over the detection range, which
leads to the smallest movement
can be detected.
• Auto off timer adjustment: 6
adjustments for time, test and
short impulse function, it is
convenient in corresponding
selection.
• Precise LUX adjustment: With
defined standard value scales for
easy and convenient adjustment.
• Built-in red LED as an indicator
for clear movement detecting
registered and easy test operation.
• Easy for installing in different
thickness of ceiling boards.
• Compact design of housing body
makes an easy installation and suit
for decor.
• RJ-12 plug and socket for quick &
easy connection.
Dimension (See FIG.1)
Detector : 50 x 38 x 43mm
Power box: 154 x 50 x 33.5mm
www.grupotemper.com
Mini presence detector
50
FIG.1
Instructions manual |
KDP9
50
11
43
19
