- Page 1 SC264 System Computer Installation Manual Document Revision: A Part Number: 840-11306-01 Release Date: May 2010 Euphonix is Avid. Learn more at www.avid.com...
-
Page 2: Regulatory And Safety Notices
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at personal expense. Euphonix is Avid. Learn more at www.avid.com... -
Page 3: Canadian Ices-003
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecté toutes les exigences du Règlement sur le matériel brouilleur du Canada. Euphonix is Avid. Learn more at www.avid.com... -
Page 4: European Union Declaration Of Conformity
Verantwortung,daß dieses Produkt, déclarons sous notre seule responsabilité que le produit, declaramos, bajo nuestra sola responsabilidad, que el producto, verklaren onder onze verantwoordelijkheid, dat het product, dichiariamo sotto nostra unica responsabilità, che il prodotto, Euphonix is Avid. Learn more at www.avid.com... - Page 5 è conforme alla/e seguente/i norma/o documento/i normativo/i. The requirements of the European Council: Safety: Directive 2006/95/EC EN 60065:2002 /A1:2006 EMC: Directive 2004/108/EC EN 55103-1:1996 EN 55103-2:1996 Euphonix is Avid. Learn more at www.avid.com...
-
Page 6: Led Safety Notices
Optical connections are located on the rear panel and are typically labeled “Optical” or “SPDIF/ADAT.” The exact location of optical connections is identified more clearly elsewhere in the documentation for the Avid hardware device. Euphonix is Avid. Learn more at www.avid.com... -
Page 7: European Union
• Circuit Overloading — Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. Euphonix is Avid. Learn more at www.avid.com... -
Page 8: Lithium Battery Replacement
Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. VAROITUS Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. Euphonix is Avid. Learn more at www.avid.com... - Page 9 Redundant PSU’s Front Panel Power Switch and Status Indicators: See Status Module below. Software Status Indicator: The blue “wave” in the Euphonix logo lights up to indicate the software in the SC264 is operating correctly. Status Module Power Switch: Turns the unit on or off.
- Page 10 12. Power Connectors (IEC): Accepts two standard IEC power cords (provided). Two auto ranging switching supplies accept voltages between 100–240 VAC, 50–60 Hz. 13. Serial Port 1 (DE-9): Com1; currently not used. (Com2 is wired internally to the SNMP board’s Com port.) Euphonix is Avid. Learn more at www.avid.com...
-
Page 11: Specifications
Specifications SC264 Technical Specification Power Requirements 100-250 VAC; 50 or 60 Hz (Auto-ranging) Power Consumption 8-4A Tempreture of Operation 5-35 º Dimensions H 177mm W 482mm L 482mm Weight 20kg Heat Dissipation 685BTU/hr Euphonix is Avid. Learn more at www.avid.com...
