey.com,
www2.mouser.com
and probably in your
local supermarket. The key thing is to choose a CR2450 battery with high capacity since this will translate
into a longer logger battery life.
First remove the Minnow cover by unscrewing the two fastener screws (#1 Philips) at the rear of the logger.
©
Revision 1.0.6
Senonics LLC
1/6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINNOW LOGGER and is the answer not in the manual?

Questions and answers

Related Manuals for Senonics MINNOW LOGGER

Summary of Contents for Senonics MINNOW LOGGER

  • Page 1 Battery Installation The Minnow logger runs from a standard coin cell battery. We recommend a CR2450 620mAH Coin cell battery. There are different manufacturers but a good one is Panasonic CR-2450/G1AN. You can find it easily on the web from different places such as www.digikey.com, www2.mouser.com...
  • Page 2 To configure or retrieve data from a logger you will need a Windows PC running Windows XP, Windows Vista, Windows 7 or Windows 8. Alternatively, you can also install the application on a Mac. Connect the Minnow logger to your PC using the provided USB cable. Any USB port on the PC can be used. ©...
  • Page 3 Configuring a Minnow Logger Installation of the Senonics Minnow PC application is very simple. The Minnow needs no special drivers since it is a USB HID device and such devices can make use of the standard drivers that come with Windows.
  • Page 4 Minnow Logger Quick Reference Guide Senonics LLC www.senonics.com support@senonics.com sales@senonics.com Connect the logger and you will see the connected indication changes to blue. Connection Indication Configure Button Next fill out the configuration settings. For example:-  C or  logging start to "On Disconnection"...
  • Page 5 Retrieving Data Connect your Minnow logger. The logger red light will illuminate for 1 second indicating logging is stopping. Start the PC application and navigate to the Configuration page. Press "Read Logger Configuration/Data" to retrieve the configuration and data from the connected logger.
  • Page 6 More Advanced Topics This document has shown the most basic way to configure the Minnow logger in order for you to get started very quickly. There are for example other logger start modes such as button press, start at a defined time and real time logging.
