Summary of Contents for MIKOTERM mControl HT400
- Page 2 THE CONTENT: WHAT IS SMART ROOM THERMOSTAT? HOW DOES SMART ROOM THERMOSTAT WORKS? WHAT ARE ADVANTAGES OF SMART ROOM THERMOSTAT HT400? RULES TO BE CONSIDERED FOR SAFETY HT400 AND EQUIPMENTS TECHNICAL DATA HT400 RECEIVER HT400 RECEIVER PLACEMENT HT400 RECEIVER SETUP HT400 SMART ROOM THERMOSTAT RESET AND SYNCHRONIZATION HT 400 ROOM THERMOSTAT PLACEMENT HT 400 ROOM THERMOSTAT SETUP...
- Page 3 WHAT IS SMART ROOM THERMOSTAT? Smart Room Thermostat is a device which allows you to control your heating equipment via App even you are not at home. 1.1 HOW DOES SMART ROOM THERMOSTAT WORKS? HT 400 Smart Room Thermostat with its 0.1 measurement accuracy helps you to keep your living area temperature as you set. This saves up to 30% on your bills by preventing the heating unit running unnecessarily.
-
Page 4: Technical Data
1.5 TECHNICAL DATA Room Thermostat Technical Data Feeding Voltage 5V (DC) Load Current 250 mA maximum Dimensions 90mm / 45mm Measurement Accuracy C – 1.0 Temperature Setting Accuracy Working Accuracy C) – (+50 Operating Temperature (-10 C) – (+60 Storage Temperature (-20 Modem Technical Data Feeding Voltage... - Page 5 At the following link you can watch a video that describes in detail the procedure for connecting the receiver: https://www.youtube.com/watch?v=EPZexrCDGdA or on the Mikoterm YouTube channel which you can reach through our site or by loading the following QR code:...
- Page 6 HT400 SMART ROOM THERMOSTAT RESET AND SYNCHRONIZATION Chapter 2.2 describes the synchronization procedure in more detail HT 400 ROOM THERMOSTAT PLACEMENT Place your room thermostat in a room where you most use it as your living area. For example: living room. Avoid installing the room thermostat where there is a lot of air circulation such as door entry or window edges.
- Page 7 https://www.youtube.com/watch?v=vjmHbMTPg9g&t or on the Mikoterm YouTube channel which you can reach through our site or by loading the following QR code: Note: in order to synchronize the thermostat with the home network, you must make sure that the frequency of the Wi- Fi network is 802.11 b / g / n @ 2.4GHz.
- Page 8 THERMOSTAT CONTROL THROUGH APPLICATION NOTE: if your mobile phone is set to Serbian and the application will be installed in Serbian. While if your mobile is set to English or any other language, an English language application will be installed during installation. After the correct installation of the mC HT400 application, connection and synchronization, starting the mC HT400 application, you will get image 1 on the phone screen.
- Page 9 MODES By clicking on one of the modes from image 2, the thermostat switches the operation to the selected mode (pictures 3,4,5,6,7,8). image 4 – image 5 – image 3 – home mode outside mode manual mode image 6 – image 7 –...
- Page 10 OPERATING MODE ADJUSTMENT To adjust the operating mode parameters, go to the settings by clicking on the menu icon - image 9, after which the image application menu - 10 opens. By selecting modes / modes, you enter the operating mode settings - image 11. Here you can set the temperature for each operating mode individually, so that when you select a specific operating mode (image 3,4,5,6,7,8) the thermostat will operate according to the settings you set as in image 11.
-
Page 11: Location Mode
LOCATION MODE On the smart location setting page, you can specify the distance (circle radius) from your station (thermostat). The location mode of the thermostat works so that when you enter within the circuit you set by setting the distance, the thermostat will automatically set the boiler one temperature and when you leave the circuit another temperature. - Page 12 image 16 image 17 image 18 image 20 image 21 image 19...
- Page 13 MANUAL, HOME, SLEEP AND OUTSIDE MODES Manual mode allows you to adjust the current temperature you want in your home using the "up" or "down" arrows. Active manual mode (image 2 and 3). Home mode is used when you are at home and a temperature of 23 C is recommended.
- Page 14 image 25 image 26 image 24 image 28 image 27...
- Page 15 Reports - provides an overview of the previous operation of the thermostat where weekly, monthly or 6-monthly reports can be viewed (image 29). Weather forecast - provides a daily and weekly overview of weather conditions for the place where your thermostat is located (image 30).
-
Page 16: Declaration Of Conformity
WARRANTY CONDITIONS AND STATEMENTS DECLARATION OF CONFORMITY mControl Brand: Product Name: HT400 Product Type: Smart Room Thermostat The product is connected wirelessly at 2.4 Ghz internet and periodically shares the temperature and status information with the server on the internet. Compatible Directives: Radio and Telecommunication Terminal Equipment Regulation 2014/53/EU (R&TTE/RED EN 301 489-1 V2.1.1:2017, EN 300 220- 1 V3.1.1:2017, EN 301 489-3 V2.1.1:2017, EN 300 220-2 V3.1.1:2017, EN 62479: 2010, EN 60730-2-9:2010, EN 60730-1:2011)
