OWNER'S
MANUAL
MODEL NO.
390.304050
CAUTION:
Read and Follow
All Safety Rules and
Operating Instructions
Before First Use of
This Product.
Save This Manual For
Future Reference.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
PRINTED IN U.S.A.
CRAFTSMAN
SUBMERSIBLE
SEWAGE PUMP
• Safety Instructions
• Installation
• Electrical
• Service
• Repair Parts
F642-9307
Form No.
(Rev. 3/6/97)
Advertisement
Table of Contents
Related Manuals for Sears CRAFTSMAN 390.304050
Summary of Contents for Sears CRAFTSMAN 390.304050
- Page 1 • Safety Instructions Before First Use of This Product. • Installation • Electrical Save This Manual For Future Reference. • Service • Repair Parts Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. PRINTED IN U.S.A. F642-9307 Form No. (Rev. 3/6/97)
- Page 2 PARTS ........7 FULL ONE YEAR WARRANTY ON SEARS SUBMERSIBLE SUMP PUMPS During the first year after the date of purchase, Sears will repair or replace this pump, free of charge, if defective in materials or workmanship.
- Page 3 (2 feet per second in discharge line), size pipe Two-inch (2”) plastic or steel pipe, fittings or clamps needed as follows: to do your job. We recommend a check valve, Sears stock no. 2791. A Pipe Size Of: Will Handle a Flow Rate Of: 2”...
- Page 4 A Circuit Analyzer will tell you by a pattern of lights if the power, neutral, and ground wires are correctly connected to your outlet. It can also be used to check other outlets in 3-1/2" your home. A Circuit Analyzer is available in the Sears Electrical Department. UL Listed Analyzer...
- Page 5 If a, b, and c above check OK, plug in a light that you Take it to Sears for service by a qualified technician. know works. If it lights, take your pump to Sears for service. If it doesn’t light, the electrical circuit is faulty;...
- Page 6 SERVICE Disassembly Reassembly Notice: Submerge complete pump in a T-Handle disinfectant solution ( chlorox or chlorine ) for at least one hour before disassembling pump. Upper Volute Housing Screwdriver Turn impeller counter-clockwise Impeller slot hand tight. Lower Volute Housing Volute Screw ( 11 Places ) 783 0394 Figure 6...
- Page 7 P/N PS17-54 Pump will have either Y-Cord arrangement (item 5) Motor or Power Cord / Switch arrangement as shown (see note) above. To Order Parts in the U.S.A., Call Sears Product Service, 1-800-366-7278 Repair Parts List Part Part Number Description U30-937SS...
- Page 8 Maintenance Agreement or to inquire about an existing Agreement information: call 9 am - 5 pm, Monday-Saturday 1-800-827-6655 • Product Type • Model Number • Part Number REPAIR SERVICES • Part Description America's Repair Specialists Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
