Clemco Spin-Blast HD Manual

Internal-pipe blast tool
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
© 2009 CLEMCO INDUSTRIES CORP.
One Cable Car Dr.
Washington, MO 63090
Phone (636) 239-4300
F
(800) 726-7559
ax
Email: info@clemcoindustries.com
www.clemcoindustries.com
SPIN-BLAST HD
INTERNAL-PIPE BLAST TOOL
MC FILE NUMBER: 2336-0707
DATE OF ISSUE:
REVISION:
WARNING
Do not proceed with
these instructions*
until you have READ
the orange cover of
this MANUAL and YOU
UNDERSTAND its
contents.
These WARNINGS are
included for the health
and safety of the
operator and those in
the immediate vicinity.
*If you are using a Clemco Distributor
Maintenance and Part Guide, refer to
the orange warnings insert preceding
the Index before continuing with the
enclosed instructions.
Electronic files include a Preface
containing the same important
information as the orange cover.
O. M. 25119
July, 2007
A, 07/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spin-Blast HD and is the answer not in the manual?

Questions and answers

Related Manuals for Clemco Spin-Blast HD

Summary of Contents for Clemco Spin-Blast HD

  • Page 1 © 2009 CLEMCO INDUSTRIES CORP. One Cable Car Dr. *If you are using a Clemco Distributor Washington, MO 63090 Maintenance and Part Guide, refer to Phone (636) 239-4300 the orange warnings insert preceding...

  • Page 2: General Instructions

    DO NOT modify or substitute any Clemco parts with other The products described in this material may be combined by types or brands of equipment. Unauthorized modification...
  • Page 3 ALWAYS attach safety cables at ALL air hose AND blast 1910.244). hose coupling connections. Cables relieve tension on hose and control whipping action in the event of a coupling blow-out. • NEVER modify OR substitute remote control parts. Parts from different manufacturers are NOT compatible with Clemco...

  • Page 4: Maintenance

    • Training and Educational Programs. free of the rightful claim of any third party by way of patent Clemco Industries Corp. offers a booklet, Blast-Off 2, infringement or the like. developed to educate personnel on abrasive blast equipment 6. This warranty is conditioned upon seller’s receipt within ten function and surface preparation techniques.
  • Page 5 PREFACE □ □ 3. Clean, properly maintained NIOSH-APPROVED 8. BLAST HOSE with ID 3 to 4 times the nozzle orifice. SUPPLIED-AIR RESPIRATOR. ALL components should Lines MUST be run AS STRAIGHT AS POSSIBLE from ALWAYS be present. NEVER operate without inner lens in machine to work area with NO sharp bends.
  • Page 6 Attach a coupling that is compatible with the lance or blast hose to the tube. Note * The tool comes with a Clemco CF-3 Coupling, Stock No. 00555, which provides a quick...

  • Page 7: Compressed Air Requirements

    Remove blast head assembly (Item 1). Connect a 3/8" ID hose from the outlet side of the air motor and long enough to reach outside the Remove gasket packing gland (Item 5). pipe. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 25119...
  • Page 8 Install lock ring (Item 10) to hold bearing in position. Install spacer sleeve (Item 12) over the blast tube and against the bearing. Press bearing (Item 11) to set against spacer sleeve. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 25119...

  • Page 9: Parts List

    Lock pins, Pack of 25 ......11203 Spacer sleeve .......... 25111 Body ............25112 Service kit, air motor and gear ....25130 Tube ............25113 Stock number or ordering information available on request Figure 1 © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 25119...
