- Page 1 H-T100 Installation and Operation Manual English MAEN834A 2007-11...
- Page 2 Please read the entire installation manual prior to installing and using this equipment. Only qualified per- sonnel may install, operate or repair this equipment. Beijer Electronics AB is not responsible for modified, altered or renovated equipment. Because the equipment has a wide range of applications, users must acquire the appropriate knowledge to use the equipment properly in their specific applications.
-
Page 3: Table Of Contents
Key Pad..................21 Bench and Function Tests ............22 Setting Communication Parameters ........... 22 Downloading an Application ............. 23 Uploading an Application ............24 Uploading/Downloading a Recipe ..........25 Copying an Application ............. 26 7.10 Passwords................... 27 Beijer Electronics, MAEN834A... - Page 4 Contents Beijer Electronics, MAEN834A...
-
Page 5: Safety Precautions
– The supplier neither guarantees that the operator terminal is suitable for your particular application, nor assumes responsibility for your product design, in- stallation or operation. Beijer Electronics, MAEN834A... - Page 6 Dismantling and Scrapping – The operator terminal or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: lithium battery, electrolytic capacitor and display. Beijer Electronics, MAEN834A...
-
Page 7: Installation
Installation Installation Package Contents The following parts are found in the box: – Operator terminal H-T100 – 8 installation fasteners – Power connector (connected to the 24 V DC power outlet) – This installation and operation manual (MAEN834A) Beijer Electronics, MAEN834A... -
Page 8: Product Specifications
Ambient humidity 20 - 90% RH non-condensed Vibration endurance 0.5 mm displacement, 10-55 Hz, 2 hours per X-, Y- and Z-axis directions Shock endurance 10 G, 11 ms 3 times in each direction of X-, Y- and Z-axes Beijer Electronics, MAEN834A... - Page 9 Product Specifications Parameter H-T100 RF emissions CISPR 22, Class A Electrostatic Discharge IEC61000-4-2 RF susceptibility IEC61000-4-3 High frequency transients IEC61000-4-4 Cooling Natural cooling Beijer Electronics, MAEN834A...
-
Page 10: Description Of Parts
Function keys Power lamp Communication lamps Network lamp Display Back DC power outlet COM1: RS232/RS485 Compact Flash card connection COM2: RS232/RS422/RS485 DIP switches (1-12) USB connector for printer/memory stick COM3: RS422/RS485 Network connection USB connector for transmission Beijer Electronics, MAEN834A... -
Page 11: External And Cut-Out Dimensions
Product Specifications External and Cut-out Dimensions Unit: mm CUTOUT DIMENSION Mounting Procedure 1. Cut out the control front panel to match the dimensions (mm) below. Beijer Electronics, MAEN834A... -
Page 12: Grounding
3. The operator terminal is to be installed within the angle of 0 to 135 shown below. Grounding To make sure that the operator terminal works properly and to prevent it from radiating radio frequency noise, it must be connected to the earth ground. Beijer Electronics, MAEN834A... -
Page 13: Power Supply And Wiring
Product Specifications Power Supply and Wiring H-T100 must use the power supply with 24 V DC and the power consumption is 30W. Warning: To avoid an electrical shock, be sure to switch off the power before connecting the communication/download cable to the operator terminal. -
Page 14: Dip Switches
The default user level is set to 9 if the operator terminal requires no password to start its operation. COM1 Port For RS485, this switch has to be set ON. For RS232, this switch has to be set OFF. Beijer Electronics, MAEN834A... - Page 15 For RS485, this switch has to be set ON. For RS422, this switch has to be set OFF. SW11 COM3 Port For RS485, this switch has to be set ON. For RS422, this switch has to be set OFF. SW12 Reserved Beijer Electronics, MAEN834A...
-
Page 16: Communication Ports
Function Function RS485+ RS422 TX+ (RS485+) RS232 RXD RS422 CTS+ RS232 TXD RS422 CTS- RS422 RX+ Signal ground Signal ground RS485- RS422 TX- (RS485-) RS232 RTS RS422 RTS+ RS232 CTS RS422 RTS- Optional; RS422 RX- +5V@100mA output Beijer Electronics, MAEN834A... - Page 17 25 24 23 19 18 Function Function RS422 TX+ (RS485+) RS232 TXD RS422 TX- (RS485-) RS232 RXD RS422 RX+ RS232 RTS RS422 RX- RS232 CTS Signal ground Optional; +5V@100mA output RS422 RTS+ RS422 RTS- RS422 CTS+ RS422 CTS- Beijer Electronics, MAEN834A...
-
Page 18: Touch Screen Calibration
2. Follow the route on the screen. 3. Touch the square on the center of the screen to complete the task. Note: When using the F4 - Set command all RAM data will be cleared. See also section 7.2 System Menu. Beijer Electronics, MAEN834A... -
Page 19: Operation
The results of the self-test will be displayed on the screen according to the following picture. Human Machine Interface ROM BIOS Version 1.0 (C) 2006 Beijer Electronics AB H-T100 Display Type = Color TFT LCD System RAM Size ... 16M Bytes Video RAM Size .... -
Page 20: System Menu
+ and - to set the value of the field. F3 - Copy Copies application data to another H-T100. F4 - Set Calibrates the touch screen and clears RAM data. See also section 6 Touch Screen Calibration. -
Page 21: Key Pad
Operation Key Pad The eight keys on the H-T100 include one menu key and seven functional keys (F1-F7), described below. Press the menu key to slide out the innovative slide- out menu. The functional keys can also be defined in H-Designer and used as “Quick- buttons”, for example, to set an ON/OFF value, to change a screen etc. -
Page 22: Bench And Function Tests
Bench and Function Tests Set dip switches SW3 and SW4 = OFF to be able to run the bench and function tests for the H-T100. Turn on the operator terminal to display the following screen: The bench test performs an overall hardware test, and the function test lets the user select which item to be tested. -
Page 23: Downloading An Application
Operation Downloading an Application Connect the RS232 port on the PC to the COM1 port on the H-T100 using a WPC-P8-42 cable, or to the COM2 port using a WPC-P8-41 cable. The connection can also be made according to the illustration below, where the... -
Page 24: Uploading An Application
Open dialog. Open the uploaded application file (*.C64 or *.AA6). The application screen will be displayed on the PC monitor. Finally, select File/ Save As to save the application as a *.V6F file. Thus a source file can serve the purposes of maintenance and modification. Beijer Electronics, MAEN834A... -
Page 25: Uploading/Downloading A Recipe
Also remember to upload the format of recipes from the operator terminal before starting to edit a new set of recipe data in the PC. For further information about creating/editing recipes, please see the corre- sponding chapter in the H-Designer User’s Manual. Beijer Electronics, MAEN834A... -
Page 26: Copying An Application
Operation Copying an Application To copy an application from one H-T100 to another H-T100, select F3 - Copy from the system menu. Set the dip switch SW7 = ON and connect the two operator terminals with a download cable. After the self-test, the system menu will be displayed on the screen. -
Page 27: 7.10 Passwords
2. User level 1 has the highest privilege and User level 9 has the lowest. Note: Only users of User Level 1 has the right of access to the password table. Beijer Electronics, MAEN834A... - Page 28 When selecting F3 - Copy in the system menu or File/Upload Application in H-Designer, the operator terminal will prompt for a password. The user will need to enter the correct password to copy an application from one H-T100 to another. Note that setting this password is different from the passwords set in Scenarios 1-3.
- Page 29 Head Office Subsidiary Subsidiary Subsidiary Beijer Electronics AB Beijer Electronics GmbH Beijer Electronics Inc. Hitech Electronics Corp. Box 426 Zettachring 2A 939 North Plum Grove Road, Suite F 4th Fl., No. 501-15, Chung-Cheng Rd. 201 24 Malmö, Sweden DE-705 67 Stuttgart, Germany US-Schaumburg, IL 60173, USA Shin-Tien, Taipei Shien, Taiwan, R.O.C.
