NTRIP Modem - Quick Start Guide
The Racelogic NTRIP Modem allows an RTK enabled VBOX to receive positional correction data via
RTK
without having to use a
will display status and connection information.
Registration
So that Racelogic can continue to provide you with notification of the latest software releases, firmware upgrades and to
offer technical support, please register your NTRIP Modem.
Register your unit here.
What's Included
Product Code
NTRIPMDM-V1
RLCAB170
TTV2AMBBLK1M
ANTMSTUBSMAM
VBOX Base
Station. Configuration is made via a Wi-Fi access point and the front screen
Quantity
1
1
1
1
https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_-
Network
Description
NTRIP Modem Unit
6 Way Hirose to 5 Way Lemo - 2 m
USB-A to USB Micro-B Fast Data
Charger Cable - 1 m
Multi Band Antenna
_Quick_Start_Guide
1
Advertisement
Related Manuals for Racelogic NTRIPMDM-V1
Summary of Contents for Racelogic NTRIPMDM-V1
- Page 1 Station. Configuration is made via a Wi-Fi access point and the front screen will display status and connection information. Registration So that Racelogic can continue to provide you with notification of the latest software releases, firmware upgrades and to offer technical support, please register your NTRIP Modem. Register your unit here.
-
Page 2: Hardware Overview
Hardware Overview Front The front panel of the modem contains an OLED screen which displays status and connection information. The four buttons below the screen do not currently serve any function and are reserved for future use. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide... - Page 3 An SMA connector is also included for attaching the supplied antenna. Bottom The bottom of the unit houses a Hirose connector which is used to connect to a VBOX or other GNSS receiver via the supplied RLCAB170 cable. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide...
-
Page 4: Screen Overview
If the unit is configured to use both the internal GSM modem and an external Wi-Fi hotspot, it will attempt to auto connect to the Wi-Fi hotspot first on power up. 1. Attach the supplied antenna to the SMA connector on the top of the unit. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide... - Page 5 4. Apply power to the connected VBOX or other GNSS receiver. If you are using another GNSS receiver and power isn't available via the Hirose connection, the modem can be powered from the USB socket using the supplied TTV2AMBBLK1M cable. More information on this is available here. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide...
- Page 6 'RTCM Streaming' message. If there is a problem with the server details entered, the unit will briefly display an 'Invalid Caster Credentials' message. Note: These details will be provided by your NTRIP service provider. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide...
- Page 7 9. NTRIP Modem is now setup ready for use, the front screen will display status and connection information. https://en.racelogic.support//Product_Info/Telemetry_Systems/NTRIP_Modem/Quick_Start_Guides/NTRIP_Modem_- _Quick_Start_Guide...
