Summary of Contents for NESA NS-651
- Page 1 NS-651 2 DIN 6.5' Touch Screen DVD/CD/MP3/MP4 Player AM/FM Radio Support Bluetooth Owner‟s Manual Take the time to read through this owner’s manual. Familiarity with installation and operation procedures will help you obtain the best Performance from your new DVD-receiver.
-
Page 2: Warning
WARNING! To promote safety, certain functions are disabled unless the parking brake is on. The Unit is designed to detect parked status and must be connected to the power supply side of the parking brake switch. Improper connection or use of his connection may violate applicable law and may result in serious injury or damage. -
Page 3: Table Of Contents
CONTENTS WARNING! ......................... 2 OPERATION PRECAUTIONS ..................2 CONTENTS ........................ 3 ACCESSORIES ......................4 UNIT INSTALLATION AND REMOVAL…………………………………………………...5 WIRING CONNECTIONS ................... 6 FRONT PANEL ......................8 REMOTE CONTROL ....................9 REMOVE BATTERY ....................11 MAIN MENU ......................12 ◆ RADIO ........................12 ◆... -
Page 4: Accessories
ACCESSORIES Package contains the following accessories for installation and operation of the unit. (1) Washer, Spring 1 each Washer, M5 Nut (2) Mounting Strap (3) Bolt (4) Screw (5) Mounting Collar (6) Release Key (7) Screw (8) Rubber Cushion Remote Control User Manual Warranty card Trim ring... -
Page 5: Unit Installation And Removal
INSTALLATION / UN-INSTALLATION Note Before starting installation of the unit, make sure the wiring is connected properly. Use only the parts provided with the unit to ensure proper installation. The use of unauthorized parts may cause malfunction. Install the unit where it does not get in the driver‟s way and will not injure the passenger in case there is a sudden stop, like an emergency stop. -
Page 6: Wiring Connections
WIRING CONNECTIONS Make sure you have good chassis ground. A good ground connection will eliminate most electrical noise problems. A good chassis ground requires a tight connection to the vehicle‟s metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good electrical connection. - Page 7 After connecting, when you start up the reverse gear, the unit will receive the picture from car rear view camera. Note: Only use groundless loudspeakers. Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loudspeakers at higher volumes. Use 4~8 Ω...
-
Page 8: Front Panel
FRONT PANEL IR Sensor IR Remote control signal receiving window. Max distance is 6-8 meters, 45 angels. 2. EJECT Button Press to eject a disc. If the disc is not removed for about 10 seconds after eject, the disc is reinserted automatically. -
Page 9: Remote Control
REMOTE CONTROL 1. POWER Power on or off. 2. MODE button Press it to select the mode: Radio, DISC (if there is a disc in unit), USB (if there is a USB device in the unit), CARD (if there is a SD/MMC card in the unit) and AV IN. 3. - Page 10 11. Cursor buttons Use the buttons to select the menu item, the title track or to show next frame. 12. SETUP button In DVD mode press it to enter the setup menu. 13. EJECT button Press it to eject the disc. 14.
-
Page 11: Remove Battery
26. OSD button In DVD mode press it to enter the OSD menu, press and hold for 2 seconds to set video setup. (RED /GREEN /BLUE /BRIGHT / CONTRAST /SHARP /COLOR RESET /BACK) 27. VOL- button Press to decrease volume level. 28. -
Page 12: Main Menu
MAIN MENU The best way to discover the program is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. Unit starts by displaying the Main menu. This is the root of the screen hierarchy, and you can simply access all features by tapping on the touch screen buttons. -
Page 13: Dvd Player
Note: When a radio signal is not received, the default for ST / MO function, once received radio function automatically converted to ST. ◆DVD PLAYER To start DVD Player, tap DVD icon from main menu screen. TOUCH SCREEN MENU Touch it to skip to the previous track. Touch and hold for 2 seconds to retune to the beginning of the track. -
Page 14: Setting Control
USB device. 2. Warning displays if the vehicle is moving for driver's safety. 3. DVD Player will not only play video, but also picture and music files as well. ◆USB INTERFACE OPERATION When a USB is played, the screen will show following interface: To play MP3/ MP4 files from a USB flash memory, insert a USB flash memory into the USB port on the back of the unit. -
Page 15: Bluetooth Scetion
Audio Language: Chinese, English, Japan, French, Spanish, Portuguese, Latin and German. Subtitle Language: Chinese, English, Japan, French, Spanish, Portuguese, German and Off. Menu Language: Chinese, English, Japan, French, Spanish, Portuguese, German and Off. Sound Effect: Adjust EQ and balance surround and field. - Page 16 When the unit have connect with phone, the BT icon will turn on and the Mobile phone name (if available) will be display on the panel. According to mobile pairing device manual,after searching new device(NESA), select it, input password "0000" and confirm ok, device paring is finished.
-
Page 17: Aux-In Mode
2. In calling/Out calling mode Tap In calling button or Out calling to see received and dialed calls.The unit can download automatically all the date from the mobile Phone.Dialed/Received/Missed calls are saved In History mode .Tap Up/Down arrow load previous/next history record.The calls in each category are saved from the latest one to the final one.Select a number and tap Send button to enter calling mode. -
Page 18: Notes On Disc
NOTES ON DISC Only use groundless loudspeakers. Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loud speakers at higher volumes. Use 4~8 Ω (Ohm impedance) loudspeakers only; using higher or lesser impedance may damage the unit. -
Page 19: Troubleshooting
TROUBLESHOOTING Symptom Cause Remedy Power does not turn Replace with fuse of the same amperage. Fuse is blown If the fuse blows again, consult your store of purchase (No sound is produced.) In correct wiring Consult your local retailer. 1. Turn off the unit. 2. -
Page 20: Troubleshooting
TROUBLESHOOTING SYMPTOM CAUSE SOLUTION IF THE POWER SUPPLY IS PROPERLY THE CAR IGNITION IS CONNECTED TO THE CAR NOT ON. ACCESSORY SWITCH THE IGNITION KEY NO POWER TO “ACC”. THE FUSE IS BLOWN. REPLACE THE FUSE. DISC CANNOT BE PRESENCE OF DISC REMOVE THE DISC IN THE PLAYER LOADED. -
Page 21: Technical Specifications
TECHNICAL SPECIFICATIONS General Power supply: 11~16V DC Current consumption: max. 10 A Maximum power output: 4 x 50W channels (max) DVD/ VCD/ MP3/MP4/VIDEO /CD/CD- Compatible formats: R/-RW/DVD±R/±RW/PICTURE PLAYBACK Dimensions (W x D x H) / weight: 178*170*100 mm/2 kg Working temperature range: -20℃... - Page 25 FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
