- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y S I N G L E - Z O N E W I N E C O O L E R EL-300COMM (APROX 188 BOTTLES) O W N E R ’...
- Page 3 Y o u r W i n e C e l l ar This unit can be used for storage and/or service. The unit has a glass door and soft interior light that you can use to display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
- Page 4 New Leaf will be there to assist! Usable for any Wine Cellar or other electronic device manufactured by Vinotemp. Add this warranty to purchases made from vinotemp.com or other qualified venders. Warranty must be registered within the first 10 days from original purchase.
-
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ............... 6 ELECTRICAL CONNECTION .................... 7 PARTS AND SPECIFICATIONS ..................8 BOTTLE CAPACITY....................... INSTALLATION ........................OPERATING YOUR WINE COOLER ................11 CARE AND MAINTENANCE ..................13 TROUBLESHOOTING ...................... 14 TERMS OF SALE AND WARRANTY ................15 SERVICE &... -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: Do not operate this or any other appliance with a damaged cord. • Do not operate if housing is removed or damaged. •... -
Page 7: Electrical Connection
ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, frayed or shows cracks or abrasions across its length, have it replaced at an authorized service center. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding- type plug, and should be used in combination with a properly connected grounding-type outlet. -
Page 8: Parts And Specifications
PARTS AND SPECIFICATIONS ① Stainless Steel Door ② Cabinet ③ Stainless Steel Handle ④ Tempered Glass Door ⑤ Return-airway ⑥ Control Panel ⑦ Fan (Upper Chamber) ⑧ Shelves ⑨ Lock ⑩ Ventilator ⑪ Leveling Legs EL-300COMM Model No. Voltage AC 115V Frequency 60 Hz -100 / Humidity... -
Page 9: Bottle Capacity
VINOTEMP EL-300COMM SINGLE-ZONE WINE COOLER BOTTLE CAPACITY You may adjust the shelves of your wine cooler to accommodate more or less bottles. If stacking bottles 2-3 high, please do not pull out the shelves. Adjust the shelves as shown to fit approximately 188 bottles in your cooler 7 3 2 S o u t h R a c e t r a c k R o a d , H e n d e r s o n , N e v a d a 8 9 0 1 5 i n f o @ v i n o t e m p . -
Page 10: Installation
INSTALLATION Remove all packing material before using your wine cooler. • IMPORTANT: Before connecting the unit to a power source, let it stand upright for approximately 24 • hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 11: Operating Your Wine Cooler
Operating Your Wine Cooler The Wine cooler should be placed in a position where the ambient temperature is between 12-38 /54-100 . Humidity level is between 45~90%. If the position is above °C °F or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cod or hot conditions may cause interior temperature to fluctuate. - Page 12 press this bottom, press to set temperature. To view the “set” temperature at any time, touch the UP or DOWN mark, the “set” temperature will temporarily “flash” in the LED display for 5 seconds. °F/°C Selector Select the temperature display setting in Fahrenheit or Celsius degree. Power To control the appliance turn on/off.
-
Page 13: Care And Maintenance
DOOR LOCK The wine cooler comes with a lock and key combination. The keys are located inside the plastic bag containing the Owner’s Manual. To unlock the door, insert the key into the lock and turn it counter-clockwise. To lock the door, insert the key and turn it clockwise, ensuring that the metal pin is fully engaged. DEFROSTING The wine cooler defrosts automatically. -
Page 14: Troubleshooting
PROBLEMS WITH YOUR WINE COOLER Most common problems can be solved easily, saving you the cost of a possible service call. Try the following suggestions to see if you can solve the problem before contacting Vinotemp at Info@Vinotemp.com. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE Ensure unit is plugged into an electrical outlet. -
Page 15: Terms Of Sale And Warranty
Return Authorization Number (RA) assigned by Vinotemp. Any unauthorized defective return to Vinotemp will be rejected at the time of attempted delivery. Return freight costs for defective product is covered by Vinotemp within the first 90 days from date of sale. For defective Return Authorizations issued after the 90th day from date of sale, the purchaser assumes responsibility for any related freight costs within the product warranty term. - Page 16 We are a manufacturer not a shipping company, deliveries are done by a 3rd party service. Email us at info@vinotemp.com for a quote or any additional information. Freight discussed is Continental USA (excluding Alaska, Puerto Rico, Hawaii), cost is additional please email info@vinotemp.com for a quote.
- Page 17 30 day period once they have been notified by Vinotemp through phone call, email, or letter that their unit is ready for pick up. If the item remains in the Vinotemp warehouse after 30 days but no longer than 60 days, the Purchaser will incur additional storage fees of 2%.
- Page 18 1. Freight: Vinotemp is not a freight, moving or installation company, if Freight is arranged for the Buyer, the Seller assumes no responsibility for the goods sold to the Purchaser once the goods have left the Seller’s premises, including, but not limited to, late delivery by the moving carrier, or for events caused by any difficulty carrier incurs in attempting to fit the goods into the Purchaser’s place of business or residence due to the size of the goods or otherwise, such as the disassembly and...
- Page 19 Note: Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any 3rd party repair facility must be pre-approved before providing parts free of charge.
-
Page 20: Service & Important Notice
Henderson, NV 89015 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
