Apollo MXR Operating Manual

Color mixing scroller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
[
]

Limited Warranty

• Items are covered for defects in materials and workmanship for one year, including
repair parts and repair labor on defective item, from date of Apollo invoice. The
warranty covers freight for 30 days after initial purchase. Apollo does not cover any
other loss resulting from product failure.
•
Products being returned for warranty repair must display the original serial number
sticker. Removal of the serial number sticker voids the product's limited warranty.
• Despite the care taken for the compilation of this book, Apollo Design Technology,
Inc cannot be held responsible for any damages resulting from errors that may
appear in this book. All efforts have been made to provide the most accurate,
up-to-date instructions and illustrations possible.
• Need assistance? Call Apollo at 800-288-4626 for details.
Keep this information handy if requiring technical assistance.
Serial Number
Date Purchased
Purchased From
[
]

Contact Information

Apollo Design Technology
4130 Fourier Drive Fort Wayne, IN 46818 USA
Phone: +01.260.497.9191
Fax: +01.260.497.9192
www.apollodesign.net
[ ]
15
4-17-09
Color Mixing Scroller
Operating Manual
[ ]

Advertisement

Table of Contents
loading

Related Manuals for Apollo MXR

Summary of Contents for Apollo MXR

  • Page 1: Limited Warranty

    Operating Manual • Despite the care taken for the compilation of this book, Apollo Design Technology, Inc cannot be held responsible for any damages resulting from errors that may appear in this book. All efforts have been made to provide the most accurate, up-to-date instructions and illustrations possible. • Need assistance? Call Apollo at 800-288-4626 for details. Keep this information handy if requiring technical assistance. Serial Number Date Purchased Purchased From Contact Information Apollo Design Technology 4130 Fourier Drive Fort Wayne, IN 46818 USA Phone: +01.260.497.9191 Fax: +01.260.497.9192 www.apollodesign.net 4-17-09...

  • Page 2: Table Of Contents

    Troubleshooting Table Of Contents Symptom Cause Solution MXR fails to start and home No power from power supply • Verify that the power supply is on • Verify that XLR pinout is compatible Safety Information ................2 • Verify 4 pin cable is good Introduction ..................3...

  • Page 3: Safety Information

    R393 L738 L744 L746 – – • The MXR is designed for indoor applications and should not be R395 L747 exposed to moisture. L748 L763 R397 L764 • There is a risk of fire, shock or injury if the MXR is not used as specified. L765 R398 L767 L770 • Servicing the MXR should be undertaken by qualified personnel only. L776 L777 L778 • The MXR is not intended for residential use. L779 L781 L789 • Safety cables must be used when installing the MXR.

  • Page 4: Introduction

    R376 L363 Do not apply power to a lighting fixture without first powering up the MXR. If power is not applied L366 first to the MXR, heat from the lighting fixture will cause damage to the MXR and the gel strings.

  • Page 5: Using The Mxr

    L158 AP7800 Apricot Orange L159 • Do not apply power to a lighting fixture without first powering up the MXR. If power is not AP7850 Hot Lava Orange R358 L161 applied first to the MXR, heat from the lighting fixture will cause damage to the MXR and...

  • Page 6: Powering Up

    Color ® or Smart Move ® products can be daisy chained together using the “OUT” plug. AP3000 Simply Mauvelous L002 • Apply power and DMX signal to the MXR. A short homing sequence will occur. The fan will run AP3050 Purple Mist L003...

  • Page 7: Addressing

    • With “Fan” in the display press the “MENU” button. Press the “UP” button to activate the fan options. Gel Shield • Selecting “_1_” will set the fan to run constantly at low speed. Use this setting when the MXR is being used with low wattage fixtures or in locations requiring quiet operation.

  • Page 8: Gel String Speed Control

    This will cause the MXR to enter the speed control mode. • Use only MXR gel string sets sold by Apollo. Color mismatch will occur if other strings are used. • With “SPd” in the display press the “MENU” button.
