- Page 1 Round Rack Setbacks 36" 36" 30" ©2021...
- Page 2 Round Rack Installation Surface Mount TOOLS NEEDED RECOMMENDED BASE MATERIAL Tape Measure Solid concrete is the best base material for installation. To ensure the proper anchors Marker or Pencil are shipped with your rack, ask your Dero Rack representative which anchor is Masonry Drill Bit 3/8”...
- Page 3 Round Rack Maintenance TOOLS NEEDED Level Trowel Cement mixing tub Corrosion-Resistant Sleeve (min. 3” diameter) Shovel Materials to build brace (see “Install Tip” at bottom of page) Poured concrete Sleeves (4-7” deep) Final grade level Sand pour bed Place corrosion resistant sleeve (min. 3” inside diameter) in sand Pour concrete and allow to cure.
- Page 4 Round Rack Installation In-Ground Mount : Existing Concrete TOOLS NEEDED Level Trowel Cement mixing tub Hole coring machine with 4” bit Shovel Materials to build brace (see “Install Tip” at bottom of page) Access to water hose Ø 3” min. 10”...
- Page 5 Round Rack Installation Footing Diagrams IN-GROUND MOUNT SURFACE MOUNT 12” 18” 36” 10” 24” (or standard 4” sidewalk slab) ©2021...
