Briggs & Stratton 020507 Quick Start Up/Shutdown Manual

The quick start up/shutdown guide is not a substitute for
reading the manual; the manual contains detailed
information and instructions that you must be aware of and
follow in order to maintain the equipment properly and use it
safely. Remember to record the date of purchase and model number in
your manual.
Items Included:
Items needed:
(not included)
• Grease
• Garden hose, 50 ft. (15 m) or less
• Safety goggles (indirect vented type)
• Adjustable Wrench
WARNING! USE OUTDOORS - AVOID CARBON MONOXIDE POISONING
(SEE MANUAL)
Start Up
7
1
Purge System
Place Outdoors
2 8
Connect Spray Tip
Working CO Alarms
and Wand to Gun
9
3
Add Oil and Fuel Throttle Fast
4
10
Lubricate O-Rings
5
11
Connect Hose
6
Connect Garden Hose
Outdoor
Use Only
12
Pull Recoil
13
Run
Shutdown
1
Throttle Stop
2
Fuel On
Fuel Off
3
Choke
Purge System
QUICK START UP / SHUTDOWN GUIDE
Replace Pump Oil Cap
NOTICE Failure to install vented
plug/dipstick will result in a pump
failure and void the warranty.
Spray Tips
Fuel Cap
Throttle Lever
Choke Lever
Fuel Shut-off
Lever
Recoil Starter
Copyright © 2020. All rights reserved. Briggs & Stratton, LLC. Milwaukee, WI, USA. No part of this
material may be reproduced or transmitted in any form without the express written permission of
Briggs & Stratton, LLC.
Every effort has been made to ensure that the information in this document is accurate and correct.
However, we reserve the right to alter or otherwise improve the product and this document at any
time without prior notice and without incurring obligation.
(800) 743-4115
BRIGGSandSTRATTON.COM
WARNING! Risk of eye injury. Spray could splash
back or propel objects resulting in serious injury.
• Always wear indirect vented (chemical splash) safety
goggles when using or near this product.
• Always wear protective clothing such as long-sleeved shirts,
long pants and closed-toed shoes.
Handle Attachment
Spray Gun
High Pressure
Hose
Spray Wand
High Pressure
Outlet
Water Inlet
Oil Fill/Dipstick
80098561 Rev. A
