CONTROL DESCRIPTIONS

All the functions can be controlled with the remote control handset.
Some functions can also be adjusted with the buttons on the front
panel of the set.
Remote control handset
Before you use the remote control handset, please install the bat-
teries. See the next page.
Displays the selected device
1.
2. MODE
selects a LG TV, VCR or DVD function.
3. TV/AV
selects the remote operating mode.
switches the set on from standby.
4. MULTIMEDIA
selects
Component 1/2 or RGB-DTV, RGB-PC
5. NUMBER BUTTONS
switches the set on from standby or directly select a number.
6. SLEEP
sets the sleep timer.
7. VOL + / - (Volume Up/Down)
Increases/decreases sound level.
PR + / - (Programme Up/Down)
selects a programme.
8. PSM (Picture Status Memory)
recalls your preferred picture setting.
9. PIP BUTTONS (option)
PIP/DW
switches the sub picture on or off.
selects PIP, POP or DW modes.
PIP PR +/-
selects a programme for the sub picture.
SWAP
alternates between main and sub picture.
PIP INPUT
selects the input mode for the sub picture.
SIZE
adjusts the sub picture size.
STILL
freezes motion of the sub picture.
POSITION
relocates the sub picture in clockwise direction.
10. MENU
M
selects a menu.
OK
11.
accepts your selection or displays the current mode.
F / G
D / E or
Adjusts menu settings.
Selects menu item.
12. DVD BUTTONS
control a LG DVD player.
13. VCR BUTTONS
control a LG video cassette recorder.
- 6 -
modes.
