DH Wireless Solutions PDN LITE OOBM Field Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PDN LITE
Field Manual
OOBM
FIELD MANUAL
1
877.524.0430

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDN LITE OOBM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DH Wireless Solutions PDN LITE OOBM

Summary of Contents for DH Wireless Solutions PDN LITE OOBM

  • Page 1 PDN LITE Field Manual OOBM FIELD MANUAL 877.524.0430...

  • Page 2: Table Of Contents

    PDN LITE Field Manual OOBM Table of Contents PAGE Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 What’s Inside .

  • Page 3: Welcome

    LITE can be utilized as a source of high speed LTE Internet access by ® OOBM providing a direct connection through its external Ethernet ports. Sincerely, DH Wireless Solutions WHAT’S INSIDE AGM Batteries 15.8” Cable Pouch Field Manual Quick Start /...

  • Page 4: Getting To Know Your Pdn

    PDN LITE Field Manual OOBM GETTING TO KNOW YOUR PDN 10 10 10, 12 www.portablessupport.com...
  • Page 5 PDN LITE Field Manual OOBM PART Quick Start Guide / Troubleshooting: Get connected and start working immediately with this accessible reference guide . Main Power Switch: Connects or disconnects power supply . Should always be “ON,” except during travel mode . Antenna: Low profile, enables critical communications .

  • Page 6: General Use

    PDN LITE Field Manual OOBM GENERAL USE Auxiliary Main Power Switch If battery charge is DC POWER PORT (12V DC) low and an AC power Main Power Switch must be in source is unavailable, use the DC the “ON” position for the PDN Power Port to power the device .

  • Page 7: Quick Start Guide

    PDN LITE Field Manual OOBM Quick Start Guide – Failover 1 . Verify Main Power Switch is in “ON” position . 2 . Plug PDN Lite to available AC power source for power/charging . OOBM • Battery power will initiate should power outage event occur . 3 .

  • Page 8: Transport

    PDN LITE Field Manual OOBM Transport Your PDN is TSA friendly and suitable for carry-on . When traveling by airplane, the Main Power Switch must be turned “OFF,” cutting power to the PDN . WARNING To reduce risk of injury or electric shock, turn Main Power Switch to “OFF”...

  • Page 9: Monthly Maintenance Checks

    PDN LITE Field Manual OOBM MONTHLY MAINTENANCE CHECKS We recommend monthly maintenance checks of the unit for optimal functionality . (See pages 16–19 for a convenient Maintenance Log .) The steps below should be followed every month to ensure unit is ready when needed: 1 .

  • Page 10: Troubleshooting

    PDN LITE Field Manual OOBM TROUBLESHOOTING 1 . If unit fails to power up, check to ensure Main Power Switch is in the “ON” position . Then check the Battery Gauge to ensure batteries are sufficiently charged . Unit can run at the same time it is being charged by AC power source . 2 .
  • Page 11 PDN LITE Field Manual OOBM Problem/ Possible Possible Verification Symptom Cause Corrections Battery gauge displays Open case and ensure Main power a red LED signal only Main Power Switch in the switch is when batteries are upper left corner of in “OFF”...
  • Page 12 PDN LITE Field Manual OOBM Problem/ Possible Possible Verification Symptom Cause Corrections Use a voltmeter to check The DC Change the external DC source voltage. Ensure source source or switch to a power voltage source has a voltage may source with adequate minimum of 9 volts DC be too low charge and voltage.
  • Page 13 PDN LITE Field Manual OOBM Problem/ Possible Possible Verification Symptom Cause Corrections Reverse battery connections Remove service cover. ensuring positive red wire Reverse Check LED lights on battery is connected to positive polarity charger. If orange solid LED red battery terminal and of battery appears, battery polarity is negative black wire is...

  • Page 14: Warranty

    PDN LITE Field Manual OOBM WARRANTY Your PDN includes a comprehensive support services and limited warranty plan . See your service plan for details or contact DHWS at www .portablessupport . c om or 877 .524 . 0 430, option 3 . WARNING To reduce risk of injury or electric shock, turn Main Power Switch to “OFF”...

  • Page 15: Important Safety Instructions & Warnings

    PDN LITE Field Manual OOBM Read entire Field Manual before using your PDN. IMPORTANT SAFETY MEASURES & WARNINGS The following list alerts users of proper usage to avoid potentially hazardous situations that could result in minor or moderate injury or damage to the product or property: - Do not use PDN for any purpose other than described in this manual .

  • Page 16: 12-Month Maintenance Log

    PDN LITE Field Manual OOBM 12-MONTH MAINTENANCE LOG DATE INITIALS INSPECTION NOTES / COMMENTS www.portablessupport.com...
  • Page 17 PDN LITE Field Manual OOBM 12-MONTH MAINTENANCE LOG DATE INITIALS INSPECTION NOTES / COMMENTS 877.524.0430...
  • Page 18 PDN LITE Field Manual OOBM 12-MONTH MAINTENANCE LOG DATE INITIALS INSPECTION NOTES / COMMENTS www.portablessupport.com...
  • Page 19 PDN LITE Field Manual OOBM 12-MONTH MAINTENANCE LOG DATE INITIALS INSPECTION NOTES / COMMENTS 877.524.0430...
  • Page 20 PDN LITE Field Manual OOBM Place "My PDN" Label Here 175 Hill Brady Road Battle Creek, MI 49037 877.524.0430 www.dhm2m.com www.portablessupport.com © Digital Highway, Inc., ver. LO2011...
