OWNER'S
MANUAL
Read this manual carefully before operating
this outboard motor.
F15
F20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F15 and is the answer not in the manual?

Questions and answers

Related Manuals for Hidea F15

Summary of Contents for Hidea F15

  • Page 1 OWNER’S Read this manual carefully before operating this outboard motor. MANUAL...
  • Page 3 Read this manual carefully before operating this outboard motor. Keep this manual onboard in a waterproof bag when boating. This manual should stay with the outboard motor if it is sold.
  • Page 4 Hidea. If you have any man- ual. Therefore some items may not question about operation apply to every model.

  • Page 5: Table Of Contents

    Table of contents Specifications of Battery Safety information......1 Mounting battery......16 Outboard motor safety......1 Multiple batteries......16 Propeller..........1 Without a rectifier or Rectifier Regulator. 16 Rotating parts........1 Propeller selection......16 Hot parts..........1 Start-in-gear protection....17 Electric shock........1 Engine oil requirements....17 Power tilt..........1 Fuel requirements......18 Engine shut-off cord (lanyard)...1 Gasoline...........18 Gasoline..........1...
  • Page 6 Table of contents Tilt lock mechanism......31 models...........54 Tilt support knob......32 Checks after engine warm up..54 Tilt support bar.........32 Shifting..........54 Power tilt unit........32 Stop switches........54 Cowling lock lever (pull up type)..33 Shifting...........54 Flushing device........33 Stopping boat.........56 Alert indicator........33 Stopping engine......56 Instruments and indicators....34 Procedure........56 Indicators........34 Trimming outboard motor....57...
  • Page 7 Table of contents Maintenance chart 2......75 Greasing..........76 Cleaning and adjusting spark plug..........77 Checking fuel filter......78 Inspecting idle speed.......78 Changing engine oil......79 Inspecting wiring and connectors..80 Checking propeller......81 Removing propeller......81 Installing propeller......82 Changing gear oil......82 Inspecting replacing anode(s)........83 Checking battery (for electric start models)....84 Connecting the battery.....84 Disconnecting the battery....85 Trouble Recovery......86...

  • Page 8: Safety Information

    Safety information tor and the clamp bracket when the motor is Outboard motor safety trimmed or tilted. Keep body parts out of Observe these precautions at all times. this area at all times. Be sure no one is in this area before operating the power tilt Propeller mecha- nism.

  • Page 10: Gasoline Exposure And Spills

    Personal flotation devices distributed cording boat Have an approved personal flotation device manufacturers instruc- tions. Overloading or (PFD) on board for every occupant. Hidea incorrect weight distribution recommends that you must wear a PFD compromise the boats han- dling and lead...

  • Page 12: Avoid Collisions

    Safety information swamping. Accident reporting Avoid collisions Boat operators are required by law to file a Scan constantly for people, objects, and Boating Accident Report with their state oth- er boats. Be alert for conditions that boating law enforcement agency if their limit your visibility or block your vision of boat is involved in any of the following others.

  • Page 14: Passenger Training

    Safety information Passenger training Boat Owners Association of The United Make sure at least one other passenger is States trained to operate the boat in the event of 1-800-336-BOAT (1-800-336-2628) an emergency. http://www.boatus.com/ Boating safety publications National Association of State Boating informed about boating...

  • Page 16: Rules When Encountering Vessels

    Safety information way; it is called the “stand-on” vessel. The vessel that does not have the right-of-way Rules when encountering vessels called “give-way” There are three main situations that you “burdened”vessel. These rules determine may encounter with other vessels which which vessel has the right-of-way, and what could lead to a collision unless the Steering each vessel should do.

  • Page 17: Other Special Situations

    Safety information Other special situations There are three other rules you should be aware of when driving your boat around oth- er vessels. Narrow channels and bends When navigating in narrow channels, you should keep to the right when it is safe and practical to do so.
  • Page 18 Safety information Reading buoys and other markers The waters of the United States are marked for safe navigation by the lateral system of buoyage. Simply put, buoys and markers have an arrangement of shapes, colors, numbers and lights to show which side of the buoy a boater should pass on when navigat- ing in a particular direction.
  • Page 20 Safety information ZMU01708...

  • Page 21: General Information

    Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from your Hidea dealer or for reference in case your outboard HD25191 motor is sto- len.

  • Page 22: Read Manuals And Labels

    Read all labels on the outboard motor and the boat.  If you need any additional information, contact your Hidea dealer. HD33832 Warning labels If these labels are damaged or missing, contact your Hidea dealer for replacements. F15, F20 ZMU05739...
  • Page 23 General information...
  • Page 24 General information Electrical hazard HD33843 Symbols The following symbols mean as follows. Notice/Warning Remote control lever/gear shift lever operat- ing direction, dual direction Read Owner’s Manual Engine start/ Engine cranking Hazard caused by continuous rotation...

  • Page 25: Specifications And Requirements

    Specifications and requirements Transom height S: HD34521 Specifications 438 mm (17.2 in) TIP: Transom height L: “(AL)” stated in the specification data below F15HE 565 mm (22.2 in) represents the numerical value for the F15H 565 mm (22.2 in) alumi- num propeller installed. F15HE/T 570 mm (22.4 in) Likewise, “(SUS)”...
  • Page 26 Specifications and requirements (20 HP@5500 r/min) 0.15–0.25 mm (0.0059–0.0098 in) F20FE/T 14.7 kW@5500 r/ Valve clearance (cold engine) EX: 0.25– min (20 HP@5500 r/min) 0.35 mm (0.0098–0.0138 in) F20HE/T 14.7 kW@5500 Min. cold cranking amps (CCA/SAE): r/min (20 HP@5500 r/min) F15HE 245.0 A Idle speed (in neutral): F15HE/T 245.0 A...
  • Page 27 Specifications and requirements...

  • Page 28: Installation Requirements

    Specifications and requirements F15HE/T Power tilt HD33554 F20FEManual tilt Installation requirements F20EHA Manual tilt HD33564 F20HEManual tilt Boat horsepower rating F20FE/T Power tilt EWM01560 WARNING F20HE/T Power tilt Overpowering boat cause Propeller mark: severe instability. Fuel and oil: Before installing the outboard motor(s), con- Recommended fuel: firm that the total horsepower of your out- Regular unleaded gasoline...
  • Page 29 Specifications and requirements...

  • Page 30: Battery Requirements

    (CCA/SAE): To connect multiple batteries, such as for F15HE 245.0 A multiple engine configurations or for an ac- F15HE/T 245.0 A cessory battery, consult your Hidea dealer F20FE245.0 A about battery selection and correct wiring. F20FE/T 245.0 A HD25730 Without a rectifier or Rectifier F20FE/T 245.0 A...

  • Page 31: Propeller Selection

    Specifications and requirements higher with the above models. Consult your Hidea dealer for details on installing an optional Rectifier Regulator. HD34195 Propeller selection Next to selecting an outboard motor, select- ing the right propeller is one of the most im-...

  • Page 32: Start-In-Gear Protection

    Select an oil grade according to the average more appropriate. temperatures area where Your Hidea dealer can help you select the outboard motor will be used. right propeller for your boating needs. Recommended engine oil: Select a propeller that will allow the engine...
  • Page 33 Specifications and requirements...

  • Page 34: Fuel Requirements

    10% Ethanol. pinging occurs, use a different brand of A high quality gasoline without Ethanol is gas- oline or premium unleaded fuel. Hidea the preferred fuel for your Hidea outboard recommends that you use alcohol-free mo- tor.
  • Page 35 Specifications and requirements particular- ly in older boats, as well as tanks and pipes...

  • Page 36: Gasoline Additives

    Hidea recommends the use of two Ya- a layer at the bottom of the fuel tank. This malube gasoline additives to reduce internal ethanol...
  • Page 37 Specifications and requirements...

  • Page 38: Anti-Fouling Paint

    Keep the following items onboard in case for use on aluminum may be applied to the there is trouble with the outboard motor. out- board motor. The original Hidea paint A tool kit with assorted screwdrivers,  sur- face may be scuffed lightly before...
  • Page 39 Specifications and requirements...

  • Page 40: Star Labels

    Specifications and requirements ZMU04346 HD25274 Star labels 1.Manufactured date label Your outboard motor is labeled with a Cali- fornia This label is attached to the clamp bracket or the swivel bracket. ZMU05623 Star labels location HD40330 One Star—Low Emission The one-star label identifies engines that meet the Air Resources Board’s Personal Watercraft and Outboard marine engine 2001 exhaust emission standards.
  • Page 41 Specifications and requirements HD40340 HD33861 Two Stars—Very Low Emission Four Stars—Super Ultra Low Emission The two-star label identifies engines that The four-star label identifies engines that meet the Air Resources Board’s Personal meet the Air Resources Board’s Sterndrive Watercraft and Outboard marine engine and Inboard marine engine 2009 exhaust 2004 exhaust emission standards.

  • Page 42: Components

    Components HD2579Y Components diagram TIP: * May not be exactly as shown; also may not be included as standard equipment on all mod- els (order from dealer). F15HE, F15HE/T, F20HE, F20EHA, F20FE/T, F20HE/T ZMU07412 1. Top cowling 16. Clamp screw 2.
  • Page 43 Components...

  • Page 44: Fuel Tank

    Components F15H, F20MHA 16 15 ZMU07413 1. Top cowling 21. Flushing device 2. Cowling lock lever 22. Fuel tank* 3. Drain screw HD25802 4. Anti-cavitation plate Fuel tank 5. Trim tab 6. Propeller If your model was equipped with a portable 7.

  • Page 45: Fuel Joint

    Components allowed to enter the fuel tank while operating the engine. HD26181 Remote control box The remote control lever actuates both the shifter and the throttle. The electrical switch- es are mounted on the remote control box. ZMU0744 1. Fuel joint 2.
  • Page 46 Components...

  • Page 47: Neutral Interlock Trigger

    Components 1. Neutral “ ” 1. Fully open 2. Forward “ ” 2. Fully closed 3. Reverse “ ” 4. Shift TIP: 5. Fully closed The neutral throttle lever will operate only 6. Throttle when the remote control lever is in neutral. 7.

  • Page 48: Throttle Grip

    Components ZMU05519 ZMU05337 1. Forward “ ” 1. Throttle indicator 2. Neutral “ ” 3. Reverse “ ” HD25976 Throttle friction adjuster HD25942 A friction device provides adjustable resis- Throttle grip tance to movement of the throttle grip or the The throttle grip is on the tiller handle.
  • Page 49 Components...

  • Page 50: Engine Shut-Off Cord (Lanyard) And Clip

    Components ZMU02001 When constant speed is desired, tighten the 1. Cord adjuster to maintain the desired throttle set- 2. Clip ting. 3. Engine shut-off switch HD25995 Engine shut-off cord (lanyard) and clip The clip must be attached to the engine shut- off switch for the engine to run.
  • Page 51 Components...

  • Page 52: Manual Starter Handle

    Components HD26091 Main switch The main switch controls the ignition system; its operation is described below. “ ” (off)  With the main switch in the “ ” (off) posi- tion, the electrical circuits are off, and the key can be removed. “...

  • Page 53: Steering Friction Adjuster

    Components port side “A”. To decrease resistance, turn the lever to the starboard side “B”. WARNING Do not overtighten the friction adjuster. If there is too much resistance, it could be difficult to steer, which could result in an accident. ZMU05522 ZMU05579 If the resistance does not increase even...

  • Page 54: Trim Tab

    Components adjuster lever is set to the “A” position. Bolt tightening torque: Check tiller handle  8.0 Nm (0.8 kgf-m, 5.8 ft-lb) smooth move- ment when the lever is turned to the star- board side “B”. Trim rod (tilt pin) Do not apply lubricants such as ...

  • Page 55: Tilt Support Knob

    Components HD26333 Tilt support bar The tilt support bar keeps the outboard motor in the tilted up position. ZMU05631 1. Tilt lock lever (Release / tilt-up) To lock it, set the tilt lock lever in the lock ZMU05528 po- sition. To release, push the tilt lock lever in the release position.
  • Page 56 Components HD26333...

  • Page 57: Cowling Lock Lever (Pull Up Type)

    Components HD26463 Flushing device This device is used to clean the cooling wa- ter passages of the motor using a garden hose and tap water. 1. Power tilt unit 2. Power tilt motor NOTICE ZMU05597 Do not use the tilt support lever or knob when trailering the boat.

  • Page 58: Instruments And Indicators

    Instruments and indicators Indicators Low oil pressure-alert indicator If oil pressure drops too low, this indicator will light up. For further information, see page 35. NOTICE Do not continue to run the  ZMU06257 engine if the low oil pressure-alert 1.
  • Page 59 Instruments and indicators...

  • Page 60: Engine Control System

     Do not continue to operate the engine if clogging. a alert device has activated. Consult your Hidea dealer if the problem cannot be located and corrected. Overheat alert This engine has an overheat-alert device. If the engine temperature rises too high, the alert device will activate.
  • Page 61 Engine control system...
  • Page 62 If the alert system has activated, stop the en- gine as soon as it is safe to do so. Check the oil level and add oil as needed. If the oil level is correct and the alert device does not switch off, consult your Hidea dealer.
  • Page 63 Engine control system...

  • Page 64: Installation

    Installation 3. Hold the handgrips and steering brack- HD26902 Installation ets as shown in the illustration and lift The information presented in this section is the outboard motor using two people. intended as reference only. It is not possible to provide complete instructions for every possible boat and motor combination.
  • Page 65 Installation...
  • Page 66 Test runs at different heights can help de- termine the optimum mounting height. Consult your Hidea dealer or boat man- ufacturer for further information on deter- mining the proper mounting height. For instructions on setting the trim ...
  • Page 67 Installation...

  • Page 68: Clamping The Outboard Motor

    This the out- board (if packed). For details, could cause loss of control and seri- consult your Hidea dealer. WARNING! ous injury. Make sure the clamp Avoid using bolts, nuts or washers screws are tightened securely. Occa-...

  • Page 69: Operation

    Operation For 10 hours for breaking in engine avoid First-time operation ex- tended idling, rough water and crowded ar- eas. Fill engine oil For the first hour of operation: The engine is shipped from the factory with- Run the engine at varying speeds up to out engine oil.
  • Page 70 Operation...

  • Page 71: Remove The Top Cowling

    If any water is found in the fuel, or if a significant amount of debris is found, the fuel tank should be checked and cleaned by a Hidea dealer. Fuel system ZMU06169 WARNING...
  • Page 72 Operation...

  • Page 73: Engine Shut-Off Cord (Lanyard)

    Operation Operate throttle levers  several times to make sure there is no Engine oil hesitation in their travel. Operation should Put the outboard motor in an upright be smooth over the complete range of po- sition (not tilted). NOTICE: If the motion, and each le- ver should return motor is not level, the oil level completely to the idle po- sition.
  • Page 74 Operation...

  • Page 75: Engine

    After installing, check the fitting of the top during oper- ation. cowling by pushing it with both hands. If the top cowling is loose, have it repaired by your Hidea dealer. ZMU06172 1. Fitting 2. Flushing device Checking power tilt system...
  • Page 76 Operation...

  • Page 77: Battery

    Operation motor is trimmed or tilted. mable and explosive. Always refuel ac- Be sure no one is near the cording to this procedure to reduce  outboard motor before performing this the risk of fire and explosion. Gasoline is poisonous and can check.
  • Page 78 Operation 5. While pressing and holding the pressure relief tab under the fuel tank cap, slowly turn the fuel tank cap counterclockwise 1/4 turn. 1. Fuel joint 2. Fuel hose ZMU07446 2. Turn the air vent screw clockwise to close it. 1.

  • Page 79: Operating Engine

    Operation Fuel tank capacity: 25 L (6.60 US gal, 5.50 Imp.gal) ZMU07444 1. Air vent screw ZMU07448 Operating engine TIP: Wipe up any spilled gasoline  WARNING immediately with dry rags. Before starting the engine, make  Dispose of rags properly ...
  • Page 80 Operation...
  • Page 81 Operation 3. Primer pump 4. Toward the fuel tank 4. Align the groove in the fuel joint on the outboard motor with the protrusions on the fuel hose. ZMU07445 1. Air vent screw 2. Remove the fuel joint cap on the out- board motor.
  • Page 82 Operation...

  • Page 83: Starting Engine

    Operation hose. fuel valve may also be equipped on the boat. Open the fuel valve. TIP: Check the boat’s manual for the position of the fuel valve. 10. Squeeze the primer pump, with the ar- row pointing up, until you feel it become firm.
  • Page 84 Operation opera- tor is ejected. Attach the engine WARNING shut- off cord to a secure place on Failure to attached engine shut-off  your cloth- ing, or your arm or leg cord could result in a runaway boat if while operating.
  • Page 85 Operation Do not attach the cord to clothing that could tear loose. Do not route the cord where it could become entangled, pre- venting it from functioning. Avoid accidentally pulling the  cord dur- ing normal operation. Loss of engine power means the loss of most steering control.
  • Page 86 Operation strong pull straight After the engine out to crank and starts, slowly start the engine. return Repeat if manual starter necessary. handle original posi- tion before releasing it. TIP: When the engine is cold, it needs to be ZMU05536...
  • Page 87 Operation warmed up. For further information, see page 54. 6. Slowly return the throttle grip to the fully closed position. Starting procedure (warm engine) Place the gear shift lever in neutral. ZMU06609 TIP:  If the throttle is opened too much, the en- gine speed rises rapidly, causing the out- board motor to swivel toward the starboard side.
  • Page 88 Operation...
  • Page 89 Operation ZMU05533 ZMU05536 6. After the engine starts, slowly return TIP: manual starter handle to its original The start-in-gear protection device prevents posi- tion before releasing it. the engine from starting except when in Loosen the throttle friction adjuster and neu- tral.
  • Page 90 Operation...
  • Page 91 Operation page 54. If the engine is warm and fails to  start, open the throttle slightly and try to start the engine again. If the engine still fails to start, see page 86. 6. Slowly return the throttle grip to the fully closed position.
  • Page 92 Operation...

  • Page 93: Checks After Starting Engine

    Consult your turn to “ ” (on). NOTICE: Never turn Hidea dealer if the problem cannot be the main switch “...

  • Page 94: Warming Up Engine

    1. Pull the neutral interlock trigger up (if could occur. Check the oil level and equipped). add engine oil if necessary. Consult your Hidea dealer if the cause for the low oil pressure alert cannot be found. [ECM01831] HD36531 Checks after engine warm up...
  • Page 95 Operation...
  • Page 96 Operation gear) [about 35 (a detent can felt) for To shift from in gear (forward/reverse) to re- mote control models]. Be sure to neutral check that the tilt lock lever is in the Close the throttle so that the engine lock/down position (if equipped) before slows to idle speed.
  • Page 97 Operation er / and crisply into the neu- tral positio ZMU05729 TIP:...
  • Page 98 Operation...

  • Page 99: Stopping Boat

    Operation ZMU05533 ZMU02083 HD31742 Stopping boat EWM01510 WARNING reverse  function to slow down or stop the boat as it could cause you to lose control, be ejected, or im- pact the steering wheel or other parts of the boat. This could increase the risk of serious injury.
  • Page 100 Operation...

  • Page 101: Trimming Outboard Motor

    Operation 6. Remove the key if the boat will be left un- attended. TIP: The engine can also be stopped by pulling the cord and removing the clip from the en- gine shut-off switch, then turning the main switch to “ ” (off). HD27862 Trimming outboard motor ZMU07459...
  • Page 102 Operation...

  • Page 103: Adjusting Trim Angle For Manual Tilt Models

    Operation TIP: HD27872 Adjusting trim angle for manual tilt The outboard motor trim angle can be models changed approximately degrees There are 4 or 5 holes provided in the shifting the trim rod one hole. clamp bracket to adjust the outboard motor HD27904 Adjusting trim angle (power tilt trim an- gle.
  • Page 104 Operation...

  • Page 105: Adjusting Boat Trim

    Operation from a standing start onto plane. ZMU05579 Bow Up Too much trim-out puts the bow of the boat too high in the water. Performance and econ- omy are decreased because the hull of the boat is pushing the water and there is more air drag.
  • Page 106 Operation...

  • Page 107: Tilting Up And Down

    Operation on page 56. Never tilt the outboard mo- tor while the engine is running. Severe damage from overheating can result. Do not tilt up the engine by  pushing the tiller handle (if equipped) because this could break the handle. HD43220 Procedure for tilting up (manual tilt models)
  • Page 108 Operation...

  • Page 109: Procedure For Tilting Up (Power Tilt Models)

    Operation Hold the rear of the top cowling with one hand and tilt the engine up fully. Push the tilt support knob into the clamp bracket. Or the tilt support bar will turn lock position automatically. NOTICE: Do not use the tilt support lever or knob when trailering the boat.
  • Page 110 Operation ZMU05533 ZMU04900 2. Press the power tilt switch “ ” (up) until Push the tilt support knob into the the outboard motor has tilted up com- clamp bracket to support the engine. pletely. WARNING! After tilting the outboard motor, be sure to support it with the tilt support knob or tilt support lever.
  • Page 111 Operation...

  • Page 112: Procedure For Tilting Down (Manual Tilt Models)

    Operation switch “ ” (down) to retract the trim free. rods. NOTICE: Make sure that the Pull out the tilt support knob. trim rods retracts completely during mooring. This protects the rods from marine growth and corrosion, which could damage the power trim and tilt mechanism.
  • Page 113 Operation...

  • Page 114: Shallow Water

    Operation ZMU04901 HD28062 HD28125 Shallow water Procedure Place the remote control lever / gear HD28073 Cruising in shallow water (manual shift lever in neutral. tilt models) EWM01781 WARNING Run the boat at the lowest  possible speed when using shallow water cruising system. The tilt lock mecha- nism does not work while the shallow water cruising system is being used.
  • Page 115 Operation...

  • Page 116: Power Tilt Models

    Operation NOTICE Do not tilt the outboard motor up so that the cooling water inlet on the lower unit is above the surface of the water when set- ting up for and cruising in shallow water. Otherwise severe damage from overheat- ing can result.
  • Page 117 Operation...

  • Page 118: Cruising In Other Conditions

    Operation ter. Cruising in muddy, turbid, or acidic water Hidea strongly recommends that you use the optional chromium-plated water pump kit (see page 19) if you use the outboard motor in acidic water or water with a lot of sediment in it, such as muddy or turbid (cloudy) water.
  • Page 119 Operation...

  • Page 120: Maintenance

    When transporting and storing the such as a transom saver bar. Consult your outboard motor, disconnect the fuel Hidea dealer for further details. line from the outboard motor to HD43270 prevent fuel from leaking.

  • Page 121: Storing Outboard Motor

    Place a towel or something similar under the outboard motor to protect it from damage. Storing outboard motor When storing your Hidea outboard motor for prolonged periods of time (2 months or longer), several important procedures must be performed to prevent excessive damage.
  • Page 122 Maintenance...

  • Page 123: Procedure

    Do not touch or remove electrical TIP: parts when starting or during opera- The use of “Hidea Fuel Conditioner and tion. Keep hands, hair, and clothes Stabilizer” eliminates the need to drain the away from the flywheel and other ro- fuel system.
  • Page 124 Maintenance...

  • Page 125: Lubrication

    3. Grease all grease fittings. For further de- tails, see page 76. TIP: For long-term storage, fogging the engine with oil is recommended. Contact your Hidea dealer for information about fogging oil and procedures for your engine. HD28423 Cleaning and anticorrosion measures...

  • Page 126: Cleaning The Outboard Motor

    Reinstall the garden hose connector necessary, clean and paint the areas. A onto the fitting on the bottom cowling. touch-up paint is available from your Hidea Tighten connector securely. dealer. NOTICE: Do not leave the garden HD37012...
  • Page 127 Maintenance...

  • Page 128: Replacement Parts

    Hidea marine dealership. A service manual is available for purchase through your Hidea dealer for owners who have the mechanical skills, tools, and other equipment necessary to perform mainte- nance not covered by this owner’s manual.

  • Page 129: Maintenance Chart 1

     engine should be flushed with clean water after each use. The “ ” symbol indicates the check-ups which you may carry out yourself. The “ ” symbol indicates work to be carried out by your Hidea dealer. Initial Every...
  • Page 130 Maintenance Initial Every Item Actions hours (3 hours hours hours months) (3 years) (5 years) year) Fuel filter (can be dis- Inspection or replace- assembled) ment as necessary Fuel line Inspection Inspection or replace- Fuel line ment as necessary Inspection or replace- Fuel pump ment as necessary Fuel/engine oil leakage Inspection...

  • Page 131: Maintenance Chart 2

    (1 year) (3 years) (5 years) months) Wire harness connec- Inspection or replace- tions/wire coupler con- ment as necessary nections Fuel tank (Hidea por- Inspection and clean- table tank) ing as necessary Maintenance chart 2 Every Item Actions 1000 hours...

  • Page 132: Greasing

    Maintenance HD28933 Greasing Hidea marine grease (Water resistant grease) F15HE, F15H, F15HE/T, F20EHA, F20MHA, F20HE/T...

  • Page 133: Cleaning And Adjusting Spark Plug

    Maintenance F20HE, F20FE/T Hidea dealer. You should periodically re- HD28957 Cleaning and adjusting spark plug move and inspect the spark plug because The spark plug is an important engine com- heat and deposits will cause the spark plug ponent and is easy to inspect. The condition to slowly break down and erode.
  • Page 134 Maintenance...

  • Page 135: Checking Fuel Filter

    DPR6EB-9 or replace it. For cleaning or replacement of the fuel filter, consult your Hidea dealer. Be sure to use the specified spark plug, otherwise the engine may not operate properly. Before fitting the spark plug, measure the electrode gap with a wire thickness gauge;...
  • Page 136 Maintenance motor is in the WARNING water. A flushing Do not touch  attachment or test or remove tank can be used. electrical parts when starting or If the boat is not during operation. equipped with Keep hands,  tachometer for the hair, and clothes outboard motor, use away...

  • Page 137: Changing Engine Oil

    2. Once the engine has warmed up, verify whether the idle speed is set to specifi- cation. For idle speed specifications, see page 13. If you have difficulty verifying the idle speed, or the idle speed requires adjustment, consult a Hidea dealer other qualified mechanic. ZMU06617 Changing engine oil 1.
  • Page 138 Maintenance...

  • Page 139: Inspecting Wiring And Connectors

    Change the oil more often when  up- per and lower marks. Consult your operating the engine under adverse Hidea dealer if the oil level is out of conditions such as extended trolling. specified level. HD29114 Inspecting wiring and connectors Inspect that each connector is ...
  • Page 140 Maintenance...

  • Page 141: Checking Propeller

    Maintenance damage.  Check the propeller shaft for damage.  Check the splines for wear or damage.  Check for fish line tangled around the pro- peller shaft. ZMU02087 HD32112 Checking propeller EWM01881 could WARNING seriously injured gine accidentally starts when you are near Check the propeller shaft oil seal for ...
  • Page 142 Maintenance...

  • Page 143: Installing Propeller

    If the propeller nut does not align with the oper- ation and be lost. propeller shaft hole after tightening to the specified torque, tighten the nut further to 1. Apply Hidea marine grease or a corro- align it with the hole. sion resistant grease to the propeller shaft.
  • Page 144 Maintenance...

  • Page 145: Inspecting And Replacing Anode(S)

    [ECM00713] external anodes periodically. Remove scales TIP: from the surfaces of the anodes. Consult a For disposal of used oil, consult your Hidea Hidea dealer for replacement of external dealer. anodes. 5. Put the outboard motor in a vertical...
  • Page 146 Maintenance...

  • Page 147: Checking Battery (For Electric Start Models)

    Consult a functions will help you monitor the bat- Hidea dealer for inspection and replace- tery’s charge. If the battery needs ment of internal anodes attached to the charg- ing, consult your Hidea dealer.

  • Page 148: Disconnecting The Battery

    Maintenance Disconnect the positive cable(s) and re- ECM01124 NOTICE move the battery from the boat. Do not reverse the battery cables. Other- Clean, maintain, and store the battery wise, the electrical parts could be dam- according to the manufacturer’s instruc- aged.
  • Page 149 Maintenance...

  • Page 150: Trouble Recovery

    Q. Has fuel pump malfunctioned? If your outboard motor requires repair, bring A. Have serviced by a Hidea dealer. it to your Hidea dealer. If the engine trouble-alert indicator is flash- Q. Are spark plug(s) fouled or of incorrect ing, consult your Hidea dealer.
  • Page 151 Q. Is fuel contaminated or stale? A. Fill tank with clean, fresh fuel. Q. Is carburetor clogged? A. Have serviced by a Hidea dealer. Q. Is fuel filter clogged? A. Clean or replace filter. Q. Is fuel joint connection incorrect? A.
  • Page 152 Q. Is fuel system obstructed? Q. Is water pump or thermostat faulty? A. Check for pinched or kinked fuel line or A. Have serviced by a Hidea dealer. other obstructions in fuel system. Q. Is there excess water in fuel filter cup? Q.
  • Page 153 Trouble Recovery...

  • Page 154: Temporary Action In Emergency

    Replace it with a spare one of the proper amperage. Q. Is steering pivot loose or damaged? EWM00631 WARNING A. Tighten or have serviced by a Hidea Substituting an incorrect fuse or a piece dealer. of wire could allow excessive current HD29433 Temporary action in flow.
  • Page 155 Trouble Recovery se puller 2. Cap 3. Fuse (20 A) 4. Spare fuse (20 A) ZMU05565 1. F...

  • Page 156: Power Tilt Will Not Operate

    Trouble Recovery valve protecti per- ate. Make screw sure device remote turnin does control lever engine neutral. clock cannot be tilted Otherwise wise. up or down with boat could HD29533 power tilt unexpectedly Starter because start to move, will not discharged bat- which...

  • Page 157: Emergency Starting Engine (Manual Starter Model)

    Trouble Recovery ing normal operation. Loss of engine power means the loss of most steering control. Also, without engine power, the boat could slow rapidly. This could cause people and objects in the boat to be thrown forward. Make sure no one is standing ...
  • Page 158 Trouble Recovery repeat the procedure. If the engine fails to start after 4 or 5 tries, open the throttle a small amount (between 1/8 and 1/4) and try again. Also if the engine is warm and fails to start, open the throttle a same amount and try to start the engine again.
  • Page 159 Trouble Recovery...
  • Page 160 Trouble Recovery ZMU05613 ZMU05615 6. Secure the electrical system plate by tightening the bolt(s), and fix the plate. ZMU05624 5. Remove the starter/flywheel cover after ZMU05616 removing the bolt(s). Prepare the engine for starting. For fur- ther information, see page 48. Be sure that the gear shift is in neutral and that the clip is attached to the engine shut- off switch.

  • Page 161: Treatment Of Submerged Motor

    HD33501 Treatment of submerged motor If the outboard motor is submerged, OFF ON START immedi- ately take it to a Hidea dealer. Otherwise some corrosion may begin almost immedi- ately. NOTICE: Do not attempt to run the outboard motor until it has been com- pletely inspected.
  • Page 162 Trouble Recovery...
  • Page 163 Genuine Hidea Ac- cessories will fit right and perform right — right out of the box. Lube — Take care of your Hidea with legendary Lube oils, lubricants, and care products. They're formulated and approved by the toughest judges we know: the Hidea engineering teams that know your Hidea from the inside out.

This manual is also suitable for:

F20

Table of Contents
