- Page 1 CycleSafe, Inc. OCTO-RACK High-Capacity Bicycle Parking INSTALLATION & ASSEMBLY INSTRUCTIONS www.cyclesafe.com info@cyclesafe.com 616.954.9977 888.950.6531...
-
Page 2: Table Of Contents
Comments in BLUE are helpful Comments in BLACK are Comments in RED are warnings suggestions Instructions ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 2 of 10 Printed: 9/20/2021... -
Page 3: Introduction
Introduction This Installation & Assembly Instruction will detail the tools required, fasteners and components furnished, and assembly steps to successfully install the CycleSafe Octo Rack High Density Bicycle Parking System. Please read the instructions completely before beginning. Identify & inventory all parts using the packing list furnished with the shipment and the parts list in this Installation Instruction. -
Page 4: Parts List
Parts List This Installation & Assembly Instruction will detail the tools required, fasteners and components furnished, and assembly steps to successfully install the CycleSafe Octo Rack High Density Bicycle Parking System. Item Description Part Number FRONT SUB-FRAME ASSEMBLY 18301 BACK SUB-FRAME ASSMBLY... -
Page 5: Configuration Layout
ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 5 of 10 Printed: 9/20/2021... -
Page 6: Front Frame Assembly
{S/S} Torx BHCS x 1' Lg. (17274) and square up Front Frame Assembly (18301) and then tighten as above. ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 6 of 10 Printed: 9/20/2021... -
Page 7: Rear Frame Assembly
{S/S} Torx BHCS x 1' Lg. (17274) and square up Back Frame Assembly (18302) and then tighten as above. ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 7 of 10 Printed: 9/20/2021... -
Page 8: Main Frame Assembly
Front with (4) 3/8-16NC {S/S} Torx BHCS x 1" Lg. (12724) square up and tighten Bolts. ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 8 of 10 Printed: 9/20/2021... -
Page 9: Wheel Guide Assemblies
GUIDE RAILS Item Description Part Number UPPER WHEEL GUIDE ASSEMBLY 18304 LOWER WHEEL GUIDE ASSEMBLY 18305 ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 9 of 10 Printed: 9/20/2021... -
Page 10: Rack Assembly
(12724) and tighten, then repeat for the remainimng (6) Guide Rails alternating as shown till completion. ALWAYS OBSERVE POSTED SAFETY GUIDELINES WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES Octo-Rack Assembly Instructions.xlsx CONTROLLED DOCUMENT Sheet 10 of 10 Printed: 9/20/2021...
