Sheldon Manufacturing Inc. P.O. Box 627 Cornelius, Oregon 97113
EMAIL:
tech@Shellab.com
1-800-322-4897
ECONOMY INCUBATOR
INSTALLATION AND OPERATIONAL MANUAL
INTERNET:
http://www.Shellab.com/~Shellab
(503) 640-3000
SMI1E & SMI1E-2
SMI2E & SMI2E-2
Previously Designated as:
EI1 & E1-2
EI2 & E2-2
11/2013
4861571
FAX (503) 640-1366
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for shelolab SMI1E
Summary of Contents for shelolab SMI1E
- Page 1 ECONOMY INCUBATOR SMI1E & SMI1E-2 SMI2E & SMI2E-2 Previously Designated as: EI1 & E1-2 EI2 & E2-2 11/2013 4861571 INSTALLATION AND OPERATIONAL MANUAL Sheldon Manufacturing Inc. P.O. Box 627 Cornelius, Oregon 97113 EMAIL: tech@Shellab.com INTERNET: http://www.Shellab.com/~Shellab 1-800-322-4897 (503) 640-3000 FAX (503) 640-1366...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1.0 RECEIVING AND INSPECTION SECTION 2.0 GRAPHIC SYMBOLS SECTION 3.0 INSTALLATION SECTION 4.0 CONTROL PANEL OVERVIEW SECTION 5.0 OPERATION SECTION 6.0 MAINTENANCE SECTION 7.0 TROUBLESHOOTING SECTION 8.0 PARTS LIST UNIT SPECIFICATIONS SCHEMATICS These units are general purpose air incubators for professional, industrial or educational use where the preparation or testing of materials is done at approximately atmospheric pressure and no flammable, volatile or combustible materials are being heated. -
Page 3: Receiving And Inspection
Section RECEIVING AND INSPECTION Your satisfaction and safety require a complete understanding of this unit. Read the instructions thoroughly and be sure all operators are given adequate training before attempting to put the unit in service. NOTE: This equipment must be used only for its intended application;... -
Page 4: Graphic Symbols
Section GRAPHIC SYMBOLS Your incubator is provided with a display of graphic symbols to help in identifying the use and function of the available adjustable components. This symbol, when shown, indicates that you should consult your manual for further description or discussion of a control or item. -
Page 5: Installation
Section INSTALLATION Local city, county or other ordinances may govern the use of this equipment. If you have any questions about local requirements, please contact the appropriate local agency. Installation may be performed by the end user. Under normal circumstances this unit is intended for use indoors, at room temperatures between 5 above ambient to 70C, at no greater than 80% Relative Humidity (at 25C) and with a supply voltage that does not vary by more than 10%. - Page 6 Shelf Placement: Place the two shelves in the desired position. See Figure 1. Figure 1...
-
Page 7: Control Panel Overview
Section CONTROL PANEL OVERVIEW Power Switch: The main power I/O (on/off) switch controls all power to the unit and must be in the I or ON position before any systems are operational. Temperature Controller: The controller is marked SET TEMPERATURE and is equipped with an adjustment knob and a graduated dial. -
Page 8: Operation
Section OPERATION Check power supply against unit serial plate; they must match. Plug service cord into the grounded electrical outlet and turn the power switch ON. Thermometer Placement: Place the thermometer and clip (provided in the accessory kit) through the hole at the top of incubator. The thermometer is to verify operating temperature. -
Page 9: Maintenance
Section MAINTENANCE NOTE: Prior to any maintenance or service on this unit, disconnect service cord from the power supply. Cleaning: Clean interior of the incubator on a regular basis. Remove shelves and shelf clips and sterilize the incubator with a disinfectant that is appropriate for your application. -
Page 10: Troubleshooting
Section TROUBLESHOOTING FOR PERSONAL SAFETY, ALWAYS DISCONNECT THE POWER BEFORE SERVICING. Always make a visual inspection of the incubator and control panel when troubleshooting. Look for loose or disconnected wires that may be the source of the trouble. TEMPERATURE Temperature too high 1/ controller set too high-see section 5.3 2/ controller failed on –... - Page 11 MECHANICAL Door not sealing 1/ check physical condition of gasket 2/ assure that gasket is in original location 3/ Verify that door latch is operating correctly and not miss-aligned or broken. OTHER Unit or wall fuse/circuit breaker is blown 1/ check wall power source. 2/ compare current draw and compare to specs on data plate.
-
Page 12: Parts List
Section PARTS LIST Description 115V 220V Circuit Breaker 1100505 Fuse 3300515 Fuse Holder 3300501 Heating Element 2350562 2350500 HEATING Pilot Lamp 4650554 4650554 I/O Switch 7850579 7850579 Inlet With Fuse Holder 4200505 Power Cord, European 1800500 Power Cord, USA 1800529 Temperature Controller 1750813 1750813... -
Page 13: Unit Specifications
UNIT SPECIFICATIONS Dimensions WxDxH Weight Temperature Capacity Unit C Cubic Ft Exterior Interior Shipping SMI1E (EI1) 16.75x17.75x22.25 12x12x14 53 lbs. 44 lbs. Amb. +5-70 SMI1E-2 (EO1-2) SMI2E (EI2) 21.5x18x25.5 17x12x17 71 lbs. 57 lbs. Amb. +5-70 SMI2E-2 (EI-2) - Page 14 WIRE DIAGRAM SMI1E (E1)110V POWER CORD 1800529 FUSE POWER SWITCH 7850579 CONTROL THERMOSTAT 1750860 HEATING LIGHT 4650554 120V 250W...
- Page 15 WIRE DIAGRAM SMI2E (EI2) 110V POWER CORD 1800529 FUSE POWER SWITCH 7850579 CONTROL THERMOSTAT 1750860 HEATING LIGHT 4650554 120V 250W...
- Page 16 WIRE DIAGRAM SMI1E-2 (EI1-2) 220V FUSED INLET 4200505 FUSE 2800502 EMI FILTER POWER SWITCH 7850579 TOP ½ CONTROL BOTTOM ½ CONTROL 1750813 1750813 HEATING LIGHT 4650554 125 WATTS...
- Page 17 WIRE DIAGRAM SMI2E-2 (EI2-2) 220V FUSED INLET 4200505 FUSE 2800502 EMI FILTER POWER SWITCH 7850579 TOP ½ CONTROL BOTTOM ½ CONTROL 1750813 1750813 HEATING LIGHT 4650554 120V 125 WATTS 120V 125 WATTS...
