  • Page 1 MultiSpot HT3030 (HP3) ® Exclusive USA Distributor...

  • Page 2: Product Description

    Introduction Since 1992, Apollo Design Technology, Inc. has been one of the world’s leading innovators, manufacturers and distributors of gobos, color filters, lights and related equipment and accessories for the lighting industry. We are continually engineering new products to help you create and execute the designs of your dreams for theaters, bands, advertising, touring companies, television, motion pictures, museums, retail and architecture.
  • Page 3 USER MANUAL MULTISPOT G-II-HS3045 / HT3030 High-Power DMX-Controlled LED light source For firmware 50-010-0088-00113-1-01 MS GII RevN Updated versions of this document may be available at WWW.MULTIFORM-LIGHTING.COM RevB 08/2013 Order code: 12-010-0083-80201-1-01...

  • Page 4: Safety Information

    User Manual: Multispot GII-HS3045/HT3030 ■ Introduction Dear customer, congratulations on the purchase of a Multiform-branded item and the trust having been put in us with this decision. Multiform is one of the leading global manufacturers of professional lighting equipment and has decades of experience in design, production and quality assurance.
  • Page 5 User Manual: Multispot GII-HS3045/HT3030 WARNING! Shock hazard. Equipment must be properly grounded. WARNING! Hot surface. Risk of skin burn or skin irritation. WARNING! Fire hazard. WARNING! Laser radiation. Risk of surface damage. WARNING! LED light emission. Risk of eye injury. ■...
  • Page 6 User Manual: Multispot GII-HS3045/HT3030 Protection from electric shock: Only connect this unit to a mains socket outlet with protective earth connection, ground-fault (earth-fault) and overload protection. Where the mains plug or an appliance coupler is used as a dis- connect device, such device shall remain readily operable. To pull the AC Cord out of the wall outlet or the unit’s AC socket, never pull the cable itself, but only the AC plug.
  • Page 7 User Manual: Multispot GII-HS3045/HT3030 The surface of the device may get hot during operation, and heat sink areas may reach to or exceed the limits of EN60950. Do not touch heat sink areas of the device during operation, and allow 20 minutes of cool-down time after powering off before touching.
  • Page 8 User Manual: Multispot GII-HS3045/HT3030 ■ LED Lifetime advice LED lifetime is determined by the gradually declining brightness of a LED over time, with a point of 50% brightness reduction marking the defined end of its lifetime. The driving factor of this effect is the heat that the chip inside the LED is exposed to. While a chip may under ideal circumstances reach to more than 100000 hours of lifetime, the real-world lifetime may only be 30000 to 50000 hours or less if the LED is exposed to excessive heat, which can be caused by continuously running all LEDs inside this...
  • Page 9 User Manual: Multispot GII-HS3045/HT3030 Before you start to change the connectors, please make sure that: • yourself or the person in charge has the relevant experience in safe work methods for electrical equipment service and maintenance. • the unit is disconnected from any AC source. Please note that this also applies to the unit’s AC output, since being connected by the AC output to other units which are still under AC supply, will still supply power to the unit.
  • Page 10 User Manual: Multispot GII-HS3045/HT3030 Loosen the 6pcs. of HexInsert screw that hold the rear cover of the power supply compartment, and remove the screws. Carefully lift the rear cover with the attached electronics assembly from the main unit. Turn the rear cover around, and unplug the wire connections to the main unit. Detach the rear cover with the attached electronics assembly from the main unit.
  • Page 11 User Manual: Multispot GII-HS3045/HT3030 V2.00 (08-2013)
  • Page 12 User Manual: Multispot GII-HS3045/HT3030 V2.00 (08-2013)
  • Page 13 User Manual: Multispot GII-HS3045/HT3030 ■ Getting started: changing the lens panel (only if required – only HT3030) Your MULTISPOT-GII-HS3045/HT3030 has been factory-fitted with the default lens panel. If you need to exchange the lens panel to achieve specific dispersion angles (only HT3030), please contact your distributor for availability information of other lens panels and follow the below procedure to exchange the lens panel if required.
  • Page 14 User Manual: Multispot GII-HS3045/HT3030 Remove the 5 standoffs that define the lens panel distance to the PCB by unscrewing them with left-turns. Keep these 5 standoffs stored together with the removed lens panel as every specific lens panel has its matching standoff length.
  • Page 15 User Manual: Multispot GII-HS3045/HT3030 ■ Getting started: choosing a location Risk of fire: The MULTISPOT-GII-HS3045/HT3030 LED has been designed for environmental temperatures of up to 40 degrees Celsius. For proper operation, the unit must be operated with unobstructed air convection to its outside metal case. Do not: •...
  • Page 16 User Manual: Multispot GII-HS3045/HT3030 weight of the device when installing the unit. This secondary safety attachment should be installed in a way that no part of the installation can drop more than 20cm if the main attachment fails. • Never stand directly below the device when mounting, removing, or servicing the fixture.
  • Page 17 User Manual: Multispot GII-HS3045/HT3030 ■ Operation User interface overview: MODE selection Button LEFT ARROW Button RIGHT ARROW Button – Button + Button DISPLAY: Sound-to-Light Indicator DISPLAY: 4-Digit Message Display Area DISPLAY: + Indicator DISPLAY: - Indicator DISPLAY: ARROW Indicators DISPLAY: DMX Signal Presence Indicator Microphone cover membrane DMX Input DMX Output...
  • Page 18 User Manual: Multispot GII-HS3045/HT3030 Upon the user’s choice, the unit can work in stand-alone automatic mode, or with fixed colors, or it may be controlled by external DMX-controllers. Available modes: ■ STATIC COLOUR Press the MODE button until the display shows “STxx” whereas xx stands for numbers 0 until 25.
  • Page 19 User Manual: Multispot GII-HS3045/HT3030 1 second accelerates the change rate of the displayed value to 3 times. If no further changes are made to the dimming level by the +/- buttons, the display will automatically return to show “C0”…”C225” after 5 seconds, and the dimming level will remain as last set.
  • Page 20 User Manual: Multispot GII-HS3045/HT3030 Please note that above speed levels are only applicable to patterns SP0….SP08. For the strobe patterns, the following speed table applies: Setting Speed Beatflash function: one flash per sound trigger (Strobe-to-Sound) SL1..SL25 Strobe speed 1 Hz...18Hz Choosing “S2L”...
  • Page 21 User Manual: Multispot GII-HS3045/HT3030 SL11 1 loop per 6 seconds SL24 2,8 loops per second SL12 1 loop per 4 seconds SL25 3,2 loops per second Once the speed level is set and no changes done the display will return to show “FP0”…”FP7”...
  • Page 22 User Manual: Multispot GII-HS3045/HT3030 changed. After 30 sec. of no alterations or if the MODE button is pressed the display returns to show “GDMX”. IN PRES (preset mode), the channel assignment is as follows: CH1 = 000-255: Color presets ST1….ST25 as in Static Color Mode [If CH3 < 050] CH1 = 000-127: Fade presets FP0…FP7 as in Switch Pattern Mode [If CH3 ≥...
  • Page 23 User Manual: Multispot GII-HS3045/HT3030 ■ EDIT Automatic DMX addressing. This allows to use the first device in a row of units connected via DMX to be used as a master unit and set all subsequent units’ DMX address automatically. On the first (master) unit, in EDIT menu, use the left/right arrows until the display shows “ADMX”.
  • Page 24 User Manual: Multispot GII-HS3045/HT3030 This device does not need regular maintenance. It is protected by an internal fuse located on the power supply PCB. If this fuse fails, this usually indicates an internal fault requiring servicing by a qualified engineer. The fuse shall only be replaced by a fuse of same specification, and the replacement has to be made by qualified personnel obeying applicable safety rules.
